Altronix NETWAYSP8LWPX Dual Fiber PoE Switch with Integrated Power and Battery Backup
Overview
The Altronix NETWAYSP8LWPX is a hardened outdoor PoE switch designed for distributed security and telecom deployments requiring fiber connectivity, extended power delivery, and environmental protection. This integrated platform combines dual 1G fiber SFP ports with eight copper Ethernet ports capable of delivering PoE and PoE+ power, all mounted in a NEMA 4/4X IP66-rated outdoor enclosure. The NETWAYSP8LWPX consolidates switching, power conversion, battery charging, and environmental sealing into a single ruggedized system, eliminating the need for separate component procurement and reducing field installation complexity.
Key Features
- Dual 1G Fiber SFP Ports: Supports long-distance, noise-immune fiber connectivity for remote locations and campus deployments
- 8 Copper Network Ports: Configuration options include 2×60W Hi-PoE ports plus 6 standard 10/100 PoE/PoE+ ports for mixed device requirements
- 10/100/1000 Mbps Copper Connectivity: Full gigabit support on PoE-capable ports for high-bandwidth camera and access control feeds
- 75W Hardened Power Supply: Integrated AC/DC power conversion optimized for outdoor and unattended operation
- LiFePO4 Battery Charger: Built-in intelligent charging circuit supports lithium iron phosphate batteries for extended system runtime during mains failure
- Configurable PoE Budget: Supports up to 2×60W Hi-PoE outputs for thermal imaging, LED illumination, and high-current auxiliary devices, with remaining ports delivering standard PoE/PoE+ (30W/95W)
- NEMA 4/4X IP66 Enclosure: Sealed outdoor cabinet rated for severe weather, salt spray, and dust ingress; suitable for rooftop, ground-level, and pole-mount installations
- Switch and Power Board Architecture: Factory-mounted Ethernet switch and power management boards eliminate field assembly and reduce commissioning time
- LINQ Integration: Compatible with LINQ management and monitoring platform for centralized system oversight
Integration & Compatibility
The NETWAYSP8LWPX connects to remote network segments via 1G fiber SFP transceivers, providing immunity from electromagnetic interference in industrial and RF-dense environments. The dual fiber ports enable redundant paths or aggregated bandwidth for critical backbone links. Copper ports support standard IP camera, access control, and PoE-powered auxiliary device protocols. The integrated battery charger accommodates field-replaceable LiFePO4 cells, extending system uptime without external UPS equipment. LINQ compatibility enables remote configuration, power monitoring, and port status reporting from a centralized management interface.
Power and Environmental Specifications
Input AC voltage and current ratings, along with detailed LiFePO4 charging profiles and DC output specifications, should be verified in the product datasheet. The unit's 75W power budget must be allocated across all active ports; Hi-PoE ports consume 60W each, leaving remaining capacity for lower-power PoE devices. The NEMA 4/4X IP66 enclosure provides full protection against water jets and temporary submersion, suitable for outdoor cable runs and exposed mounting locations. Operating temperature range and humidity specifications ensure stable performance in extreme climates.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Altronix NETWAYSP8LWPX represents a practical consolidation of fiber switching, PoE distribution, and backup power in a single outdoor-rated platform. During field deployment planning, this unit eliminates the complexity of coordinating separate fiber switches, PoE injectors, and external power supplies—reducing spares inventory and simplifying troubleshooting.
Technical Highlights:
- Fiber SFP Connectivity: Dual 1G ports enable long-distance, interference-free backbone links to remote camera arrays or distributed access control nodes
- Dual Hi-PoE Capability: Configurable 2×60W outputs support thermal imaging cameras and auxiliary power loads that exceed standard PoE limits
- Integrated LiFePO4 Charging: Factory-installed charging circuit optimized for lithium batteries eliminates need for external chargers and reduces DC power distribution complexity
- Sealed Enclosure Design: NEMA 4/4X IP66 construction eliminates environmental concerns for rooftop, utility pole, or exposed ground-level installations
Deployment Considerations:
- Verify fiber optic SFP transceiver compatibility and wavelength requirements with your backbone network before procurement
- Plan power budget allocation carefully—2×60W Hi-PoE ports consume 120W of the 75W total supply, requiring external auxiliary power or battery support for simultaneous operation
- Confirm LiFePO4 battery cell compatibility and charging voltage/current profiles before field installation
- Integrate LINQ management credentials and monitoring thresholds during pre-deployment configuration to enable proactive power and link-status alerts
The NETWAYSP8LWPX is well-suited for security and telecom integrators managing distributed outdoor sites where fiber backbone connectivity, extended PoE delivery, and harsh environmental conditions intersect. The factory-mounted board assembly and IP66 sealing reduce field assembly risk and accelerate project timelines.
