CipherLab A2504SMBSU001 vs CipherLab A2200NBUN0001: Specification Comparison
Both the CipherLab A2504SMBSU001 and A2200NBUN0001 are handheld barcode scanners in the same general product class, but they differ meaningfully in scan engine generation: the A2504SMBSU001 is a 1D linear imager with Bluetooth connectivity, while the A2200NBUN0001 is a 2D area-imaging scanner with USB connectivity. Buyers cross-shopping these units are typically weighing 1D-only wireless workflow needs against 2D corded versatility, making this a legitimate and common purchasing decision in warehouse, retail, and light-industrial environments.
In This Guide
- Which scanner reads the barcode types your operation actually uses?
- How do connectivity method and environmental ruggedness compare between the two units?
- Which unit better fits stationary point-of-scan versus mobile roaming deployment scenarios?
- Which should you choose: the A2504SMBSU001 or the A2200NBUN0001?
- Side-by-Side Specs
- FAQ
Which scanner reads the barcode types your operation actually uses?
The A2504SMBSU001 uses a 1D linear imager engine and supports a focused set of 1D symbologies: Code 39, Code 128, UPC/EAN, GS1 DataBar, Codabar, and MSI. It cannot read any 2D codes such as QR Code, Data Matrix, or PDF417. Its scan rate is specified at 578 scans per second, which reflects the high-speed sweep capability of linear imager technology optimized for 1D throughput.
The A2200NBUN0001 uses a 2D scan engine and reads the full 1D symbology set — including Code 39, Code 93, Code 128, UPC/EAN/GS1-128, Codabar, Interleave 2 of 5, MSI, and numerous others — plus 2D formats including QR Code, Data Matrix, PDF417, Aztec, MaxiCode, Micro QR Code, HanXin, and Composite Codes. A scan rate is not specified for the A2200NBUN0001 in the provided data. Buyers whose workflows include any 2D symbology — mobile-phone screens, healthcare labels, shipping manifests — require the A2200NBUN0001, as the A2504SMBSU001 physically cannot decode 2D codes.
How do connectivity method and environmental ruggedness compare between the two units?
The A2504SMBSU001 offers Bluetooth wireless connectivity plus USB, making it suitable for untethered, mobile scanning environments. Its IP65 rating provides full protection against dust ingress and resistance to low-pressure water jets, making it appropriate for dusty warehouse floors or light washdown-adjacent areas. No drop-resistance specification is provided in the available data for this model.
The A2200NBUN0001 connects via USB only — no wireless option is specified. Its IP52 rating provides protection against dust that could harm equipment and against dripping water, which is a lower environmental seal than the A2504SMBSU001's IP65. However, the A2200NBUN0001 does carry a stated drop specification of 1.5 m (4.9 ft) across multiple drops onto concrete, providing a concrete durability benchmark. No equivalent drop spec is provided for the A2504SMBSU001. Physical dimensions for the A2200NBUN0001 are 83 × 80 × 150 mm and weight is 320 g / 380 g (two figures listed, likely without/with cable). Dimensions and weight are not specified for the A2504SMBSU001.
Which unit better fits stationary point-of-scan versus mobile roaming deployment scenarios?
The A2504SMBSU001's Bluetooth wireless capability and IP65 rating position it for mobile, roaming scan tasks — pick-and-pack on a warehouse floor, inventory walks, or any application where the operator moves away from a fixed workstation. Its scan pattern supports auto-sense and continuous modes, suiting active in-motion scanning.
The A2200NBUN0001's scan pattern is listed as presentation mode, which is oriented toward stationary or semi-stationary use: the operator brings items to the scanner, or the scanner is positioned at a fixed point such as a checkout lane or receiving desk. Its USB-only connectivity reinforces a tethered, fixed-station deployment model. Its storage temperature range is specified at -40°C to 60°C (-40°F to 140°F), but operating temperature is not listed in the provided specs. Input voltage is specified as 5V 2A max. No power input specification is provided for the A2504SMBSU001.
Which should you choose: the A2504SMBSU001 or the A2200NBUN0001?
Our take: The A2504SMBSU001 is the stronger choice when the workflow is 1D-only, mobile, and demands high-throughput wireless scanning in a harsh environment. Its 578 scans-per-second rate, IP65 dust-and-splash seal, and Bluetooth-plus-USB connectivity address fast-moving warehouse and logistics applications where operators roam and 1D barcodes are the exclusive format. The A2200NBUN0001 is the stronger choice when 2D symbology support is required or may be required in the future — it reads QR Code, Data Matrix, PDF417, Aztec, MaxiCode, and an extensive 1D set that exceeds the A2504SMBSU001's range. Its 1.5 m concrete drop rating provides a verified durability benchmark the A2504SMBSU001 lacks in the provided specs, though its IP52 rating is lower than the A2504SMBSU001's IP65. Neither unit overlaps the other's core strength: buyers locked into 1D-only codes with wireless mobility needs should specify the A2504SMBSU001; buyers needing 2D decode capability or a USB fixed-station presenter should specify the A2200NBUN0001.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | CipherLab A2504SMBSU001 | CipherLab A2200NBUN0001 |
|---|---|---|
| Scan Engine | 1D Linear Imager | 2D Area Imager |
| Connectivity | Bluetooth + USB | USB only |
| IP Rating | IP65 | IP52 |
| Scan Rate | 578 scans/sec | — |
| Drop Specification | — | 1.5 m onto concrete |
| Scan Pattern | Auto-sense and continuous | Presentation mode |
| Scan Range | 0.5–60 cm (varies by symbology) | — |
| 1D Symbologies | Code 39, Code 128, UPC/EAN, GS1 DataBar, Codabar, MSI | Code 39, Code 93, Code 128, UPC/EAN/GS1-128, Codabar, I2of5, MSI, ISBT-128, and more |
| 2D Symbologies | None | QR Code, Data Matrix, PDF417, Aztec, MaxiCode, Micro QR, HanXin, Composite |
| Dimensions | — | 83 x 80 x 150 mm (3.3 x 3.2 x 5.9 in) |
| Weight | — | 320 g / 380 g (11 oz / 13 oz) |
| Input Voltage | — | 5V 2A max |
| Storage Temperature | — | -40°C to 60°C (-40°F to 140°F) |
| Color Options | Black, Register White | Black |
| Min Print Contrast | 15% | — |
| Warranty | 2-Year | 2-Year |
Frequently Asked Questions
Which should you choose: the A2504SMBSU001 or the A2200NBUN0001?
The A2504SMBSU001 is the stronger choice when the workflow is 1D-only, mobile, and demands high-throughput wireless scanning in a harsh environment. Its 578 scans-per-second rate, IP65 dust-and-splash seal, and Bluetooth-plus-USB connectivity address fast-moving warehouse and logistics applications where operators roam and 1D barcodes are the exclusive format. The A2200NBUN0001 is the stronger choice when 2D symbology support is required or may be required in the future — it reads QR Code, Data Matrix, PDF417, Aztec, MaxiCode, and an extensive 1D set that exceeds the A2504SMBSU001's range. Its 1.5 m concrete drop rating provides a verified durability benchmark the A2504SMBSU001 lacks in the provided specs, though its IP52 rating is lower than the A2504SMBSU001's IP65. Neither unit overlaps the other's core strength: buyers locked into 1D-only codes with wireless mobility needs should specify the A2504SMBSU001; buyers needing 2D decode capability or a USB fixed-station presenter should specify the A2200NBUN0001.
Can the A2504SMBSU001 or A2200NBUN0001 read QR codes?
Only the A2200NBUN0001 can read QR codes. It uses a 2D scan engine that supports QR Code, Micro QR Code, Data Matrix, PDF417, Aztec, MaxiCode, HanXin, and Composite Codes, among others. The A2504SMBSU001 uses a 1D linear imager and is limited to 1D symbologies such as Code 39, Code 128, and UPC/EAN — it cannot decode any 2D barcode format.
Is the A2504SMBSU001 or A2200NBUN0001 better suited for a dusty or wet warehouse environment?
The A2504SMBSU001 carries an IP65 rating, meaning it is fully dust-tight and resistant to low-pressure water jets — a higher environmental seal than the A2200NBUN0001's IP52 rating, which protects against limited dust ingress and dripping water only. For consistently dusty or splash-prone environments, the A2504SMBSU001's IP65 rating provides greater protection per the specifications provided.
Which unit works wirelessly, and which requires a cable?
The A2504SMBSU001 supports Bluetooth wireless connectivity in addition to USB, allowing operators to scan without being tethered to a workstation. The A2200NBUN0001 is specified as a USB scanner only — no wireless connectivity option is listed in the provided specifications, making it a tethered, fixed-station or corded-handheld unit.
