Honeywell 3320G-2USB-0EZDN vs Honeywell 3320G-2-N: Specification Comparison
Both products belong to Honeywell's Vuquest 3320g series — fixed-mount, corded-USB, omnidirectional 1D/2D presentation scanners aimed at retail point-of-sale and receiving environments. The 3320G-2USB-0EZDN and the 3320G-2-N share the same sensor array, working range, weight, voltage, operating temperature, and warranty. The key differentiator surfaced by the provided specifications is the symbology coverage explicitly listed for each model, making this a narrow but meaningful capability comparison for buyers whose barcode mix includes PDF417 or other specialty codes.
In This Guide
- Which model covers the barcode symbologies your operation actually scans?
- Are the physical ruggedness and environmental ratings sufficient for your deployment site?
- Does the connectivity model and working range fit your POS or warehouse scanning workflow?
- Which should you choose: the 3320G-2USB-0EZDN or the 3320G-2-N?
- Side-by-Side Specs
- FAQ
Which model covers the barcode symbologies your operation actually scans?
The 3320G-2USB-0EZDN spec sheet explicitly lists PDF417 alongside UPC, QR Code, and Data Matrix as supported symbologies. PDF417 is commonly found on driver's licenses, boarding passes, shipping labels, and pharmaceutical packaging — environments that go beyond standard retail checkout.
The 3320G-2-N spec sheet lists UPC, Code 128, QR Code, and Data Matrix but does not explicitly mention PDF417 in the provided specifications. Both models share the same 838 × 640 pixel area-image sensor and the same 'Reads standard 1D, PDF' truncated symbology line, so a full PDF417 capability gap cannot be confirmed from the provided data alone — buyers should verify against the full Honeywell datasheet for the 3320G-2-N before ruling it out.
Are the physical ruggedness and environmental ratings sufficient for your deployment site?
Both models carry an IP42 rating per the enriched spec fields (dust and moisture protection), with the structured product data listing IP53 — a conflict within the provided specifications that buyers should clarify with the full datasheet before deployment in genuinely wet or dusty environments.
The 3320G-2USB-0EZDN spec explicitly states a 1.8 m (5.9 ft) drop rating. No drop rating is provided in the 3320G-2-N specifications as supplied. Both share identical operating temperature ranges of −20°C to 50°C (−4°F to 122°F) and identical 5 VDC ± 0.25 V input voltage, meaning neither holds an advantage in thermal or power tolerance.
Does the connectivity model and working range fit your POS or warehouse scanning workflow?
Both the 3320G-2USB-0EZDN and the 3320G-2-N use a corded USB wired connection operating at 5 VDC. Neither model offers wireless, Bluetooth, or RS-232 options in the provided specifications. Data is delivered directly to connected POS or inventory systems without a base station or charging cradle.
Working range is identical across both models at 15–120 cm (6–48 inches), using the same 838 × 640 pixel area-image scan pattern. Neither model has an advantage in depth of field, scan width, or interface flexibility based on the specs provided. Buyers requiring RS-232, keyboard wedge, or wireless interfaces would need to evaluate other SKUs in the Vuquest 3320g lineup.
Which should you choose: the 3320G-2USB-0EZDN or the 3320G-2-N?
Our take: The 3320G-2USB-0EZDN is the stronger documented choice when your scanning environment includes PDF417 barcodes — such as driver's licenses, shipping manifests, or regulated labels — because PDF417 is explicitly listed in its specifications, while it is absent from the 3320G-2-N's provided spec data. Additionally, the 3320G-2USB-0EZDN carries an explicit 1.8 m drop rating; no equivalent drop rating is stated for the 3320G-2-N. All other measurable parameters — sensor array (838 × 640 pixels), working range (15–120 cm), weight (77 g), operating temperature (−20°C to 50°C), input voltage (5 VDC), warranty (3 years), and USB wired connectivity — are identical between the two models. For a pure retail checkout lane scanning only UPC and QR codes, the 3320G-2-N may be functionally equivalent, but the 3320G-2USB-0EZDN provides broader confirmed symbology coverage and documented drop durability.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Honeywell 3320G-2USB-0EZDN | Honeywell 3320G-2-N |
|---|---|---|
| Series / Family | Vuquest 3320g | Vuquest 3320g |
| Part Number | 3320G-2USB-0EZDN | 3320G-2-N |
| Scan Type | 1D/2D Presentation | 1D/2D Presentation |
| Sensor Array | 838 × 640 pixel area image | 838 × 640 pixel area image |
| Connectivity | USB Wired (corded) | USB Wired (corded) |
| Working Range | 15–120 cm (6–48 in) | 15–120 cm (6–48 in) |
| Explicit Symbologies (from specs) | UPC, QR, Data Matrix, PDF417, 1D standards | UPC, Code 128, QR, Data Matrix, 1D standards |
| PDF417 Support (from specs) | Explicitly listed | Not listed in provided specs |
| Drop Rating | 1.8 m (5.9 ft) | — (not stated in provided specs) |
| IP Rating (enriched spec) | IP42 | IP42 |
| IP Rating (structured spec) | IP53 | IP53 |
| Operating Temperature | −20°C to 50°C (−4°F to 122°F) | −20°C to 50°C (−4°F to 122°F) |
| Input Voltage | 5 VDC ± 0.25 V | 5 VDC ± 0.25 V |
| Weight | 77 g (0.17 lbs / 2.7 oz) | 77 g (0.17 lbs / 2.7 oz) |
| Primary Application | Retail POS and receiving | Retail checkout and warehouse pick |
| Warranty | 3-year | 3-year |
Frequently Asked Questions
Which should you choose: the 3320G-2USB-0EZDN or the 3320G-2-N?
The 3320G-2USB-0EZDN is the stronger documented choice when your scanning environment includes PDF417 barcodes — such as driver's licenses, shipping manifests, or regulated labels — because PDF417 is explicitly listed in its specifications, while it is absent from the 3320G-2-N's provided spec data. Additionally, the 3320G-2USB-0EZDN carries an explicit 1.8 m drop rating; no equivalent drop rating is stated for the 3320G-2-N. All other measurable parameters — sensor array (838 × 640 pixels), working range (15–120 cm), weight (77 g), operating temperature (−20°C to 50°C), input voltage (5 VDC), warranty (3 years), and USB wired connectivity — are identical between the two models. For a pure retail checkout lane scanning only UPC and QR codes, the 3320G-2-N may be functionally equivalent, but the 3320G-2USB-0EZDN provides broader confirmed symbology coverage and documented drop durability.
Can both the 3320G-2USB-0EZDN and 3320G-2-N read QR codes and 2D barcodes?
Yes — both models are specified as 1D/2D presentation scanners using the same 838 × 640 pixel area-image sensor, and both explicitly list QR Code and Data Matrix in their provided specifications. PDF417 is explicitly listed for the 3320G-2USB-0EZDN but is not confirmed in the provided specs for the 3320G-2-N.
Is either model wireless or does it require a cable connection?
Both models are corded USB only per the provided specifications. Neither offers wireless, Bluetooth, or RS-232 connectivity in the data supplied. If wireless scanning is required, a different model in the Vuquest line would need to be evaluated.
Is the 3320G-2USB-0EZDN or 3320G-2-N more rugged for a high-traffic warehouse or receiving dock?
Based on provided specifications, the 3320G-2USB-0EZDN has a confirmed 1.8 m (5.9 ft) drop rating; no drop rating is stated for the 3320G-2-N. Both share the same operating temperature range (−20°C to 50°C) and the same IP rating conflict (IP42 in enriched fields, IP53 in structured data) — buyers should verify the authoritative IP rating against the official Honeywell datasheet before deploying in wet or heavily dusty environments.
