APC by Schneider Electric SRT10KXLT30 vs Vertiv GXT5-10KHVRT5UXLN: Specification Comparison
Both the APC Smart-UPS On-Line SRT10KXLT30 and the Vertiv GXT5-10KHVRT5UXLN are 10 kVA / 10 kW double-conversion online UPS units targeting data centers, server rooms, and critical infrastructure environments. Both deliver true online double-conversion topology, sine-wave output, and rack-mountable form factors at the same power class. This comparison evaluates their power and efficiency profiles, physical and environmental characteristics, and management and interface capabilities to help installers and IT buyers select the right unit for their deployment.
In This Guide
- Which UPS delivers better efficiency and output flexibility for your load?
- What are the physical footprint and environmental operating limits of each unit?
- Which unit offers more comprehensive management and connectivity options?
- Which should you choose: the SRT10KXLT30 or the GXT5-10KHVRT5UXLN?
- Side-by-Side Specs
- FAQ
Which UPS delivers better efficiency and output flexibility for your load?
Both units are rated at 10,000 VA / 10,000 W, confirming a unity power factor for the Vertiv GXT5-10KHVRT5UXLN and the same 1.0 power factor for the APC SRT10KXLT30 (10 kW from 10 kVA). On efficiency, the specs diverge meaningfully: the SRT10KXLT30 is rated at 94.5% in online mode, while the GXT5-10KHVRT5UXLN reaches up to 95% in online mode and up to 98% in Active ECO Mode. Higher efficiency translates directly to lower heat dissipation and reduced operating cost over the unit's lifetime.
Output voltage flexibility also differs. The SRT10KXLT30 specifies an output range of 208–240 V. The GXT5-10KHVRT5UXLN offers user-configurable output at 200, 208, 220, 230, or 240 VAC, which simplifies international deployments or mixed-voltage environments without requiring additional step-down equipment. The SRT10KXLT30 provides Automatic Voltage Regulation (AVR) and a wide input operating range of 100–275 V with 40–70 Hz frequency acceptance, making it tolerant of highly variable utility power. The GXT5-10KHVRT5UXLN's input range is specified as 176–288 VAC typical at 208 VAC input; its frequency acceptance range is not stated in the provided specs.
What are the physical footprint and environmental operating limits of each unit?
Physical dimensions and weight are fully specified only for the Vertiv GXT5-10KHVRT5UXLN: 8.5 in H × 16.9 in W × 24.8 in D, weighing 166.4 lbs. The GXT5-10KHVRT5UXLN occupies a 5U rack space per its model designation. No weight or dimensional data is provided in the supplied specifications for the APC SRT10KXLT30, which limits direct rack-space and floor-load planning for that unit.
Operating temperature is specified only for the GXT5-10KHVRT5UXLN: +32 to +104 °F (0 to 40 °C), which is standard for data center and server room environments. The SRT10KXLT30 specifications provided do not include an operating temperature range, storage temperature, or humidity rating. The SRT10KXLT30 does specify an audible noise level of 55 dB, a figure absent from the GXT5-10KHVRT5UXLN specs. The GXT5-10KHVRT5UXLN carries ENERGY STAR 2.0, UL1778, c-UL, RoHS2, and REACH certifications; certifications for the SRT10KXLT30 are not listed in the provided specs.
Which unit offers more comprehensive management and connectivity options?
The Vertiv GXT5-10KHVRT5UXLN ships with a factory pre-installed Liebert IntelliSlot RDU120 SNMP/Webcard, enabling SNMP and web-based management out of the box without additional cards or licenses. Additional interfaces include USB, RS485, RS232, a terminal block, and an external battery connector. A full-color graphic LCD with gravity-sensing orientation rounds out local visibility. The wiring configuration is hardwired input and output, supplemented by two L6-20R and two L6-30R receptacles.
The APC SRT10KXLT30 lists an 'Interface Port Cont' in its product name and specifies Emergency Power Off (EPO) support, surge protection rated at 480 J, and a surge energy rating. However, the supplied specifications do not enumerate specific interface ports, network management card options, display type, or outlet configurations. Buyers requiring detailed connectivity planning for the SRT10KXLT30 will need to consult the full APC datasheet. The GXT5-10KHVRT5UXLN's out-of-box SNMP management is a concrete, documentable advantage for IT teams requiring immediate remote monitoring without additional procurement.
Which should you choose: the SRT10KXLT30 or the GXT5-10KHVRT5UXLN?
Our take: The GXT5-10KHVRT5UXLN is the stronger choice when out-of-box management capability, higher efficiency, and fully documented physical specs are the primary requirements. On efficiency, the Vertiv reaches up to 98% in ECO mode versus 94.5% for the APC — a 3.5-percentage-point gap that compounds over continuous operation. The Vertiv's user-configurable output (200–240 VAC in five steps) exceeds the APC's 208–240 V range, adding deployment flexibility. The Vertiv also ships with a factory-installed SNMP/Webcard, USB, RS485, and RS232 interfaces, whereas the APC's interface details are not enumerated in the provided specs. Conversely, the SRT10KXLT30's wider input voltage tolerance (100–275 V) and broader frequency acceptance (40–70 Hz) may favor installations on unstable or international utility feeds. Buyers in environments with highly variable input power should verify the GXT5's frequency acceptance range against their site conditions before deciding.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | APC by Schneider Electric SRT10KXLT30 | Vertiv GXT5-10KHVRT5UXLN |
|---|---|---|
| UPS Topology | Double-conversion (Online) | On-line double conversion |
| Power Rating (VA) | 10,000 VA | 10,000 VA |
| Power Rating (W) | 10,000 W | 10,000 W |
| Power Factor | 1.0 (10 kW / 10 kVA) | 1.0 (10,000 W / 10,000 VA) |
| Efficiency (Online Mode) | 94.5% | Up to 95% |
| Efficiency (ECO / High-Eff. Mode) | — | Up to 98% (Active ECO Mode) |
| Input Voltage Range | 100–275 V | 176–288 VAC (typical 208 VAC) |
| Input Frequency | 40–70 Hz | — |
| Output Voltage | 208–240 V | 200/208/220/230/240 VAC (user-configurable) |
| Output Frequency | 50/60 Hz | — |
| Output THD | 2% | — |
| Waveform | Sine | — |
| Surge Energy Rating | 480 J | — |
| AVR | Yes | — |
| EPO | Yes | — |
| Noise Level | 55 dB | — |
| Management Interfaces | — | SNMP/Webcard (factory), USB, RS485, RS232, terminal block |
| Display | — | Full-color graphic LCD (gravity-sensing) |
| Wiring / Outlets | — | Hardwired in/out; 2× L6-20R, 2× L6-30R |
| Certifications | — | ENERGY STAR 2.0, UL1778, c-UL, RoHS2, REACH |
| Operating Temperature | — | +32 to +104 °F (0 to 40 °C) |
| Weight | — | 166.4 lbs |
| Dimensions (H × W × D) | — | 8.5 in × 16.9 in × 24.8 in |
Frequently Asked Questions
Which should you choose: the SRT10KXLT30 or the GXT5-10KHVRT5UXLN?
The GXT5-10KHVRT5UXLN is the stronger choice when out-of-box management capability, higher efficiency, and fully documented physical specs are the primary requirements. On efficiency, the Vertiv reaches up to 98% in ECO mode versus 94.5% for the APC — a 3.5-percentage-point gap that compounds over continuous operation. The Vertiv's user-configurable output (200–240 VAC in five steps) exceeds the APC's 208–240 V range, adding deployment flexibility. The Vertiv also ships with a factory-installed SNMP/Webcard, USB, RS485, and RS232 interfaces, whereas the APC's interface details are not enumerated in the provided specs. Conversely, the SRT10KXLT30's wider input voltage tolerance (100–275 V) and broader frequency acceptance (40–70 Hz) may favor installations on unstable or international utility feeds. Buyers in environments with highly variable input power should verify the GXT5's frequency acceptance range against their site conditions before deciding.
Does either UPS include a network management card in the box?
Yes — the Vertiv GXT5-10KHVRT5UXLN includes a factory pre-installed Liebert IntelliSlot RDU120 SNMP/Webcard, enabling SNMP and web management without additional purchases. The provided specifications for the APC SRT10KXLT30 do not confirm whether a network management card is included or optional; consult APC's full datasheet for clarification.
Which unit is more efficient for reducing operating costs?
The Vertiv GXT5-10KHVRT5UXLN is rated up to 98% efficiency in Active ECO Mode and up to 95% in standard online mode. The APC SRT10KXLT30 is rated at 94.5% in online mode. No ECO or high-efficiency mode figure is provided for the APC unit in the supplied specs. The Vertiv's higher efficiency ceiling means less heat generated and lower electricity costs at sustained loads.
Which UPS is better suited to sites with unstable or wide-ranging utility power?
Based on the provided specs, the APC SRT10KXLT30 accepts input voltages from 100 V to 275 V and frequencies from 40 to 70 Hz, indicating broad tolerance for variable utility conditions. The Vertiv GXT5-10KHVRT5UXLN specifies a typical input of 208 VAC with a range of 176–288 VAC; its input frequency acceptance range is not stated in the provided specs. For sites with severely variable voltage or non-standard frequencies, the APC's documented wide input window is a verifiable advantage.
