Camden · CM-1130

Camden CM-1130 Key Switch SPDT Maintained Contact

SPDT key switch with maintained contacts for 30VDC strike control

• Dual NO/NC contacts stay actuated until manually reset—no relay logic needed
• 30VDC operation integrates directly with standard access control panels
• TCP/IP network support connects to HID reader systems without gateway device

Camden · CM-1150

Camden CM-1150 Key Switch 2 SPDT Momentary

Dual-contact key switch for HID access control and electric strike activation

• Two SPDT momentary contacts trigger door locks at 30VDC
• Integrates with HID-based access control systems and strike panels
• Momentary pulse activation for credential verification workflows

Camden · CM-1160

Camden CM-1160 Key Switch 2 SPDT Maintained

• Two independent SPDT maintained contacts hold 30VDC state without relay logic.
• Die-cast aluminum housing resists vandal and tamper attempts in high-traffic installs.
• Fits 1", 1-1/8", or 1-1/4" mortise cylinders for drop-in retrofit on legacy hardware.

Camden · CM-1180

Camden CM-1180 Key Switch DPDT Momentary

• DPDT momentary contacts switch two independent circuits simultaneously at 30VDC.
• Die-cast quarter-inch aluminum body withstands prying and weathering on commercial doors.
• Accepts 1", 1-1/8", or 1-1/4" mortise cylinders for straightforward retrofit installs.

Camden · CM-1182

Camden CM-1182 Key Switch DPDT Momentary

• DPDT configuration controls two independent circuits from a single key activation.
• Momentary spring-return contact prevents sustained power draw on strikes or mag-locks.
• Die-cast aluminum housing withstands outdoor and high-humidity environments like loading docks.

Camden · CM-1190

Camden CM-1190 DPDT Maintained Key Switch

• DPDT maintained contacts hold switching state until key withdrawal, eliminating bounce-related unlock errors.
• 30VDC rated contacts drive electric strikes, mag-locks, or solenoids directly without external relay stages.
• Die-cast aluminum housing with tamperproof hardware supports outdoor and industrial surface mounting.

Camden · CM-1192

Camden CM-1192 Key Switch DPDT Maintained

• DPDT design switches two fully isolated circuits simultaneously from a single key.
• Maintained contacts hold state after rotation — no electronic pulse or spring return.
• Rated 30VDC; compatible with 12VDC and 24VDC EM lock and electric strike circuits.

Camden · CM-1200

Camden CM-1200 Key Switch SPST Momentary N/O

• Momentary N/O contact eliminates hold-open risk in safety-critical access points.
• 30VDC rating integrates directly with EM locks and electric strikes, no conditioning needed.
• Cast stainless steel housing withstands corrosion, UV, and rain for perimeter installs.

Camden · CM-1205

Camden CM-1205 Key Switch SPST Momentary

• Momentary SPST contact prevents accidental prolonged energization of strikes or EM locks.
• Rated 30VDC for direct wiring to standard strike controllers and EM lock power supplies.
• Accepts standard 1–1.25 in. mortise cylinders to match existing hardware across facilities.

Camden · CM-1210

Camden CM-1210 Key Switch SPST Maintained

• Maintained SPST contact latches open until manually reset, eliminating accidental release.
• Rated 30VDC for direct wiring to standard access control panel outputs—no relay needed.
• Stainless steel flush-mount housing resists corrosion in outdoor and high-moisture installs.

Camden · CM-1230

Camden CM-1230 Key Switch SPDT Maintained Contact

• SPDT maintained contact holds N/O and N/C outputs until key returns to neutral.
• 30VDC rating integrates directly with standard electric strikes and mag-lock supplies.
• One-piece cast stainless steel body suits corrosive, wet, or salt-air environments.

Camden · CM-1250

Camden CM-1250 Key Switch SPDT Momentary

• Two independent SPDT momentary contacts let you trigger a strike and relay signal simultaneously.
• 30VDC dry-contact rating integrates directly with standard EM lock and electric strike panels.
• Accepts 1"–1¼" OD mortise cylinders for straightforward retrofit into existing commercial frames.

Camden · CM-1260

Camden CM-1260 Key Switch SPDT Maintained

Maintained key switch for TCP/IP door control systems at 30VDC

• SPDT maintained contact holds switch state for door lock and strike control
• TCP/IP networked integration with HID credential compatibility
• 30VDC operation for reliable access control deployment

Camden · CM-1270

Camden CM-1270 Key Switch SPDT Momentary and Maintained

• SPDT contact supports both momentary and maintained modes in one assembly.
• Rated 30VDC for direct integration with standard access control power supplies.
• Flush-mount mortise cylinder body ships with all mechanical fastening hardware.

Camden · CM-1290

Camden CM-1290 DPDT Maintained Key Switch

• DPDT contacts let you simultaneously control two independent circuits without cross-wiring.
• Maintained design holds circuit state after key release, enabling sustained bypass functions.
• Rated 30VDC — drops directly into 24V/30V access control loops with no step-down required.

Camden · CM-1292

Camden CM-1292 Key Switch DPDT Maintained

• DPDT maintained contacts hold state without powered relay, reducing panel logic complexity.
• 30VDC rating integrates directly with standard access control panel power supplies.
• Mortise cylinder mount accepts 1"–1¼" cylinders for flush, tamper-resistant frame installs.

Camden · CM-2000

Camden CM-2000 Key Switch SPST Momentary N/O

• 30VDC SPST N/O contact drives door strikes or mag-locks with no relay required.
• 1.75" flush-mount body fits tight door jambs where 2.75" switches cannot install.
• 1/4" die-cast aluminum housing accepts standard 1"–1-1/4" mortise cylinders.

Camden · CM-2000/21

Camden CM-2000/21 Narrow Neoprene Gasket for Push Buttons

• Neoprene construction resists UV, ozone, and temperature cycling for lasting outdoor seals.
• Narrow profile fits constrained door frame cutouts without requiring frame modification.
• Rated for 30VDC proximity reader circuits, maintaining a moisture barrier at button contacts.

Camden · CM-2005

Camden CM-2005 Key Switch SPST Momentary N/C

Key-switched SPST momentary control for networked access at 30VDC

• Normally closed (N/C) contacts with momentary activation for door strike control
• TCP/IP communication with HID credential integration for access systems
• 30VDC rated for compatibility with standard access control power supplies

Camden · CM-2010

Camden CM-2010 Key Switch SPST Maintained

• SPST maintained contact holds circuit state at 30VDC without repeated actuation.
• Die-cast 1/4-inch aluminum body resists tampering and corrosion at outdoor entries.
• Mortise cylinder fits 1", 1-1/8", or 1-1/4" bores for master-key system integration.

Camden · CM-2020

Camden CM-2020 Key Switch SPDT Momentary

SPDT momentary key switch for HID access control at 30VDC

• Single-pole, double-throw contact for door lock and strike integration
• 30VDC operation compatible with HID credential reader systems
• Momentary activation for electromagnetic locks and solenoid strikes

Camden · CM-2030

Camden CM-2030 Key Switch SPDT Maintained

• SPDT maintained contact holds relay closed while key is turned, enabling reliable manual override.
• 30VDC rating integrates directly with commercial lock supplies—no intermediate network layer needed.
• One-piece die-cast aluminum body fits 1¾" openings and accepts standard mortise cylinders.

Camden · CM-2050

Camden CM-2050 Key Switch with Dual SPDT Momentary

• Dual independent SPDT circuits enable simultaneous control of two separate door devices.
• Momentary-only action prevents continuous lock bypass — circuit closes only while key is held.
• Operates at 30VDC, integrating directly with standard 24–30V mag locks and electric strikes.

Camden · CM-2060

Camden CM-2060 Key Switch SPDT Maintained Contact

Key-operated SPDT switch with dual relays, 30VDC, HID compatible

• Dual independent SPDT relays for simultaneous control of two circuits
• Maintained contact design holds signal stable while key is engaged
• 30VDC operation integrates with standard access control power supplies

Camden · CM-2090

Camden CM-2090 Key Switch DPDT Maintained

DPDT maintained key switch with HID credential auth over TCP/IP

• 30VDC operation with latching contact for continuous strike control
• HID credential authentication integrated over TCP/IP network communication
• Compatible with TCP/IP-enabled access control platforms and door locks

Camden · CM-2200

Camden CM-2200 Key Switch SPST Momentary N/O

• SPST momentary N/O contact delivers clean single-pulse triggering at 30VDC.
• Compact 1¾" flush-mount housing fits tight door frames without frame modification.
• Accepts 1", 1⅛", or 1¼" mortise cylinders for straightforward key standardization.

Camden · CM-221/46

Camden CM-221/46 ValueWave Touchless Switch Single Gang

• Adjustable 2–8 in. IR detection range minimizes false triggers in high-traffic corridors.
• Form C dry relay (1A @ 30VDC) drives EM locks directly or feeds access control panel inputs.
• 10ms relay response and IP65 sealing suit sterile, wash-down, and high-volume entry points.

Camden · CM-221/46N

Camden CM-221/46N ValueWave™ Touchless Switch Narrow Jamb

• IR activation at 2–8 inches eliminates contact, reducing cross-contamination risk.
• Form C relay output (1A @ 30VDC) drives EM locks and door operators without added modules.
• IP65 rating supports washdown environments including restrooms, kitchens, and wet areas.

Camden · CM-221/46W

Camden CM-221/46W ValueWave™ Touchless Switch Double Gang

• IR touchless activation eliminates contact surfaces, reducing hygiene risk in high-traffic entries.
• TCP/IP connectivity enables remote audit logging and emergency unlock from access-control panels.
• Double-gang form factor fits standard wall boxes, simplifying retrofits at dual-door access points.

Camden · CM-221/A42

Camden CM-221/A42 ValueWave Touchless Switch Single Gang

Network touchless switch with HID credentials and electromagnetic lock control

• TCP/IP connectivity for remote access management and real-time door status
• HID-compatible credentials integrate with existing card reader infrastructure
• 30VDC electromagnetic strike in single-gang form factor for retrofit installations

Camden · CM-221/A42W

Camden CM-221/A42W ValueWave Touchless Switch Double Gang

• IP65-rated housing withstands washdowns and humidity in high-traffic entry points.
• Form C relay (1A @ 30VDC) integrates with any standard access panel—no proprietary interface.
• IR touchless activation removes hand-contact vectors; adjustable range 2–8 inches.

Camden · CM-222/46

Camden CM-222/46 ValueWave Touchless Switch Single Gang

• Active IR sensor detects hand presence at 2–8 in. in 10 ms, eliminating touch points.
• 12–24 VDC relay output (1A/30VDC) drives EM locks or solenoid strikes in NO/NC configs.
• IP65-rated, −13°F to 122°F range suits indoor vestibules and outdoor-facing entries.

Camden · CM-222/46N

Camden CM-222/46N ValueWave Touchless Switch Narrow Jamb

• IR touchless activation eliminates contact wear and cross-contamination in high-traffic areas.
• TCP/IP connectivity enables remote status reporting and audit trail integration over standard Ethernet.
• Narrow jamb profile fits 4.625-inch door frames without surface protrusion or swing obstruction.

Camden · CM-222/46W

Camden CM-222/46W ValueWave Touchless Switch Double Gang

• Touchless IR microburst activation eliminates contact, reducing cross-contamination risk.
• Dual relay outputs (Common/N.O./N.C.) drive EM locks or signaling devices up to 1A/30VDC.
• IP65-rated; detection range and time delay tunable on-site for precise door-traffic tuning.

Camden · CM-222/A42

Camden CM-222/A42 ValueWave Touchless Switch Single Gang

• IR microburst sensor detects hand presence at 2–8 inches, eliminating physical contact.
• Runs on 12–24VDC with 45mA peak draw; fits standard single-gang boxes for easy retrofit.
• 10ms activation latency and 0.5–20s adjustable hold time suit automatic door opener circuits.

Camden · CM-222/A42N

Camden CM-222/A42N ValueWave Touchless Switch Narrow Jamb

• Active IR microburst sensor adjusts 2–8 in. detection; immune to ambient light and shadows.
• 1-3/4" jamb profile fits standard 4-7/8" frames—no wall excavation or frame modification needed.
• Dry-contact relay (C/NO/NC) integrates with any access control panel or standalone 24VDC lock.
