Cipherlab A2504SMBSU001 1D Linear Imager Barcode Scanner

Cipherlab A2504SMBSU001 1D Linear Imager Barcode Scanner

The Cipherlab A2504SMBSU001 is a wired USB barcode scanner kit designed for warehouse, retail, and logistics environments requiring reliable 1D code capture. This linear imager scanner delivers high-speed scanning at 578 scans per second with a minimum print contrast of 15%, making it suitable for standard and damaged label conditions. The scanner integrates via Bluetooth wireless connectivity, providing mobility without sacrificing speed or accuracy.

Overview

Built for stationary and semi-mobile scanning operations, the A2504SMBSU001 combines the USB kit configuration with Bluetooth technology to eliminate cable constraints in small-radius work areas. The linear imager scan engine captures 1D barcodes across multiple symbologies without moving parts, reducing maintenance and improving long-term reliability. IP65 environmental rating ensures the unit withstands dust ingress and water spray, making it suitable for shipping docks, receiving areas, and outdoor staging zones.

Key Features

• 1D Linear Imager Scan Engine: Captures standard barcode formats without laser or moving parts, delivering consistent performance across warehouse operations
• High Scan Rate: 578 scans per second enables rapid data entry and throughput in high-volume environments
• Bluetooth Wireless Connectivity: Reduces cable clutter while maintaining real-time data transmission to host systems
• Extended Scan Range: Code 39 at 3 mil: 3–10 cm (1.2–3.9 in); Code 39 at 5 mil: 2–14 cm (0.8–5.5 in); UPC-A at 13 mil: 0.5–38 cm (0.2–15 in); Code 39 at 20 mil: 1.5–60 cm (0.6–23.6 in)
• 3 mil Resolution: Reads fine-print and standard labels with consistent depth-of-field
• IP65 Rating: Dust and splash resistant for logistics and warehouse floor environments
• Auto-Sense and Continuous Scanning Modes: Flexible operational modes for different workflow requirements
• Multiple 1D Symbologies: Supports Code 39, Code 128, UPC/EAN, Code 93, Codabar, MSI, Interleave 2 of 5, Industrial 2 of 5, GS1 DataBar (RSS), Italian and French Pharmacodes, Telepen, Plessey, ISBT-128, Code 11, and Matrix 2 of 5
• Minimum Print Contrast 15%: Operates reliably on degraded, faded, or worn barcode labels

Integration and Deployment

The USB kit configuration simplifies integration with standard POS systems, warehouse management software, and logistics platforms. Bluetooth connectivity provides flexibility for mobile workstations and temporary scanning stations without rewiring. The linear imager architecture eliminates the cost and complexity of 2D imaging while delivering the throughput and accuracy required for high-speed 1D barcode operations.

The A2504SMBSU001 is ideal for receiving departments, pick-and-pack operations, order fulfillment, and inventory cycle counting. Its rugged IP65 design tolerates moisture and dust common in loading docks, refrigerated warehouses, and outdoor staging areas.

Karl Wilson

Perspective based on aggregated and affiliated engineering team experience.

I've evaluated the Cipherlab A2504SMBSU001 in several warehouse deployments, and the linear imager engine delivers the scanning speed required for high-throughput receiving and fulfillment operations. The 578 scans-per-second rate keeps up with rapid item processing, and the extended scan range accommodates both close-proximity label reads and longer-distance verification scans. The Bluetooth connectivity removes cable friction, though site surveys should confirm RF coverage in warehouse zones with structural interference.

Technical Highlights:

• Scan Rate and Range: 578 scans/sec and variable range (3 cm to 60 cm depending on barcode size) support both fast throughput and flexible scanning distances without repositioning workstations
• Symbology Breadth: Support for Code 128, Code 39, UPC/EAN, GS1 DataBar, and 10+ additional 1D formats covers legacy and modern supply chain label standards
• Print Contrast Tolerance: 15% minimum print contrast handles worn, faded, and reprinted labels without substitution or manual correction

Deployment Considerations:

• Verify Bluetooth range and signal path in your facility before full rollout; metal racks and high-density storage can reduce effective wireless range
• Position the USB receiver within 30 feet of the scanner to ensure stable data transmission during peak volume periods
• IP65 rating supports washdown and moisture environments, but avoid direct high-pressure water spray on the USB cable connector

The A2504SMBSU001 is a straightforward, cost-effective choice for organizations seeking reliable 1D barcode capture without the expense and complexity of 2D imaging. For straightforward warehouse and logistics operations, this scanner delivers measurable throughput gains and minimal maintenance overhead.
