Socket Mobile CX4066-3129 vs CipherLab A2560SCBS0001: Specification Comparison
Both the Socket Mobile CX4066-3129 SocketScan S720 and the CipherLab A2560SCBS0001 are cordless 1D Bluetooth handheld barcode scanners targeting mobile retail, warehouse, and point-of-sale environments. The comparison pits a scanner with mixed 1D/2D symbology support and a documented battery capacity against a dedicated 1D linear imager with a rated scan speed, broader 1D symbology library, and an IP65 ingress protection rating. Buyers cross-shopping these units are typically weighing symbology breadth, environmental durability, and scan performance against shift-length battery life.
In This Guide
- Which scanner reads more barcode types, and does either handle 2D codes?
- How do scan speed, range, and environmental protection compare?
- What are the differences in battery life, connectivity options, and warranty coverage?
- Which should you choose: the CX4066-3129 or the A2560SCBS0001?
- Side-by-Side Specs
- FAQ
Which scanner reads more barcode types, and does either handle 2D codes?
The CX4066-3129 is specified with both 1D and 2D symbologies: Code 128, Code 39 on the 1D side, plus QR Code, Data Matrix, and PDF417 on the 2D side. This gives it a meaningful advantage wherever QR codes, shipping labels using PDF417, or Data Matrix marks appear in the workflow.
The A2560SCBS0001 is a pure 1D linear imager. Its 1D symbology library is substantially wider than the CX4066-3129's 1D set, covering Codabar, Code 39, Code 93, Code 128, GS1 DataBar (RSS), Industrial 2 of 5, Interleaved 2 of 5, ISBT-128, Italian and French Pharmacodes, Matrix 2 of 5, MSI, Plessey, Telepen, UPC/EAN/GS1-128, and Code 11 — 15 distinct 1D symbologies versus 2 listed for the CX4066-3129.
Buyers whose environment is strictly 1D and requires specialty codes such as Pharmacode, ISBT-128 (blood-bank), or GS1 DataBar will find the A2560SCBS0001's library more complete. Those who need any 2D capability — even occasional QR or PDF417 reads — must select the CX4066-3129, as the A2560SCBS0001 has no 2D support per its specifications.
How do scan speed, range, and environmental protection compare?
The A2560SCBS0001 provides a rated scan rate of 578 scans per second in auto-sense and continuous modes, with a documented scan range of 3–10 cm at 3 mil, 2–14 cm at 5 mil, and 1.5–60 cm at 20 mil for Code 39. No scan rate or scan range is specified for the CX4066-3129.
On environmental protection, the A2560SCBS0001 carries an IP65 rating, meaning it is fully dust-tight and protected against water jets — relevant for warehouse docks, food-service areas, or outdoor-adjacent receiving. No IP rating is specified for the CX4066-3129.
The CX4066-3129 does specify an operating temperature range of 0–45°C (32–113°F). The A2560SCBS0001 does not list an operating temperature range in the provided specifications. Buyers in thermally extreme environments should request confirmation from the manufacturer before committing to the A2560SCBS0001.
What are the differences in battery life, connectivity options, and warranty coverage?
The CX4066-3129 specifies a 2000 mAh lithium-ion battery. No battery capacity or runtime figure is provided for the A2560SCBS0001.
Both units use Bluetooth as their wireless interface. The CX4066-3129 specifications also reference Wi-Fi connectivity in addition to Bluetooth; however, the product's primary marketing describes it as a Bluetooth scanner, and no Wi-Fi protocol version or standard is specified. The A2560SCBS0001 specifies Bluetooth only, with no Wi-Fi reference.
Warranty coverage differs: the CX4066-3129 carries a 1-year warranty, while the A2560SCBS0001 is covered by a 2-year warranty — a meaningful total-cost-of-ownership consideration in high-cycle deployments. The A2560SCBS0001 is available in two colors (Black and Register White); the CX4066-3129 ships in Yellow with a charging cradle included per the listed package contents. No cradle or accessories are listed in the A2560SCBS0001 spec.
Which should you choose: the CX4066-3129 or the A2560SCBS0001?
Our take: The CX4066-3129 is the stronger choice when any 2D barcode reading — QR Code, Data Matrix, or PDF417 — is present or anticipated in the workflow, and when a documented battery capacity (2000 mAh) and a bundled charging cradle matter for shift planning. Conversely, the A2560SCBS0001 is the stronger choice for strictly 1D environments that demand a rated scan speed (578 scans/second versus no figure provided for the CX4066-3129), a wider 1D symbology library (15 symbologies versus 2 specified), IP65 dust and water resistance versus no IP rating on the CX4066-3129, and a longer warranty period (2 years versus 1 year). Healthcare facilities using ISBT-128, pharmacies using Pharmacodes, or warehouse operations requiring IP65 durability should lean toward the A2560SCBS0001, provided 2D scanning is not required.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Socket Mobile CX4066-3129 | CipherLab A2560SCBS0001 |
|---|---|---|
| Product Type | Scanner | Barcode Scanner |
| Form Factor | Handheld | Handheld |
| Scan Engine | 1D + 2D | 1D Linear Imager |
| Connectivity | Bluetooth (Wi-Fi also referenced) | Bluetooth |
| 1D Symbologies Listed | Code 128; Code 39 | Codabar; Code 39; Code 93; Code 128; GS1 DataBar (RSS); Industrial 2 of 5; Interleaved 2 of 5; ISBT-128; Pharmacodes; Matrix 2 of 5; MSI; Plessey; Telepen; UPC/EAN/GS1-128; Code 11 |
| 2D Symbologies Listed | QR Code; Data Matrix; PDF417 | — |
| Scan Rate | — | 578 scans/second |
| Scan Range (Code 39 20 mil) | — | 1.5–60 cm |
| IP Rating | — | IP65 |
| Battery Capacity | 2000 mAh | — |
| Operating Temperature | 0–45°C (32–113°F) | — |
| Min Print Contrast | — | 15% |
| Scan Pattern | — | Auto-sense and continuous |
| Color Options | Yellow | Black; Register White |
| Package Contents | Scanner + charging cradle | — |
| Warranty | 1 year | 2 years |
Frequently Asked Questions
Which should you choose: the CX4066-3129 or the A2560SCBS0001?
The CX4066-3129 is the stronger choice when any 2D barcode reading — QR Code, Data Matrix, or PDF417 — is present or anticipated in the workflow, and when a documented battery capacity (2000 mAh) and a bundled charging cradle matter for shift planning. Conversely, the A2560SCBS0001 is the stronger choice for strictly 1D environments that demand a rated scan speed (578 scans/second versus no figure provided for the CX4066-3129), a wider 1D symbology library (15 symbologies versus 2 specified), IP65 dust and water resistance versus no IP rating on the CX4066-3129, and a longer warranty period (2 years versus 1 year). Healthcare facilities using ISBT-128, pharmacies using Pharmacodes, or warehouse operations requiring IP65 durability should lean toward the A2560SCBS0001, provided 2D scanning is not required.
Can either scanner read QR codes or 2D barcodes?
Only the CX4066-3129 supports 2D symbologies — specifically QR Code, Data Matrix, and PDF417 — per its specifications. The A2560SCBS0001 is a 1D linear imager only and cannot read 2D codes.
Which scanner is better suited for warehouse or food-service environments where it might get wet or dusty?
The A2560SCBS0001 carries an IP65 rating, confirming full dust-tight protection and resistance to water jets. No IP rating is specified for the CX4066-3129, so the A2560SCBS0001 is the documented choice for harsh or wet environments.
Is the CX4066-3129 or A2560SCBS0001 better for healthcare barcode applications such as blood-bank or pharmacy?
The A2560SCBS0001 explicitly lists ISBT-128 (blood-bank) and Italian and French Pharmacodes among its 15 supported 1D symbologies. Neither of those is listed in the CX4066-3129 specifications, making the A2560SCBS0001 the better-documented choice for those specific healthcare use cases — provided 2D codes are not also required.
