Resolution:
2MP
Lens Type:
Varifocal
IR Low Light:
IR; Lightfinder
WDR:
Forensic WDR
Video Compression:
H.265
Form Factor:
Dome
Power Type:
PoE+ (PoE+ Type 1 Class 3)
IP Rating:
IP66
Environment Rating:
IK10
IR Distance:
Optimized IR; Lightfinder 2.0
Compatibility:
PoE
Audio Support:
Acoustic sensor for audio analytics
Analytics:
Object classification; people and vehicle counting; motion detection; customizable masking
Mount Type:
Ceiling; Wall
Frame Rate:
60 fps @ 2MP
Storage Capacity:
microSD card support
Features:
Axis Edge Vault with FIPS 140-3 Level 3; case-open sensor
VMS Compatibility:
ONVIF Profile S/T/G
Type:
Dome
Product Type:
Dome
Night Vision:
IR
Wide Dynamic Range:
Forensic WDR
Housing Color:
White
Mounting:
(Probe Dependant)
Image Sensor:
CMOS
Lightfinder:
Lightfinder 2.0
Min Illumination/ Light Sensitivity (color:
0.08 lux
Min Illumination/ Light Sensitivity (b/w:
0 lux
Max Frames Per Second:
50/60
Day And Night Functionality:
Yes
Focal Length:
3.4 - 9.8 / 10.8 - 28.2 mm
Horizontal Field Of View:
100-32 / 29.1-11.0 °
Vertical Field Of View:
52-18 / 16.4-6.2 °
Zipstream:
Yes
H.264:
Baseline, High, Main
H.265:
Yes
AV1:
On
PoE Class:
3
Signed OS:
Yes
Secure Boot:
Yes
Secure Keystore:
Secure Element (CC EAL6+, FIPS 140-3 Level 3)
Axis Edge Vault:
Yes
Remote Focus:
Yes
Remote Zoom:
Yes
Built-in IR:
Yes
Local Storage (memory Card Slot:
Yes
Operating Temperature:
-40 to 50 °C
Outdoor Ready:
Yes
Vandal Rating:
IK10
Designed For Repaint:
Yes
Sustainability:
BFR/CFR free, PVC free
Variants:
AXIS P3285-LVE 10 mm AXIS P3285-LVE 29 mm
Minimum Focus Distance:
1 m (3.28 ft) 29 mm lens: Varifocal, 10.8–28.2 mm, F1.70–1.76; 3 m (9.84 ft) IR corrected, remote zoom and focus, P-Iris control
Minimum Illumination Color:
0.08 lux at 50 IRE, F1.4; 0.08 lux at 50 IRE, F1.71
Minimum Illumination B/W:
0.02 lux at 50 IRE, F1.4 0 lux with IR illumination on; 0.02 lux at 50 IRE, F1.71 0 lux with IR illumination on
Shutter Speed:
1/37000 s to 2 s
Camera Adjustment:
Pan ±190°, tilt -45 to +80°, rotation ±95°
Model:
ARTPEC-9
Compute Capabilities:
Deep learning processing unit (DLPU)
Video Streaming:
Up to 20 unique and configurable video streams Axis Zipstream technology in AV1, H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265/AV1 Low latency mode Video streaming indicator
Signal-to-noise Ratio:
>55 dB
Multi-view Streaming:
Up to 7 individually cropped out view areas
Noise Reduction:
Spatial filter (2D noise reduction) Temporal filter (3D noise reduction)
Image Settings:
Saturation, contrast, brightness, sharpness, white balance, day/night threshold, local contrast, tone mapping, exposure mode, exposure zones, defog, barrel distortion correction, compression, rotation: 0°, 90°, 180°, 270° including corridor format, m
Image Processing:
Axis Zipstream, Forensic WDR, Lightfinder 2.0, OptimizedIR
Pan/Tilt/Zoom:
Digital PTZ, preset positions Guard tour, control queue
Network Protocols:
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB- II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP
Application Programming Interface:
Open API for software integration, including VAPIX®, metadata and AXIS Camera Application Platform (ACAP); specifications at axis.com/developer- community . One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF®
Video Management Systems:
Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5, and video management software from Axis’ partners available at axis.com/vms .
Onscreen Controls:
Autofocus Day/night shift Defog Wide dynamic range Video streaming indicator IR illumination Privacy masks Media clip Heater
Event Conditions Device Status:
above/below/within operating temperature, casing open, IP address blocked/removed, live stream active, network lost, new IP address, system ready
Event Conditions Edge Storage:
recording ongoing, storage disruption, storage health issues detected
Event Conditions I/O:
digital input, manual trigger, virtual input
Event Conditions MQTT:
stateless
Scheduled And Recurring:
schedule
Event Conditions Video:
average bitrate degradation, day-night mode, tampering
Event Actions Defog:
Set Defog mode, set Defog mode while the rule is active
Event Actions I/O:
toggle I/O once, toggle I/O while the rule is active
Event Actions Illumination:
use lights, use lights while the rule is active
Event Actions LEDs:
flash status LED, flash status LED while the rule is active
Event Actions MQTT:
publish
Event Actions Notification:
HTTP, HTTPS, TCP and email Overlay text
Event Actions Recordings:
SD card and network share
Event Actions Security:
erase configuration
Event Actions SNMP Traps:
send, send while the rule is active
Images Or Video Clips:
FTP, SFTP, HTTP, HTTPS, network share and email WDR mode
Built-in Installation Aids:
Pixel counter, remote zoom and focus, straighten image, level grid
Included:
AXIS Object Analytics, AXIS Image Health Analytics, AXIS Audio Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection
Supported:
AXIS Perimeter Defender, AXIS License Plate Verifier Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/ acap
Image Degradation:
blurred image, underexposed image
AXIS Scene Metadata Object Classes:
humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates
Object Attributes:
vehicle color, upper/lower clothing color, bag, confidence, position
AXIS Live Privacy Shield Object Classes:
Humans, (entire body or face only), license plates, backgrounds
Product Markings:
UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC
Supply Chain:
TAA compliant
Australia/New Zealand:
RCM AS/NZS CISPR 32 Class A
EMC Canada:
ICES(A)/NMB(A)
EMC Japan:
VCCI Class A
EMC Korea:
KS C 9835, KS C 9832 Class A
EMC USA:
FCC Part 15 Subpart B Class A
EMC Railway:
IEC 62236-4
Safety:
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, IEC/EN 62471 risk group exempt
Cybersecurity:
ETSI EN 303 645, BSI IT Security Label, FIPS 140
Edge Security Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 Client Credential Flow/OpenID Authorization Code Flow for centralized ADFS account management, password protection, Axis Cryptographic Module (FIPS 140-2 level 1)
Edge Security Hardware:
Axis Edge Vault cybersecurity platform
Network Security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2) , IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS , TLS v1.2/v1.3 , Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/ cybersecurity/resources To read more about Axis cybersecurity suppor
Casing Color:
white NCS S 1002-B For repainting instructions, go to the product’s support page. For information about the impact on warranty, go to axis.com/warranty-implication-when-repainting . This product can be repainted.
Environmental Sensors:
Environmental sensors through portcast technology accessories. For more information, see Optional accessories .
I/O Functionality I/O:
Terminal block for one configurable supervised input/digital output (12 V DC output, max load 25 mA)
Connectors Network:
RJ45 10BASE-T/100BASE-TX PoE
Connectors I/O:
4-pin 2.5 mm terminal block for 1 alarm input and 1 output
IR Illumination:
OptimizedIR with power-efficient, long-life 850 nm IR LEDs 10 mm lens: Range of reach 40 m (130 ft) or more depending on the scene 29 mm lens: Range of reach 45 m (148 ft) or more depending on the scene
Start-up Temperature:
-30 °C (-22 °F)
Operating Conditions Humidity:
10–100% RH (condensing)
Storage Conditions Temperature:
-40 °C to 65 °C (-40 °F to 149 °F)
Storage Conditions Humidity:
5–95% RH (non-condensing)
Effective Projected Area (epa:
0.023 m (0.075 ft )
Dimensions:
For the overall product dimensions, see the dimension drawing in this datasheet.
Weight:
10 mm lens: 850 g (1.9 lb) 29mm lens: 860 g (1.9 lb)
Box Content:
Camera, weathershield, installation guide, terminal block connector, connector guard, cable gasket, owner authentication key
System Tools:
AXIS Site Designer, AXIS Device Manager, product selector, accessory selector, lens calculator Available at axis.com
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Part Numbers:
Available at axis.com/products/axis-p3285-lve#part- numbers
Substance Control:
PVC free, BFR/CFR free in accordance with JEDEC/ECA Standard JS709 RoHS in accordance with EU RoHS Directive 2011/65/ EU and 2015/863, and standard EN IEC 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Renewable Carbon-based Plastic Content:
45% (bio- based: 43%, carbon capture based: 2%) Screened for conflict minerals in accordance with OECD guidelines To read more about sustainability at Axis, go to axis. com/about-axis/sustainability
Environmental Responsibility:
axis.com/environmental-responsibility Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
DORI Detect:
DORI definition: 25 px/m (8 px/ft); Distance (wide): 149 m (489 ft); Distance (tele): 394 m (1292 ft); DORI definition: 25 px/m (8 px/ft); Distance (wide): 48 m (157 ft); Distance (tele): 135 m (443 ft)
DORI Observe:
DORI definition: 63 px/m (19 px/ft); Distance (wide): 19 m (62 ft); Distance (tele): 54 m (177 ft); DORI definition: 63 px/m (19 px/ft); Distance (wide): 59 m (194 ft); Distance (tele): 157 m (515 ft)
DORI Recognize:
DORI definition: 125 px/m (38 px/ft); Distance (wide): 30 m (98 ft); Distance (tele): 79 m (259 ft); DORI definition: 125 px/m (38 px/ft); Distance (wide): 9.6 m (31.5 ft); Distance (tele): 27 m (89 ft)
DORI Identify:
DORI definition: 250 px/m (76 px/ft); Distance (wide): 15 m (49 ft); Distance (tele): 39 m (128 ft); DORI definition: 250 px/m (76 px/ft); Distance (wide): 4.8 m (15.7 ft); Distance (tele): 14 m (46 ft)
Camera Resolution:
2 MP
Lens Focal Length:
10.8-28.2 mm
Video Codecs:
AV1/H.264/H.265
Ingress Protection:
IP66
Impact Protection:
IK10
Power Over Ethernet:
IEEE 802.3af/802.3at Type 1 Class 3
Shipping Weight:
2.660 lb
Mounting Type:
Dome
Input/Output:
Supervised digital input and output
Security Features:
Axis Edge Vault, FIPS 140-3 level 3
Storage Media:
SD card
Country of Origin:
Poland
UNSPSC:
46171610
