Altronix NETWAYSP8X 8-Port PoE Switch with Dual Fiber SFP
Overview
The Altronix NETWAYSP8X is a hardened managed PoE switch purpose-built for security integrators deploying mid-scale video surveillance, access control, and IP intercom systems. This unit consolidates network distribution and power delivery into a single industrial-grade chassis, eliminating the need for separate PoE injectors and reducing both installation footprint and maintenance complexity. The combination of 8 copper/fiber ports and a 120W integrated power supply with battery charging capability makes the NETWAYSP8X well-suited to distributed security architectures where both network resilience and reliable power are non-negotiable.
Key Features
- Dual 1G Fiber SFP Ports: Gigabit fiber connectivity extends backbone runs beyond the 300-foot copper limitation without signal degradation and eliminates susceptibility to electromagnetic interference—critical in industrial warehouses, manufacturing facilities, or any site with high-frequency equipment, VFDs, or welding operations that would corrupt copper signals.
- 8 Total Network Ports with Configurable PoE Architecture: The NETWAYSP8X supports 2×60W Hi-PoE ports for PTZ cameras or powered turrets plus 6×10/100 PoE/PoE+ ports for standard endpoints. This port segmentation lets you prioritize power-hungry devices without undersizing the entire switch—a real practical constraint when budgeting 802.3at or 802.3bt capacity across a mixed deployment.
- 120W Integrated Power Supply: Hardened AC supply with universal input (110–240V) and battery charging connectors for seamless integration with external UPS modules. This design means you provision one power cord and one battery backup unit instead of managing separate injector supplies—fewer single points of failure and simpler sparing logistics.
- Managed Switch with LINQ Integration: Built-in management interface compatible with Altronix surveillance infrastructure for centralized configuration, monitoring, and firmware updates across distributed edge deployments. Reduces on-site troubleshooting time and improves visibility into network health.
- Industrial BC300 Enclosure: Metal chassis with thermal design rated for continuous operation indoors without external cooling. Wall- or rack-mount form factor fits standard integration cabinets and control rooms.
- Standard SFP Transceiver Support: Accepts off-the-shelf SFP modules, allowing you to choose fiber types (multimode, single-mode) and distances based on actual site topology rather than being locked into a proprietary module ecosystem.
- Mixed Gigabit and Fast Ethernet Ports: Combination of port speeds optimizes bandwidth allocation—Gigabit uplinks for backbone camera streams, Fast Ethernet for access control readers or intercoms that don't require high throughput.
Integration & Compatibility
The NETWAYSP8X integrates directly with LINQ-compatible Altronix devices and accepts standard CAT5e/CAT6 cabling on copper ports. Battery backup integration requires an external charger and battery module; the 120W supply is designed to float charge a connected UPS during normal operation and hand off seamlessly to battery power during AC loss. This architecture is standard in security-focused power infrastructure and works with most 12VDC or 24VDC external battery systems. Verify your battery module voltage and connector type before ordering—mismatches are silent and discovered only during an actual power failure.
Deployment Considerations
Before deployment, calculate total PoE power draw across all planned endpoints. The 60W Hi-PoE ports are dedicated—they cannot be reconfigured to standard PoE+, so assign only the devices that truly require 60W (most PTZs, some powered turrets) to these ports. Standard PoE/PoE+ ports share the remaining 60W of the 120W budget; oversubscription here will cause port shutdown or brownout during peak demand. Fiber uplinks are strongly recommended for distances beyond 300 feet or in environments with significant electrical noise; copper runs in such conditions are a common source of intermittent frame loss and difficult-to-diagnose network instability. The BC300 chassis supports both wall and rack mounting; verify your rack depth clearance if mounting in a vertical orientation. Thermal design is passive for typical indoor ambient conditions (roughly 50–77°F); confirm adequate ventilation if mounting in a confined space or unair-conditioned closet.
Frequently Asked Questions
Q: Can the NETWAYSP8X supply power to more than 8 devices?
A: No. The NETWAYSP8X has exactly 8 network ports total (2 fiber SFP uplinks plus 6 copper ports). If you need more endpoint connections, you must cascade additional switches or use a larger Altronix model in the NETWAY series.
Q: What is the maximum fiber distance supported over the SFP ports?
A: Standard multimode SFP transceivers typically support 300–550 meters depending on fiber grade and transceiver specification. Single-mode SFP modules extend range to 10+ kilometers. Verify your chosen transceiver datasheet—the switch itself does not limit fiber distance.
Q: Does the NETWAYSP8X require external DC power conversion or only AC input?
A: The 120W power supply is AC-input only and outputs 12VDC or 24VDC on the battery charging connectors. If your site runs DC-only infrastructure, you will need a separate AC-to-DC conversion stage upstream.
Q: Can I use the NETWAYSP8X in an outdoor cabinet?
A: The BC300 enclosure is rated for indoor deployment only. For outdoor or semi-outdoor use, you will need an additional weatherproof cabinet or consider an outdoor-rated power distribution unit in the Altronix industrial line.
Q: What is the warranty coverage on the NETWAYSP8X?
A: Refer to the manufacturer's warranty documentation or contact your distributor for the specific coverage terms and claim process.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The NETWAYSP8X solves a real problem in mid-scale security deployments: the sprawl of separate PoE injectors and power supplies. By consolidating 120W of managed PoE and dual 1G fiber uplinks into one hardened BC300 chassis, you eliminate clutter, reduce wiring failures, and simplify battery backup integration. If you're designing a warehouse automation or distributed access control network, this is worth a serious look—especially where long-distance fiber runs or high-EMI environments make copper unreliable.
Technical Highlights:
- 2×60W Hi-PoE ports: Supports two simultaneous high-power devices (PTZ cameras, powered turrets) without sharing a power budget with other ports—no brown-out or port-cycling surprises during peak demand.
- Dual 1G SFP fiber uplinks: Eliminates the 300-foot copper limitation and immunity to EMI. Industrial sites with VFDs, welding equipment, or long backbone runs get clean, noise-free connectivity without expensive shielded cable runs.
- 120W integrated supply with battery charging: One AC cord, one external battery module. Standard 12/24VDC output plays well with existing Altronix UPS ecosystems and most enterprise backup systems—simpler commissioning, fewer voltage mismatches at deployment time.
Deployment Considerations:
- Calculate endpoint power budgets carefully: 60W Hi-PoE ports are fixed-function; if you assign a low-power device to a 60W port, you're burning unused capacity. Plan endpoint assignments during design phase to avoid mid-project reconfiguration.
- Fiber SFP transceivers are not included—you supply your own based on distance and fiber type. This is a flexibility win (choose single-mode for 10+ km runs, multimode for <1 km at lower cost) but requires upfront homework on fiber distances and connector types.
- Battery backup is external: the switch itself does not store power. You must provision an external charger module and battery pack (12VDC or 24VDC, per your site standard) and verify connector compatibility before installation.
The NETWAYSP8X is the right choice for a distributed warehouse, multi-building campus, or manufacturing facility where you need managed PoE, fiber backbone reach, and genuine power redundancy without overengineering into a full NVR appliance. Pass on it if your entire site fits in one cabinet or if you need more than 8 total endpoints—cascade to a larger NETWAY model instead.
