DMP · 736P

DMP 736P Radionics POPIT Interface Module

• Interfaces DMP systems with Radionics POPIT devices for cross-platform integration.
• Expansion module form factor simplifies addition to existing DMP control panel installations.
• Datasheet available for download to support pre-deployment planning and compliance review.

DMP · 738A

DMP 738A Interface Expansion Module

TCP/IP expansion module for DMP control panels with 12VDC operation

• TCP/IP communication eliminates proprietary serial links for clean network integration.
• Draws 12VDC from existing panel supply rail—no separate regulated power source needed.
• Slot-based form factor (5.5"×3"×0.75") minimizes panel footprint versus stand-alone boxes.

DMP · 7463-W

DMP 7463-W Network Thinline LCD Keypad with Prox Reader

Network LCD keypad with dual PIN and proximity card access

• Network communication eliminates dedicated wiring runs, simplifying multi-keypad deployments.
• Integrated proximity reader supports dual-credential (PIN + prox card) access from one device.
• Built-in 4-hour backup battery maintains operation during AC loss without an external enclosure.

DMP · 763

DMP 763 Wi-Fi Interface Module

Wi-Fi interface for DMP keypad systems—wireless retrofit or new build

• Adds 2.4GHz Wi-Fi to DMP XT/XR panels—no network cable run required.
• Auto-fails over to cellular if Wi-Fi drops, maintaining signal path continuity.
• Draws 12VDC directly from panel supply; no external power adapter needed.

DMP · 861

DMP 861 Power Distribution/4 Wire Bus Module

Centralized power & 4-wire bus module for multi-keypad access systems

• 4-wire bus connectivity synchronizes multiple keypads and readers from one module.
• Centralized 12V/24V DC power distribution eliminates distributed point-of-load supplies.
• Compact form factor mounts in existing DMP cabinets with no separate power supply needed.

DMP · 865

DMP 865 Style W/X Notification Module

TCP/IP notification module for DMP control panel auxiliary expansion

• TCP/IP integration eliminates dedicated serial runs in DMP control panel networks.
• Monitors opens, shorts, and ground faults on notification circuits in real time.
• Operates at 9.6–14.2 VDC, compatible with panel-mounted or remote 24VDC supplies.

DMP · 866

DMP 866 Notification Module

12VDC auxiliary notification module for DMP access control expansion

• Runs on 12VDC, integrating directly into existing access control cabinet power supplies.
• Auxiliary architecture adds notification endpoints without disrupting active panel configs.
• Scales multi-door and multi-reader deployments without replacing core control infrastructure.

DMP · 869

DMP 869 Style D Initiating Module

25VDC initiating module expands DMP security system zones

• Two independent supervised 4-wire initiating circuits expand DMP panel zone capacity.
• 8–25 VDC operating range integrates directly with standard DMP power distribution.
• Continuous ground-fault supervision detects wiring opens, shorts, and faults pre-alarm.

DMP · 893A

DMP 893A Dual Phone Line Module Keypad

Dual phone line keypad module for DMP access control expansion

• Monitors main and backup phone lines for voltage drops, alerting local keypads and central station.
• UL 864 listed and FCC Part 15/68 compliant, meeting fire signaling and telecom regulatory requirements.
• Installs into DMP panel enclosure at 12VDC via wire harness, fitting existing auxiliary expansion slots.

DMP · AP2-20N

DMP AP2-20N Curtain PIR Motion Detector

Curtain PIR motion detector for doorways, windows, and perimeter zones

• Vertical curtain pattern limits coverage to doorways and windows, cutting lateral false alarms.
• Hardwired zone-loop connection eliminates battery maintenance and wireless mesh overhead.
• Native DMP panel integration supports unified hardwired architecture with contacts and keypads.

DMP · CM-30E

DMP CM-30E Push to Exit Button

24VDC networked push-to-exit button for DMP access control

• Accepts 12 or 24 VDC supply, matching either DMP XT or XR Series panel output.
• SPDT contacts support NO or NC wiring to meet your panel's fail-safe configuration.
• Single-gang stainless faceplate fits standard electrical boxes; consumes one zone input.

DMP · CM-310GPTE

DMP CM-310GPTE Slimline Push to Exit Button

Slimline push-to-exit button with TCP/IP networking for access control

• Runs on 24VDC, matching standard door-zone power supplies with no added distribution hardware.
• Native TCP/IP communication eliminates gateway hardware, reducing labor on networked deployments.
• HID credential compatibility lets integrators standardize reader ecosystems across the facility.

DMP · CMC-2

DMP CMC-2 Conekt Bluetooth Mobile Credential

Bluetooth mobile credential reader for DMP wireless access control

• BLE-based authentication eliminates physical card issuance and reduces lost-credential overhead.
• MIFARE DESFire EV1 encryption prevents credential cloning for compliance-sensitive deployments.
• Integrates natively with DMP Conekt panels; no third-party API gateway or VMS required.

DMP · CSK-2

DMP CSK-2 MIFARE DESFire EV2 Keyfob Credential

13.56 MHz contactless keyfob with MIFARE DESFire EV2 encryption

• DESFire EV2 encryption enables dynamic credential reissuance without hardware replacement.
• ISO 14443-A at 13.56 MHz ensures compatibility with all DESFire EV2-certified readers.
• Keyfob form factor attaches to key rings, reducing credential loss risk in daily use.

DMP · CSM-2P

DMP CSM-2P MIFARE DESFire EV2 Smart Card

MIFARE DESFire EV2 contactless smart card with 128-bit AES encryption

• 128-bit AES encryption blocks credential cloning and eavesdropping attacks.
• 13.56 MHz ISO 14443-A protocol integrates with HID, Salto, and Axis readers.
• Standard CR80 card dimensions (2.1"×3.4"×0.03") fit existing badge holders.

DMP · CX-702

DMP CX-702 PIR Motion Detector 70' x 70' Coverage

70' x 70' PIR motion detector for wired intrusion systems

• 70' x 70' coverage monitors ~4,900 sq ft per sensor, reducing device count on large sites.
• 12VDC operation integrates into existing panel aux power loops — no separate supply needed.
• Passive infrared sensing eliminates active illumination and resists false alarms from light shifts.

DMP · ES501

DMP ES501 Plug-In Transformer Enclosure

Compact transformer enclosure for DMP NFC/13.56MHz access control

• Hinged metal cover with built-in venting protects transformers while dissipating heat.
• Compact 4.25″×5.625″×2.5″ footprint consolidates transformer power at the control panel.
• Supports low-voltage transformers rated over 20 VA for DMP access control installations.

DMP · ES502

DMP ES502 Transformer Enclosure

Isolated transformer housing for DMP control panel systems

• Vented metal housing protects transformers 20 VA and above from dust and accidental contact.
• Compact 4.25" × 5.625" × 3.75" footprint integrates into standard DMP control panel layouts.
• Hinged cover enables fast one-handed transformer access for maintenance in wall-mount installs.

DMP · ET10-7WS

DMP ET10-7WS Multi-Technology Access Control Reader

Wired multi-technology reader for mixed-credential access control

• Multi-technology credential support reduces hardware SKUs in mixed or retrofit deployments.
• Wired connection delivers deterministic, RF-interference-free communication to the access panel.
• Compact 5.1" × 1.7" × 0.71" body fits narrow mullions and constrained door-frame cutouts.

DMP · ET20-7WS

DMP ET20-7WS Multi-Technology Access Control Reader

Dual-credential reader for NFC and 125kHz cards in compact form

• Reads both NFC/13.56MHz and 125kHz prox cards, eliminating separate readers per door.
• OSDP support enables encrypted two-way comms, reducing credential cloning exposure.
• Wiegand output ensures drop-in compatibility with legacy and modern access panels.

DMP · ET25-7WS

DMP ET25-7WS Multi-Technology Access Control Reader

Compact multi-technology reader with OSDP & Wiegand for mixed credentials

• Supports both OSDP and Wiegand, enabling use with legacy and modern panels.
• 5.1" x 3.25" x 0.71" form factor fits standard door frames without modification.
• Multi-technology credential support reduces hardware count in mixed-format deployments.

DMP · OP-08CB

DMP OP-08CB Motion Detector

Wired ceiling motion detector for door and window zone monitoring

• Dual 12/24 VDC operation eliminates hardware swaps across XT and XR Series panels.
• Two-conductor wired zone input integrates directly—no adapters or gateways required.
• Fail-safe or fail-secure relay output supports egress code compliance on power loss.

DMP · P-500-H-A

DMP P-500-H-A Alps Proximity Reader

TCP/IP proximity card reader for distributed door-level access control

• 8-inch read range handles high-traffic turnstiles without precise card positioning.
• 5–16V input tolerance integrates with existing DMP keypads and control nodes.
• Metal-surface mounting maintains full read range on steel door frames and enclosures.

DMP · P-640-H-A

DMP P-640-H-A Patagonia Proximity Reader with Keypad

Dual-credential proximity and keypad reader for DMP access control

• Accepts proximity cards, proximity tags, and PIN codes for flexible credential deployment.
• Wired connection to DMP panels enables real-time credential verification without network dependency.
• Single faceplate houses both 125 kHz proximity reader and keypad, simplifying door hardware.

DMP · PP-6005B

DMP PP-6005B Proxpoint Plus Proximity Reader

Wired proximity reader for DMP panels; reads 26-bit and 35-bit cards

• Reads 26-bit and 35-bit proximity cards, supporting mixed credential deployments.
• Supervised loop wiring ties directly to DMP 734, 7073/7073A, 7173, and 7873 panels.
• 4.75–16VDC tolerance and weatherized enclosure suit covered exterior door installations.

DMP · PSC-1

DMP PSC-1 Standard Light Proximity Card

Standard light proximity card for multi-door access control

• Reads up to 8 inches from compatible proximity readers for hands-free entry.
• Credit-card dimensions (2.2"×3.4"×0.6") fit wallets and strap clips without bulk.
• Passive credential requires no wiring or tools, simplifying multi-door deployments.

DMP · PSK-3

DMP PSK-3 Proximity Key Ring Tag

125 kHz proximity key ring tag for DMP & third-party readers

• 125 kHz passive operation eliminates battery management across large credential deployments.
• 26-bit Wiegand encoding ensures compatibility with DMP readers and standard third-party panels.
• Compact 1.2"×1.5"×0.15" key ring form factor keeps credentials on-person, reducing re-enrollment.

DMP · PSM-2P

DMP PSM-2P ISO Imageable Proximity Card

ISO imageable proximity card for 125 kHz access control systems

• 125 kHz RF integrates with existing proximity readers—no additional hardware required.
• ISO-standard dimensions support direct photo printing, consolidating badge and photo ID in one card.
• PVC construction withstands daily handling without delamination or RF performance loss.

DMP · SR3

DMP SR3 Bluetooth Wireless Access Control Reader

Wireless 125kHz proximity reader with encrypted Bluetooth, no cables

• Bluetooth wireless link eliminates cable runs, cutting retrofit installation labor.
• Reads standard 125kHz proximity cards and fobs, compatible with existing credential stock.
• Encrypted wireless transmission protects credentials against eavesdropping and cloning.

DMP · USB

DMP USB Multi-Technology Access Control Reader

USB multi-technology reader for mixed credential deployments

• Reads both 125kHz proximity and 13.56MHz NFC credentials from a single reader head.
• USB interface moves credential format logic to panel software, not door hardware.
• Integrated 15-foot cable covers standard door-mount runs without hubs or amplifiers.

DMP · X1-8

DMP X1-8 Multi-Door Access Controller

Wired multi-door controller with OSDP and keypad reader support

• OSDP communication ensures standardized, secure reader-to-controller dialogue.
• Single controller manages credential-based access across multiple door points.
• PoE 802.3af support simplifies wired deployment by eliminating separate power runs.

DMP · X1-POE

DMP X1-POE PoE Module

PoE module for DMP X1 access control over single Ethernet cable

• 802.3af PoE delivers power and data over one CAT5e/6 run—no door-side PSU needed.
• 10Base-T/100Base-TX support keeps legacy copper and modern switch plants compatible.
• Exclusive X1 series integration simplifies single-door controller deployment at scale.

DSC · HS2016NK

DSC HS2016NK Keypad Reader

PIN keypad reader with included 16.5 VAC transformer for DSC access control

• UL/ULC listed access control keypad reader
• 16.5 VAC transformer included (CSFM certified)
• 213 x 235 x 52 mm wall-mount form factor

DSC · HS2032NK

DSC HS2032NK Security Keypad Reader

Hardwired keypad reader with included transformer for PIN entry access control

• Security keypad reader, UL/ULC listed with CSFM
• 16.5 VAC transformer included for power supply
• 213 x 235 x 52 mm wall-mount keypad form

DSC · HS2064NK

DSC HS2064NK Access Control Keypad Reader

Hardwired numeric keypad reader with included transformer for access control

• Access control keypad reader, UL/ULC and CSFM listed
• 16.5 VAC transformer included for power supply
• 297 x 298 x 78 mm wall mount form factor

DSC · HS2128NK

DSC HS2128NK Keypad Reader

UL/ULC-listed keypad reader for DSC hardwired security systems

• UL/ULC listed keypad reader for security installs
• 16.5 VAC transformer included (CSFM certified)
• 297 x 298 x 78 mm wall-mount form factor
