Hanwha XNO-6020R vs i-PRO U15301-V3L: Specification Comparison
Both the Hanwha XNO-6020R and the i-PRO WV-U15301-V3L are 2MP outdoor IR bullet cameras targeting perimeter and general surveillance applications. This comparison is relevant for installers and IT buyers evaluating fixed-lens, single-cable PoE deployments where imaging performance, cybersecurity posture, environmental ratings, and VMS integration are primary decision factors. The two units share the same resolution class, sensor format, and form factor, making them genuine cross-shop candidates for outdoor bullet camera bids.
In This Guide
How do the imaging specs compare?
Both cameras use a 1/2.8-inch 2MP CMOS sensor. The Hanwha XNO-6020R ships with a fixed 4mm lens at F1.4 aperture, delivering an 88.6° horizontal field of view, a minimum color illumination of 0.015 lux, and 0 lux in B/W with IR active. It supports up to 60fps max frame rate and a Wide Dynamic Range of 150dB. The i-PRO WV-U15301-V3L specifies a 3.2x optical zoom lens (focal length not listed as a fixed mm value in provided specs), F1.6 aperture, minimum color illumination of 0.05 lux (1/30s), 0.004 lux monochrome with 16/30s AGC, and a maximum 120dB WDR. Standard frame rate on the i-PRO is 30fps; 25fps is selectable.
On IR range, the i-PRO WV-U15301-V3L reaches 42m at 30IRE / 30m at 50IRE, compared to 30m for the XNO-6020R. The XNO-6020R's 150dB WDR outpaces the i-PRO's 120dB Super Dynamic WDR by 30dB, which is a meaningful advantage in scenes with simultaneous bright and dark zones such as entrances with backlighting. The XNO-6020R's F1.4 aperture passes more light than the i-PRO's F1.6, but the i-PRO's optical zoom lens offers scene flexibility that a fixed-focal camera cannot match.
What about installation and environment?
The Hanwha XNO-6020R carries IP67, IP66, and NEMA 4X ingress ratings plus IK10 vandal resistance, and operates from -30°C to +55°C. It accepts PoE (IEEE 802.3af, Class 3) or 12VDC, with maximum draw of 9.7W on PoE and 8.8W on 12VDC. Physical dimensions are Ø70×296mm at 1,220g. The i-PRO WV-U15301-V3L is rated IP66 and IK10, operating from -30°C to +50°C. Power source and exact consumption figures are listed in the provided specs as 'Power Supply / Power Consumption [Power Source]' without discrete values; PoE 802.3af is confirmed. Dimensions are 112.5mm (W) × 112.5mm (H) × 298.5mm (D). Weight is not stated in the provided i-PRO specs.
The XNO-6020R has a slight environmental edge: IP67 (full immersion rated) vs the i-PRO's IP66 (powerful water jet), and a 5°C wider upper operating temperature limit (55°C vs 50°C). Both units achieve IK10 impact resistance. The XNO-6020R also documents 12VDC as an alternative power path; the i-PRO specs provided do not confirm an equivalent DC input option.
Which fits your VMS and analytics better?
Both cameras support ONVIF Profile S, G, and T, ensuring compatibility with major VMS platforms. The Hanwha XNO-6020R additionally exposes SUNAPI (HTTP API) and the Wisenet open platform for deeper native integration with Wisenet/Hanwha VMS ecosystems. Analytics on the XNO-6020R are extensive: defocus detection, directional detection, fog detection, face detection, motion detection, digital auto tracking, appear/disappear, enter/exit, loitering, tampering, virtual line, audio detection, and sound classification, plus business intelligence features (people counting, queue management, heatmap). The i-PRO WV-U15301-V3L provides VMD (4 areas) and scene change detection per the provided specs; additional i-PRO AI analytics are not listed in the supplied data.
For audio, the XNO-6020R provides both audio input (selectable mic/line, 2.5VDC supply, 2K Ohm impedance) and audio output (line out, 1Vrms max). The i-PRO WV-U15301-V3L confirms audio input; audio output capability is not stated in the provided specs. On-board storage, the XNO-6020R supports dual Micro SD/SDHC/SDXC slots up to 512GB total; edge storage specifications for the i-PRO are not included in the provided data. The i-PRO WV-U15301-V3L is certified NDAA-compliant and carries FIPS 140-3 Level 3 certification via a SecureElement (EdgeLock SE052F), a cybersecurity credential not claimed in the Hanwha specs provided.
Which should you choose: the XNO-6020R or the U15301-V3L?
Our take: The XNO-6020R is the stronger choice when WDR performance, on-board analytics depth, and dual-slot edge storage are primary requirements; the WV-U15301-V3L is the stronger choice when optical zoom flexibility, extended IR range, or FIPS 140-3 / NDAA cybersecurity compliance is mandatory. Concrete spec deltas: the XNO-6020R delivers 150dB WDR versus 120dB on the i-PRO—a 30dB difference material in high-contrast scenes—and supports up to 60fps versus 30fps on the i-PRO, relevant for fast-motion applications. The i-PRO extends IR coverage to 42m versus 30m on the XNO-6020R, and its 3.2x optical zoom enables post-install field-of-view adjustment that the fixed 4mm Hanwha cannot. If the deployment is a federal or compliance-sensitive environment requiring NDAA and FIPS 140-3 validated hardware, the i-PRO WV-U15301-V3L is the only spec-verified option of the two. For Wisenet-native VMS sites needing rich edge analytics and dual SD redundancy, the XNO-6020R is the more fully documented choice.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Hanwha XNO-6020R | i-PRO U15301-V3L |
|---|---|---|
| Resolution | 2MP | 2MP |
| Image Sensor | 1/2.8" 2MP CMOS | 1/2.8" CMOS |
| Lens / Focal Length | 4mm fixed, F1.4 | 3.2x optical zoom, F1.6 |
| Horizontal FOV | 88.6° | — |
| Min. Illumination (Color) | 0.015 lux | 0.05 lux (F1.6, 1/30s) |
| Min. Illumination (B/W / IR) | 0 lux (IR on) | 0 lux (IR on); 0.004 lux (mono, 16/30s AGC) |
| IR Range | 30m (98 ft) | 42m (138 ft) at 30IRE / 30m at 50IRE |
| WDR | 150dB | 120dB Super Dynamic (0–31 levels) |
| Max Frame Rate | 60fps | 30fps (25fps selectable) |
| Video Compression | H.265 / H.264 / MJPEG | H.265 / H.264 / MJPEG |
| IP Rating | IP67 / IP66 / NEMA 4X | IP66 |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | -30°C to +55°C | -30°C to +50°C |
| Power Input / PoE Class | PoE 802.3af Class 3 / 12VDC; max 9.7W | PoE 802.3af; power consumption not specified in provided data |
| Edge Storage | Dual Micro SD/SDHC/SDXC up to 512GB | — |
| Audio | Input (mic/line selectable) + Line output | Input confirmed; output not stated in provided data |
| Alarm I/O | 1 input / 1 output | — |
| ONVIF | Profile S / G / T | Profile S / G / T |
| Edge Analytics | Defocus, directional, fog, face, motion, auto tracking, appear/disappear, enter/exit, loitering, tampering, virtual line, audio detection, sound classification, people counting, queue management, heatmap | VMD (4 areas); Scene Change Detection |
| Cybersecurity / Compliance | HTTPS/SSL, Digest auth, 802.1X (EAP-TLS, EAP-LEAP) | FIPS 140-3 Level 3 (SecureElement); NDAA-compliant |
| Dimensions | Ø70 × 296mm | 112.5mm (W) × 112.5mm (H) × 298.5mm (D) |
| Weight | 1,220g (2.69 lb) | — |
| Warranty | 3-year | — |
Frequently Asked Questions
Which should you choose: the XNO-6020R or the U15301-V3L?
The XNO-6020R is the stronger choice when WDR performance, on-board analytics depth, and dual-slot edge storage are primary requirements; the WV-U15301-V3L is the stronger choice when optical zoom flexibility, extended IR range, or FIPS 140-3 / NDAA cybersecurity compliance is mandatory. Concrete spec deltas: the XNO-6020R delivers 150dB WDR versus 120dB on the i-PRO—a 30dB difference material in high-contrast scenes—and supports up to 60fps versus 30fps on the i-PRO, relevant for fast-motion applications. The i-PRO extends IR coverage to 42m versus 30m on the XNO-6020R, and its 3.2x optical zoom enables post-install field-of-view adjustment that the fixed 4mm Hanwha cannot. If the deployment is a federal or compliance-sensitive environment requiring NDAA and FIPS 140-3 validated hardware, the i-PRO WV-U15301-V3L is the only spec-verified option of the two. For Wisenet-native VMS sites needing rich edge analytics and dual SD redundancy, the XNO-6020R is the more fully documented choice.
Is the XNO-6020R or WV-U15301-V3L better for low-light performance?
The XNO-6020R reaches 0.015 lux in color mode and 0 lux B/W with IR at a rated 30m range. The WV-U15301-V3L reaches 0.05 lux color and 0.004 lux monochrome (with extended 16/30s AGC) and extends IR coverage to 42m. For pure IR distance the i-PRO has the advantage; for WDR-assisted performance in mixed lighting the XNO-6020R's 150dB rating leads.
Which camera is better suited for government or federally regulated installations?
The i-PRO WV-U15301-V3L is the only one of the two with documented NDAA compliance and FIPS 140-3 Level 3 certification via its SecureElement. Neither of these credentials appears in the provided Hanwha XNO-6020R specifications. For any project mandating NDAA or FIPS 140-3, the i-PRO is the spec-verified choice.
Does either camera support on-board video storage without a separate NVR?
Yes—the Hanwha XNO-6020R provides two Micro SD/SDHC/SDXC card slots supporting up to 512GB of combined edge storage, and the camera triggers local recording on alarm events. On-board storage specifications for the i-PRO WV-U15301-V3L are not included in the provided product data; buyers should verify SD card support directly with i-PRO documentation before assuming edge storage capability.
