Switch Modules
Showing Results for Switch Modules
-
ACTi
SKU: 2POE-SWC
ACTi 2 Port POE Switch Card - 2POE-SWC
- Adds PoE 802.3af power to two camera drops without a dedicated PSU at each endpoint.
- Inline injector design enables PoE retrofits on existing non-PoE network infrastructure.
- Compatible with ONVIF-compliant IP cameras and ACTi camera lines via standard RJ-45.
$125.00 $124.99 Save $0.01The item has been added -
Altronix
SKU: EBRIDGE100TM
Altronix EBRIDGE100TM Ethernet over coax/CAT5e Transceiver.
PoE transceiver for Ethernet over existing coax and CAT5e runs
- Single Ethernet output converts coax or CAT5e to standard network connection
- PoE powered—no separate power supply required for retrofit installations
- UL Listed for code-compliant security system upgrades without new cabling
$297.83 $159.99 Save $137.84The item has been added -
Add to Cart The item has been addedAltronix
SKU: EBRIDGE1CT
Altronix EBRIDGE1CT Ethernet over Coax Transceiver
Ethernet over coax transceiver for IP camera retrofit on legacy cabling
- Converts Ethernet signals over single coaxial cable—no new wiring needed
- Accepts 12/24VDC or 16/24VAC power for flexible on-site integration
- UL Listed and CE Approved for commercial security deployments
In stock · Ships same business day$228.31 $121.99 Save $106.32The item has been added -
Altronix
SKU: EBRIDGE1PCT
Altronix EBRIDGE1PCT Single-Port EoC Transceiver
Single-port PoE injector extends network 500m over existing coax cable
- Ethernet over Coax transmission eliminates need for new network cabling
- 500-meter range with PoE injection for remote cameras and access control
- UL Listed single-port transceiver for legacy CCTV infrastructure retrofit
$274.03 $146.99 Save $127.04The item has been added -
Add to Cart The item has been addedAltronix
SKU: EBRIDGE1PCTX
Altronix EBRIDGE1PCTX EoC Transceiver 25Mbps
Extend PoE & IP over coax to 500m at 25 Mbps
- 25 Mbps throughput over existing coaxial cable infrastructure
- PoE+ powered operation—no separate AC power required
- Single Ethernet output, UL Listed, rated to 500 meters
In stock · Ships same business day$274.03 $146.99 Save $127.04The item has been added -
Altronix
SKU: HUBWAY162DI
Altronix HUBWAY162DI 16-Port UTP Transceiver Hub
16-output hub for mid-scale security power distribution
- 16 independent outputs with centralized 28VAC management
- Compact rack or wall-mount form factor reduces installation complexity
- Altronix Hubway ecosystem integration for distributed device support
$2,420.59 $1,462.99 Save $957.60The item has been added -
Altronix
SKU: HUBWAY163CD
Altronix HUBWAY163CD 16-Port UTP Transceiver Hub
16-port managed switch for IP security cameras and access control
- 16 Ethernet ports with managed architecture for VLAN segmentation
- 24VAC input with PoE support for distributed camera deployments
- UTP transceiver hub design compatible with standard Ethernet cabling
$2,538.01 $1,393.99 Save $1,144.02The item has been added -
Altronix
SKU: HUBWAY163D
Altronix HUBWAY163D 16-Channel Passive UTP Transceiver Hub
16-channel UTP hub, 750 ft video runs, selectable 24/28VAC power
- 16 video channels over CAT-5 cabling up to 750 feet per channel
- Individually selectable 24VAC or 28VAC outputs, 1A max per channel
- RS422/RS485 control data and surge suppression on each channel
$2,538.01 $1,393.99 Save $1,144.02The item has been added -
Altronix
SKU: HUBWAY163DI
Altronix HUBWAY163DI 16 Channel Passive UTP Transceiver Hub
16-port PoE hub for centralized IP camera and access control power
- 16 simultaneous 802.3af/at PoE ports on single DIN-rail unit
- Centralized power injection cuts installation labor vs. individual supplies
- Transparent network operation with no latency or packet loss
$2,905.20 $1,594.99 Save $1,310.21The item has been added -
Altronix
SKU: HUBWAY16D
Altronix HUBWAY16D 16-Channel Passive UTP Transceiver Hub
16-channel passive hub with 750ft UTP video reach and integrated power
- 16 channels of passive video distribution over standard UTP cabling
- Extends video signals up to 750 feet without active repeaters
- Built-in 24/28VAC power supply (115/220VAC input) in 1U rackmount
$1,748.50 $959.99 Save $788.51The item has been added -
Altronix
SKU: HUBWAY16DI
Altronix HUBWAY16DI 16-Channel UTP Transceiver Hub
16-channel UTP hub extends video 750 feet over Cat5e/6 cabling
- 16 passive transceiver pairs terminate and regenerate video signals
- Isolated 24/28VAC supply eliminates ground-loop hum in analog chains
- 1U rack mount with dual 115/220VAC input for global deployment
$2,115.72 $1,161.99 Save $953.73The item has been added -
Altronix
SKU: HUBWAY82CDS
Altronix HUBWAY82CDS 8-Channel Passive UTP Transceiver Hub
8-channel PoE hub with individual output supervision for distributed security
- Eight independently supervised outputs enable real-time per-port fault detection.
- Wall and rack mount options simplify cabinet, pole, or surface installation.
- Lifetime warranty backs unattended indoor and outdoor field deployments.
$1,174.26 $644.99 Save $529.27The item has been added -
Altronix
SKU: HUBWAY83CD
Altronix HUBWAY83CD 8 Channel Passive UTP Transceiver Hub
8-port PoE injector for IP cameras and access control over extended runs
- 8 channels with simultaneous power and data injection via 802.3af/at
- Compact wall-mount or rack form factor fits control rooms and equipment shelters
- Operates across wide temperature range for indoor and outdoor deployments
$1,307.62 $717.99 Save $589.63The item has been added -
Altronix
SKU: HUBWAY83CDS
Altronix HUBWAY83CDS 8 Channel Passive UTP Transceiver Hub
8-channel passive UTP hub for IP security system distribution
- 8 channels for network video and data distribution in security deployments
- Passive UTP transceiver architecture requires no external power supply
- Hub and distribution module design integrates with Altronix security platforms
$1,181.18 $713.99 Save $467.19The item has been added -
Altronix
SKU: HUBWAY83D
Altronix HUBWAY83D 8-Channel Passive UTP Transceiver Hub
85-channel PoE++ hub for large-scale IP camera deployments
- 85 PoE++ outputs on single 19-inch rack-mount unit
- Wired Ethernet connectivity eliminates wireless latency and interference
- UL Listed for commercial and institutional security installations
$1,307.62 $717.99 Save $589.63The item has been added -
Altronix
SKU: HUBWAY83DI
Altronix HUBWAY83DI 8 Channel Passive UTP Transceiver Hub
8-channel passive UTP hub for legacy system support and documentation
- 8 passive UTP transceiver channels on single hub/repeater unit
- Discontinued model—replaced by Hubway8DI for new installations
- Does not include HubwayDV Baluns; verify compatibility before ordering
$1,491.23 $818.99 Save $672.24The item has been added
Switch Modules
Switch modules expand network switch capability by adding uplink options, fiber connectivity, and modular expansion ports. Select compatible SFP transceivers and switch modules to match your switch hardware, fiber type, and distance requirements.
Plan Your Deployment
- Switch model compatibility and supported module types
- Fiber type selection (single-mode vs multi-mode)
- Distance requirements and transceiver range
- Uplink speed requirements (1G, 10G, etc.)
- Network design and redundancy planning
Switch Modules — Engineering-Grade Network Infrastructure for Commercial Deployments
This category covers 196 working models of switch modules sourced manufacturer-direct or through channel-direct US distribution. Build the rest of your system around the architectural choices below — compatibility, environmental rating, and lifecycle decisions made here propagate through every downstream component you specify.
What to Look For
Port count and PoE budget come first. An 8-camera install needs at least 9 ports (cameras + uplink), with PoE budget covering the sum of per-camera PoE class. Account for uplink speed: 1 Gbps uplinks bottleneck under heavy video load on switches with 8+ high-resolution cameras. SFP+ or 10 Gbps uplinks remove that bottleneck on growing sites.
Managed versus unmanaged switches affect troubleshooting and VLAN segmentation. Managed switches (HPE Aruba, Cisco, Netgear ProSAFE M-series) support VLANs, link-aggregation, port mirroring, and SNMP monitoring — essential for any deployment over 16 cameras or with mixed traffic. Unmanaged switches work for small isolated camera networks but limit growth and troubleshooting visibility.
Layer 3 capability (routing, VLAN inter-VLAN routing) becomes important when surveillance, access control, and corporate traffic share the same physical network. Surveillance VLAN isolation is now standard practice — segregate camera traffic from corporate Wi-Fi and guest networks to prevent broadcast storms and lateral attack paths. Confirm the switch supports the VLAN count and ACL complexity you need.
Outdoor/industrial deployments need ruggedized switches. ComNet, Antaira, and Moxa make hardened switches rated for -40°C to +75°C, vibration, and waterproof housings. DIN-rail mounting fits standard outdoor enclosures. Standard data-closet switches in outdoor enclosures fail within 1-2 years from condensation and temperature swings; spec the right environment rating up front.
Key Specs in This Category
| Spec | Available Options |
|---|---|
| Connectivity | Wired |
| Type | Switch, Accessory, Media Converter, Power Supply, 4x T1/E1 ION Module, PoE Injector, 6 Slot AC ION Chassis, 19-Slot AC ION Chassis |
Top Brands in This Category
Frequently Asked Questions
What's the difference between managed and unmanaged PoE switches?
Unmanaged switches power-on and forward traffic without configuration — simplest deployment but no VLAN, no monitoring, no troubleshooting visibility. Managed switches add VLANs, link-aggregation, port mirroring, SNMP, and remote-management interfaces. For deployments above 16 cameras or those sharing infrastructure with other systems, managed is the right choice; the per-port cost is modest and the operational benefit is large.
How much PoE budget should I size for?
Sum the PoE-class budget of all PoE-powered devices, then add 20-30% headroom for growth. Eight 802.3at cameras at 30W max each is 240W minimum — but a 130W-budget 8-port PoE+ switch can't deliver that. Confirm both per-port budget and total PoE budget; many entry-level switches advertise PoE+ ports but cap aggregate budget at half the per-port maximum.
Do I need 10 Gbps uplinks?
For installations under 32 cameras with mid-resolution streams, 1 Gbps uplinks suffice. Above that, or when you need fast investigative playback for many simultaneous reviewers, 10 Gbps (SFP+) uplinks remove the choke point. NVRs writing to NAS over the network also benefit. SFP+ has become reasonably affordable on managed switches; opt for it on new installs over 16 cameras.
Can I run VoIP and video on the same switch?
Yes — modern managed switches use VLAN segregation to keep VoIP, video, and data traffic separated even on shared physical ports. Use QoS (Quality of Service) to prioritize VoIP for low latency and assign video its own queue. Avoid mixing untagged traffic types on a single switch port without VLAN configuration; broadcast storms and bandwidth competition cause both voice and video quality issues.
What's the right uplink between buildings on a campus?
Single-mode fiber for runs over 100 m, multi-mode for shorter runs (typically up to 550 m on OM3, 300 m on OM4 at 10 Gbps). Bidirectional SFPs (single fiber instead of pair) save fiber count when the run is already deployed. Avoid copper between buildings — ground-potential differences during lightning strikes destroy switch SFP modules even when surge-protected.
