Datalogic 931061345 Matrix 220 Stationary Industrial Scanner

Overview

The Datalogic Matrix 220 (model 931061345) is a compact fixed-mount 1.2MP 2D CMOS scanner built for production lines, quality checkpoints, and warehouse automation where space is tight and reliability is non-negotiable. At 48 x 46 x 64 mm and 300g, it fits into confined assembly stations and conveyor-side mounts without occupying real estate. IP65/IP67 sealing handles wet, dusty, and harsh manufacturing floors—no special enclosure needed. Power over Ethernet eliminates dedicated power runs, cutting installation time and cable clutter on factory floors already crowded with control wiring.

Compatibility

The Matrix 220 connects via dual fieldbus: PROFINET/IO and EtherNet/IP. This means direct integration with Siemens S7, Allen-Bradley CompactLogix, and other mainstream PLC ecosystems without gateway hardware or protocol converters. Ethernet connectivity also supports standard industrial switches and network infrastructure. RS-232 serial fallback is available for legacy systems. PoE sourcing requires standard 802.3at midspan or switch port (minimum 30W recommended for multicore processing headroom).

Installation Notes

Mount the Matrix 220 in fixed overhead or side-mounted positions aligned perpendicular to barcode flow. Operating temperature range is -10°C to 50°C; confirm ambient conditions before deployment in freezer or outdoor logistics yards. The rotating connector block simplifies cable dressing on tight production lines. Flexible integrated illumination adapts to reflective surfaces and etched Direct Part Marks without manual lens changes—configure intensity and spectrum via the bundled Genius software tool or X-PRESS display interface (16 x 2 character embedded display for field diagnostics).

What's in the Box

  • 1x Matrix 220 scanner unit
  • 1x Rotating connector block with M12 Ethernet port
  • 1x X-PRESS interface cable for configuration
  • 1x Mounting bracket and fasteners
  • 1x Quick-start guide
Expert Analysis
Specifications
Series / Family: Matrix 220
Product Type: Stationary Industrial Scanner
Scan Type: 1.2 MP 2D CMOS Imager
Ingress Protection Rating: IP65/IP67
Connectivity: Ethernet (PoE), PROFINET/IO, ETHERNET/IP
Operating Temperature: -10 to 50 C (14 to 122 F)
Weight: 300g (0.66 lbs)
Dimensions: 48 x 46 x 64 mm (1.89 x 1.81 x 2.52 in)
Warranty: 2-Year Limited
Symbologies: Code 128; Code 39; UPC; EAN; QR Code; Data Matrix; PDF417; Direct Part Mark (DPM)
Interface: PROFINET/IO; EtherNet/IP; RS-232
Ip Rating: IP65
Scan Rate: 800 scan/s
Display: 16 x 2 characters
Operating System: CILLATING MIRROR SERIAL MODEL
Communication: Interface
width: 4.59
height: 4.87
depth: 1.91
ip_rating: IP65
product_type: Handheld Scanner
Scan_Rate: 800 scans/sec
Operating_System: Proprietary Datalogic Firmware
Length: 30 cm
Compatible With: demanding
Form Factor: enclosure
PoE: PoE
Type: Matrix 220 Stationary Industrial Scanner
Scan_Engine: 1.2MP 2D CMOS Imager
Scanner_Type: Fixed-Mount Stationary
Symbologies_1D: Code 128; Code 39; UPC; EAN
Symbologies_2D: QR Code; Data Matrix; PDF417; Direct Part Mark
Scan_Pattern: 2D Area Imager
IP_Rating: IP65/IP67
Processor: Multicore processor
Screen_Size: 16 x 2 character embedded display
Camera: 1.2MP CMOS
Form_Factor: Compact stationary enclosure
Product_Type: Fixed-Mount Industrial Barcode Scanner
hide_reason: pricing_violation_2026-05-06
Brand: Datalogic
MPN: 931061345
Power: 30W
