Datalogic 931061345 vs Datalogic 931024111-00053: Specification Comparison
Both products are Datalogic Matrix 220 stationary fixed-mount 2D industrial barcode scanners in the same product family, sharing a 1.2 MP CMOS imager and IP65/IP67 sealing. The 931061345 and 931024111-00053 occupy the same general class of wired, fixed-mount industrial imagers intended for factory automation lines. This comparison evaluates their physical form factor, connectivity and fieldbus support, and environmental/operational parameters to help integrators and OT buyers identify which unit fits a given installation.
In This Guide
- How do the physical form factor, imager resolution, and scan performance differ between the 931061345 and 931024111-00053?
- Which unit offers broader industrial connectivity and fieldbus integration for factory automation networks?
- How do the two scanners compare on operating temperature range, ingress protection, and power input requirements?
- Which should you choose: the 931061345 or the 931024111-00053?
- Side-by-Side Specs
- FAQ
How do the physical form factor, imager resolution, and scan performance differ between the 931061345 and 931024111-00053?
Both scanners share the Datalogic Matrix 220 platform and a 1.2 MP 2D CMOS imager, so optical resolution is equivalent per spec. However, the two units diverge significantly in physical size and scan performance. The 931061345 measures 48 × 46 × 64 mm and weighs 300 g, with a rated scan rate of 800 scans/second and an integrated 16 × 2 character embedded display. It also explicitly lists Direct Part Mark (DPM) capability with integrated flexible illumination as a confirmed spec.
The 931024111-00053 is considerably smaller and lighter at 50 × 25 × 45 mm and only 60 g (without cable), but its scan engine is rated at 60 frames per second (WVGA) rather than 800 scans/second. It does not carry an explicit DPM capability claim in its spec set, and no integrated display is listed. Buyers mounting in constrained spaces may favor the 931024111-00053 for its compact footprint, while lines requiring DPM reads or a higher declared scan throughput should note the 931061345's advantages.
Which unit offers broader industrial connectivity and fieldbus integration for factory automation networks?
The 931061345 specifies PROFINET/IO and EtherNet/IP fieldbus protocols in addition to PoE Ethernet and RS-232. These are the two dominant industrial Ethernet fieldbus standards in discrete manufacturing and process automation, making this unit a direct fit for Siemens, Rockwell Automation, and compatible PLC ecosystems without additional gateways.
The 931024111-00053 lists Ethernet and PoE connectivity, along with USB and RS-232 interfaces, and a power supply range of 10–30 VDC / 5 VDC. However, its spec set does not explicitly confirm PROFINET/IO or EtherNet/IP fieldbus support. USB presence suggests possible configuration or integration flexibility, but fieldbus protocol support for factory network integration is not confirmed by the provided specifications for this SKU. Integrators requiring certified fieldbus participation should verify protocol support with Datalogic before specifying the 931024111-00053.
How do the two scanners compare on operating temperature range, ingress protection, and power input requirements?
Both units share an IP65/IP67 ingress protection rating, making both suitable for wash-down environments and dust-tight installations. On operating temperature, the 931061345 is rated -10°C to 50°C (14°F to 122°F). The 931024111-00053 lists two conflicting temperature ranges in its spec set: one entry states -10°C to 50°C, while another field explicitly records 0°C to 50°C (32°F to 122°F) as operating temperature, with storage rated to -20°C to 70°C. Buyers deploying in sub-zero ambient conditions should verify the actual cold-start operating floor with Datalogic for the 931024111-00053, as the specs are internally inconsistent.
On power, the 931061345 is specified as PoE-powered (30 W listed) with no separate DC input range called out. The 931024111-00053 lists a broad DC input of 10–30 VDC or 5 VDC alongside PoE, offering more flexibility for installations where PoE infrastructure is not available. The 931061345 does not list a DC voltage input range in its specs.
Which should you choose: the 931061345 or the 931024111-00053?
Our take: The 931061345 is the stronger choice when PROFINET/IO or EtherNet/IP fieldbus integration, confirmed DPM capability, and higher declared scan throughput are required. It specifies 800 scans/second versus 60 fps for the 931024111-00053, explicitly supports both major industrial Ethernet fieldbus protocols absent from the 931024111-00053's confirmed spec set, and lists DPM with integrated flexible illumination. The 931024111-00053 is substantially lighter (60 g vs 300 g) and smaller (50 × 25 × 45 mm vs 48 × 46 × 64 mm), and its broader power input range (10–30 VDC / 5 VDC) makes it viable where PoE infrastructure is unavailable. However, its operating temperature floor is ambiguous across its own spec fields, and fieldbus support is unconfirmed. Specify the 931061345 for PLC-integrated production lines needing DPM and fieldbus; evaluate the 931024111-00053 for compact, PoE-optional general barcode reading after confirming its temperature and protocol specs directly with Datalogic.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Datalogic 931061345 | Datalogic 931024111-00053 |
|---|---|---|
| Series / Family | Matrix 220 | Matrix 220 |
| Product Type | Stationary Industrial Scanner | Stationary Industrial Scanner |
| Imager | 1.2 MP 2D CMOS | 1.2 MP 2D CMOS |
| Scan Rate | 800 scans/sec | 60 fps (WVGA) |
| DPM Capable | Yes, integrated flexible illumination | — |
| IP Rating | IP65/IP67 | IP65/IP67 |
| Operating Temp | -10°C to 50°C | 0°C to 50°C (conflict: also listed as -10°C) |
| Storage Temp | — | -20°C to 70°C |
| Dimensions (mm) | 48 × 46 × 64 | 50 × 25 × 45 |
| Weight | 300 g | 60 g (without cable) |
| Fieldbus | PROFINET/IO; EtherNet/IP | — |
| Interfaces | PoE Ethernet; RS-232 | PoE Ethernet; USB; RS-232 |
| Power Input | PoE (30 W) | 10–30 VDC / 5 VDC; PoE |
| Integrated Display | 16 × 2 character | — |
| Warranty | 2-Year Limited | 2-Year Limited |
| Symbologies (2D) | QR Code; Data Matrix; PDF417; DPM | QR Code; Data Matrix; PDF417 |
Frequently Asked Questions
Which should you choose: the 931061345 or the 931024111-00053?
The 931061345 is the stronger choice when PROFINET/IO or EtherNet/IP fieldbus integration, confirmed DPM capability, and higher declared scan throughput are required. It specifies 800 scans/second versus 60 fps for the 931024111-00053, explicitly supports both major industrial Ethernet fieldbus protocols absent from the 931024111-00053's confirmed spec set, and lists DPM with integrated flexible illumination. The 931024111-00053 is substantially lighter (60 g vs 300 g) and smaller (50 × 25 × 45 mm vs 48 × 46 × 64 mm), and its broader power input range (10–30 VDC / 5 VDC) makes it viable where PoE infrastructure is unavailable. However, its operating temperature floor is ambiguous across its own spec fields, and fieldbus support is unconfirmed. Specify the 931061345 for PLC-integrated production lines needing DPM and fieldbus; evaluate the 931024111-00053 for compact, PoE-optional general barcode reading after confirming its temperature and protocol specs directly with Datalogic.
Is the 931061345 or 931024111-00053 compatible with Siemens or Rockwell PLC networks without a gateway?
Only the 931061345 explicitly lists PROFINET/IO (Siemens-compatible) and EtherNet/IP (Rockwell-compatible) fieldbus protocols in its specifications. The 931024111-00053 does not confirm either protocol in its provided spec set, so fieldbus compatibility for that SKU should be verified directly with Datalogic before assuming gateway-free integration.
Which scanner is better suited for reading direct part marks (DPM) on metal or machined components?
The 931061345 explicitly specifies DPM capability with integrated flexible illumination in its confirmed specs. The 931024111-00053 does not include a DPM capability claim in its provided specifications. For DPM applications, the 931061345 is the only unit with a documented DPM spec from the data provided.
Can either scanner operate in freezer or near-freezing environments below 0°C?
The 931061345 is rated to -10°C operating per its specifications. The 931024111-00053 has a conflict in its own spec fields — one entry states -10°C and another states 0°C as the lower operating limit — so buyers should request clarification from Datalogic before deploying that unit in sub-zero conditions. Storage temperature for the 931024111-00053 is listed to -20°C.
