Socket Mobile CX3535-2137 vs Socket Mobile CX4523-3764: Specification Comparison
Both the Socket Mobile CX3535-2137 SocketScan S740 and the CX4523-3764 are handheld Bluetooth barcode scanners targeting mobile workforce deployments. They share the same scan engine class (1D), identical symbology support spanning both 1D and 2D codes, the same operating temperature range, and the same 1-year warranty. The key decision axes are environmental durability, included accessories and battery specs, and platform compatibility—each of which points to meaningfully different deployment scenarios despite the surface-level similarity.
In This Guide
Which scanner handles the harsher deployment environment?
The CX4523-3764 carries an IP67 rating, meaning it is fully protected against dust ingress and can withstand temporary water immersion—making it the specified choice for washdown environments, outdoor fieldwork, or any setting where the device may be exposed to liquids or particulates. Its Environment Rating is listed as Outdoor.
The CX3535-2137 carries no IP rating in its specifications and is rated for Indoor environments only. Buyers placing units in warehouses with wet floors, food-service kitchens, or outdoor receiving docks should note this gap. Both units share the same operating temperature window of 0° to 45°C (32° to 113°F), so thermal range is not a differentiator.
How do battery capacity and included accessories differ between the two models?
The CX3535-2137 specifies a 2000mAh battery and ships with a charging stand included in the package. A charging stand enables overnight batch charging without a separate cradle purchase and allows the unit to remain docked when not in active use.
The CX4523-3764 does not list a battery capacity in the provided specifications—buyers requiring confirmed runtime figures will need to consult Socket Mobile directly. Its package contents include a protective case rather than a charging stand. The protective case aligns with its outdoor/rugged positioning, but a separate charging solution would need to be sourced.
Do the two scanners differ in platform compatibility or scan pattern?
Both scanners use Bluetooth connectivity and support identical symbologies: Code 128, Code 39, UPC, EAN (1D) plus QR Code and Data Matrix (2D). Neither is restricted to a proprietary protocol based on the provided specs.
The CX4523-3764 explicitly lists iOS 15 as a compatible operating system and specifies a single-line scan pattern. The CX3535-2137 does not list a specific OS or scan pattern in the provided specifications. If iOS 15 compatibility is a formal procurement requirement, the CX4523-3764 has it on record; the CX3535-2137's iOS support is not confirmed by the available spec data.
Which should you choose: the CX3535-2137 or the CX4523-3764?
Our take: The CX3535-2137 is the stronger choice when the deployment is primarily indoor and confirmed battery runtime plus an included charging stand are priorities. It specifies a 2000mAh battery and ships with a charging stand—concrete advantages for shift-based operations where units cycle through a charging dock overnight. The CX4523-3764 is the stronger choice for outdoor or wet-environment deployments: its IP67 rating is a categorical spec advantage the CX3535-2137 cannot match, and it ships with a protective case suited to field carry. The CX4523-3764 also has iOS 15 listed as a confirmed compatible OS, which matters for formal iOS fleet procurement; the CX3535-2137 does not state an OS. Battery capacity for the CX4523-3764 is unspecified, so runtime comparisons cannot be made from available data. Both units cover the same symbology set and share the same 1-year warranty and temperature range.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Socket Mobile CX3535-2137 | Socket Mobile CX4523-3764 |
|---|---|---|
| Product Type | Scanner | Scanner |
| Form Factor | Handheld | Handheld |
| Connectivity | Bluetooth | Bluetooth |
| Scan Engine | 1D | 1D |
| Scan Pattern | — | Single line |
| Symbologies 1D | Code 128; Code 39; UPC; EAN | Code 128; Code 39; UPC; EAN |
| Symbologies 2D | QR Code; Data Matrix | QR Code; Data Matrix |
| IP Rating | — | IP67 |
| Environment Rating | Indoor | Outdoor |
| Battery Capacity | 2000mAh | — |
| Operating Temperature | 0° to 45°C (32° to 113°F) | 0° to 45°C (32° to 113°F) |
| Compatible OS | — | iOS 15 |
| Package Contents | Scanner (Blue); Charging Stand | Scanner; Protective Case |
| Warranty | 1-year | 1-year |
Frequently Asked Questions
Which should you choose: the CX3535-2137 or the CX4523-3764?
The CX3535-2137 is the stronger choice when the deployment is primarily indoor and confirmed battery runtime plus an included charging stand are priorities. It specifies a 2000mAh battery and ships with a charging stand—concrete advantages for shift-based operations where units cycle through a charging dock overnight. The CX4523-3764 is the stronger choice for outdoor or wet-environment deployments: its IP67 rating is a categorical spec advantage the CX3535-2137 cannot match, and it ships with a protective case suited to field carry. The CX4523-3764 also has iOS 15 listed as a confirmed compatible OS, which matters for formal iOS fleet procurement; the CX3535-2137 does not state an OS. Battery capacity for the CX4523-3764 is unspecified, so runtime comparisons cannot be made from available data. Both units cover the same symbology set and share the same 1-year warranty and temperature range.
Can the CX4523-3764 survive a drop into a puddle or a hose-down on a loading dock?
Based on its specified IP67 rating, yes—IP67 certifies full dust protection and the ability to withstand water immersion up to 1 meter for 30 minutes under IEC 60529. The CX3535-2137 has no IP rating listed in its specifications, so water resistance cannot be assumed for that model.
Which scanner should I choose if my team uses iPhones running iOS 15?
The CX4523-3764 explicitly lists iOS 15 as a compatible operating system in its specifications. The CX3535-2137 does not list a specific compatible OS in the provided specs, so iOS 15 compatibility for that model cannot be confirmed from the available data.
Does either scanner come ready to charge out of the box without buying extra accessories?
The CX3535-2137 includes a charging stand in its listed package contents, so it arrives with a charging solution. The CX4523-3764 includes a protective case but no charging stand; a charging accessory would need to be sourced separately.
