Datalogic M3410-010210 vs Datalogic M3410-010200-00403: Specification Comparison
Both SKUs belong to the Datalogic Magellan 3410VSi family of vertical presentation scanners—compact 1D/2D area imagers designed for retail point-of-sale checkout counters. The M3410-010210 and M3410-010200-00403 share the same platform, form factor, and core imaging engine, making them directly cross-shoppable. The comparison focuses on the three dimensions most relevant to barcode scanner procurement: symbology coverage and scan capability, physical integration and environmental rating, and connectivity and interface options.
In This Guide
- Which scanner covers more barcode symbologies out of the box?
- Are the physical footprint, weight, and environmental ratings identical between these two models?
- Do both scanners offer the same interface options for POS system integration?
- Which should you choose: the M3410-010210 or the M3410-010200-00403?
- Side-by-Side Specs
- FAQ
Which scanner covers more barcode symbologies out of the box?
Both scanners decode the same 2D symbologies—QR Code, Data Matrix, and PDF417—and both are specified as 1D/2D area imagers. However, the M3410-010200-00403 explicitly lists Code 128, Code 39, UPC, and EAN as supported 1D symbologies in its spec data (fields _Symbologies_1D and _Symbologies). The M3410-010210 lists only '1D barcodes' as a category without enumerating specific 1D symbologies by name in its provided specifications.
For deployments where verifiable symbology coverage must be confirmed against a vendor specification document—such as pharmaceutical, grocery, or ticketing environments—the M3410-010200-00403 provides more explicit documentation of its 1D symbology set. The M3410-010210's specs do not contradict broad 1D coverage, but the named symbologies are absent from the provided data.
Are the physical footprint, weight, and environmental ratings identical between these two models?
The physical specifications are effectively identical across both units. Both measure 152 × 137 × 94 mm (6.0 × 5.4 × 3.7 inches) and weigh 350 g (0.77 lb). The encoded weight field (_weight) reads 1.32 on both units, and width, height, and depth fields are identical (5.39 × 5.98 × 3.7 inches) on both.
Both units carry an IP52 ingress protection rating, indicating protection against solid particle ingress of 5 mm or larger (dust-protected) and protection against vertically dripping water. Neither unit is rated for wash-down or outdoor exposure. The M3410-010200-00403 describes its presentation style as 'Vertical On-Counter' while the M3410-010210 uses 'Vertical'—a labeling difference, not a structural one. Both are listed with a Wall mount type in their form factor data.
Do both scanners offer the same interface options for POS system integration?
Both units list USB and RS-232 as their supported interfaces, enabling integration with modern USB-based POS terminals and legacy RS-232 serial systems. No additional interface types—such as Bluetooth, Wi-Fi, or keyboard wedge—are specified for either model in the provided data.
The M3410-010210 specifies connectivity as 'USB, RS-232' and the M3410-010200-00403 identically lists 'USB and RS-232.' Neither unit lists a preferred or default interface cable in the provided specs; buyers should confirm cable and power accessories separately. Both units are positioned as fixed-position presentation scanners, not handheld or cordless, which aligns with their stated form factors.
Which should you choose: the M3410-010210 or the M3410-010200-00403?
Our take: The M3410-010200-00403 is the stronger documented choice when a buyer requires explicit, named 1D symbology confirmation at the specification level. Its spec data enumerates Code 128, Code 39, UPC, and EAN by name, while the M3410-010210 lists only the category '1D barcodes' without naming individual symbologies. Beyond symbology documentation, the two units are effectively identical: both measure 152 × 137 × 94 mm, weigh 350 g, carry IP52 ratings, and offer USB plus RS-232 connectivity. The M3410-010210 may be preferable where procurement requires a simpler spec sheet or where the specific SKU is dictated by a Datalogic configuration option not reflected in the provided data. Buyers integrating into mixed-symbology retail environments—grocery, general merchandise, ticketing—should confirm full 1D coverage with Datalogic directly if choosing the M3410-010210, as its provided specs do not enumerate specific 1D codes.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Datalogic M3410-010210 | Datalogic M3410-010200-00403 |
|---|---|---|
| Series / Family | Magellan 3410VSi | Magellan 3410VSi |
| Product Type | Vertical Presentation Scanner | Vertical Presentation Scanner |
| Scan Engine | 2D Area Imager | 2D Area Imager |
| Scan Type | 1D/2D | 1D/2D |
| 2D Symbologies | QR Code, Data Matrix, PDF417 | QR Code, Data Matrix, PDF417 |
| 1D Symbologies (named) | — | Code 128, Code 39, UPC, EAN |
| Interface | USB, RS-232 | USB, RS-232 |
| Dimensions (mm) | 152 × 137 × 94 | 152 × 137 × 94 |
| Dimensions (in) | 6.0 × 5.4 × 3.7 | 6.0 × 5.4 × 3.7 |
| Weight | 350 g (0.77 lb) | 350 g (0.77 lb) |
| IP Rating | IP52 | IP52 |
| Presentation Style | Vertical | Vertical On-Counter |
| Form Factor | Vertical Presentation | Presentation / On-Counter Mount |
| Warranty | 3-Year Factory Warranty | 3-Year Factory Warranty |
| Datasheet | /content/product-datasheets/M3410-010210.pdf | /content/product-datasheets/M3410-010200-00403.pdf |
Frequently Asked Questions
Which should you choose: the M3410-010210 or the M3410-010200-00403?
The M3410-010200-00403 is the stronger documented choice when a buyer requires explicit, named 1D symbology confirmation at the specification level. Its spec data enumerates Code 128, Code 39, UPC, and EAN by name, while the M3410-010210 lists only the category '1D barcodes' without naming individual symbologies. Beyond symbology documentation, the two units are effectively identical: both measure 152 × 137 × 94 mm, weigh 350 g, carry IP52 ratings, and offer USB plus RS-232 connectivity. The M3410-010210 may be preferable where procurement requires a simpler spec sheet or where the specific SKU is dictated by a Datalogic configuration option not reflected in the provided data. Buyers integrating into mixed-symbology retail environments—grocery, general merchandise, ticketing—should confirm full 1D coverage with Datalogic directly if choosing the M3410-010210, as its provided specs do not enumerate specific 1D codes.
Is there any real difference in scanning capability between the M3410-010210 and M3410-010200-00403?
Based on the provided specifications, both use the same 2D area imager engine and decode the same 2D symbologies (QR Code, Data Matrix, PDF417). The M3410-010200-00403 additionally names Code 128, Code 39, UPC, and EAN in its spec data; the M3410-010210 references '1D barcodes' generically. Neither unit lists additional scan engine parameters (resolution, scan rate, or depth of field) in the provided data, so a full capability comparison beyond symbology listing is not possible from these specs alone.
Will either scanner fit the same counter cutout or mounting bracket as the other?
Yes—both units share identical physical dimensions (152 × 137 × 94 mm / 6.0 × 5.4 × 3.7 in) and weight (350 g / 0.77 lb) per the provided specifications. Both are listed with a Wall mount type. No bracket-specific part numbers or mounting hardware differences are noted in the provided data.
Can I use these scanners with both a modern USB POS terminal and a legacy RS-232 system?
Both the M3410-010210 and M3410-010200-00403 list USB and RS-232 as supported interfaces. No additional interfaces are specified. Whether a single unit supports both interfaces simultaneously or requires configuration switching is not stated in the provided specifications; consult the Datalogic datasheet or interface cable documentation for each SKU.
