Hanwha A8014R vs Hanwha XNF-8010RV: Specification Comparison
The Hanwha XNF-A8014R and XNF-8010RV are both 6MP fisheye cameras from Hanwha's Wisenet line, each delivering a 2048×2048 panoramic image from a fixed fisheye lens. Despite sharing resolution and camera type, they target different deployment scenarios: the A8014R is an IP42-rated indoor ceiling unit, while the XNF-8010RV carries IP66/IK10 ratings for outdoor and vandal-prone environments. This comparison examines imaging performance, installation requirements, and integration capabilities to help integrators choose the right model for a given site.
In This Guide
How do the imaging specs compare?
Both cameras resolve at 2048×2048 (6MP), but their optical and sensor specs diverge. The XNF-8010RV specifies a 1/1.8" 6MP CMOS sensor, a 1.6mm f/1.6 fixed fisheye lens, and a 192° horizontal/vertical/diagonal field of view; minimum illumination is 0.1 Lux color and 0 Lux in IR mode. The XNF-A8014R specifies a 1.76mm fixed fisheye lens and a 185° horizontal and vertical field of view, but its image sensor size and minimum illumination figure are not stated in the provided specifications.
For IR performance the gap is substantial: the XNF-8010RV delivers 15m (49 ft) of infrared range, while the XNF-A8014R is specified at only 0.5m IR range. On dynamic range, the XNF-8010RV explicitly lists 120dB WDR with SSDR and BLC/HLC; the XNF-A8014R lists WDR as a feature but no dB figure is provided. The XNF-8010RV also specifies a maximum frame rate of 30fps; the A8014R's maximum frame rate is not stated in the provided specifications.
What about installation and environment?
The XNF-A8014R carries an IP42 rating (protected against solid objects >1mm and water dripping up to 15° from vertical), making it suitable for dry indoor ceilings only. Its power input is PoE+ (802.3at, Class 3); no DC voltage input is specified. Operating temperature range is not stated in the provided specifications. Weight is 2.2 lb.
The XNF-8010RV is rated IP66 (dust-tight, protected against powerful water jets) and IK10 (impact-resistant to 20 joules), qualifying it for outdoor and vandal-exposed installations. Power accepts either PoE (IEEE 802.3af, Class 3, max 12.95W) or 12VDC (max 12W), giving installers a redundant power option. Operating temperature is specified at -40°C to +55°C (-40°F to +131°F). Dimensions are Ø146×65.8mm and weight is 1.73 lb. The A8014R's PoE+ (802.3at) requirement means it draws more switch power budget than the 8010RV's 802.3af Class 3 specification.
Which fits your VMS and analytics better?
Both cameras support ONVIF and H.265/H.264/MJPEG compression. The XNF-8010RV additionally specifies ONVIF Profile S/G/T, SUNAPI (HTTP API), and Wisenet open platform; the A8014R lists ONVIF compatibility but profile levels (S/G/T) are not stated in the provided specifications. The XNF-8010RV supports up to 10 simultaneous streaming profiles, WiseStream II smart codec, CBR/VBR bitrate control, and a broad protocol suite including SNMPv1/v2c/v3, 802.1X (EAP-TLS, EAP-LEAP), SRTP, and IPv6; equivalent networking detail is not provided for the A8014R.
Analytics depth also differs significantly. The XNF-8010RV specifies eight analytics functions (directional detection, appear/disappear, enter/exit, loitering, tampering, virtual line, audio detection, sound classification) plus business intelligence features (people counting, queue management, heatmap), 8-zone polygonal motion detection, 32-zone privacy masking, and 1-in/1-out alarm I/O. It also includes built-in microphone input, line audio output, and two microSD slots supporting up to 512GB. The A8014R lists microSD storage support and HTTPS encryption; analytics capabilities, audio I/O, and alarm I/O are not detailed in the provided specifications.
Which should you choose: the A8014R or the XNF-8010RV?
Our take: The XNF-8010RV is the stronger choice when the installation is outdoor, vandal-exposed, or requires long-range IR coverage and deep on-camera analytics. Three concrete spec deltas illustrate this: IR range is 15m on the 8010RV versus 0.5m on the A8014R, making the 8010RV the only viable option for unlit or low-ambient-light scenes beyond arm's reach; IP/IK rating is IP66/IK10 versus IP42, a difference that determines whether the camera can be mounted outdoors or in washdown environments at all; and WDR is a documented 120dB on the 8010RV, while the A8014R's WDR is listed as a feature without a decibel value. The A8014R warrants consideration for indoor ceiling deployments where PoE+ infrastructure is already in place, exact sensor size and low-light figures are confirmed acceptable for the site, and the shorter 185° field of view is sufficient — but buyers should verify its unlisted illumination and temperature specs against site conditions before specifying.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Hanwha A8014R | Hanwha XNF-8010RV |
|---|---|---|
| Resolution | 6MP (2048×2048) | 6MP (2048×2048) |
| Image Sensor | Not specified | 1/1.8" 6MP CMOS |
| Lens / Focal Length | 1.76mm fixed fisheye | 1.6mm fixed fisheye |
| Max Aperture | Not specified | F1.6 |
| Field of View (H × V) | 185° × 185° | 192° × 192° × 192° (D) |
| Min. Illumination | Not specified | 0.1 Lux color / 0 Lux IR |
| IR Range | 0.5m | 15m (49 ft) |
| Wide Dynamic Range | WDR (dB not specified) | 120dB WDR |
| Max Frame Rate | Not specified | 30fps |
| Video Compression | H.265, H.264, MJPEG | H.265, H.264, MJPEG |
| IP Rating | IP42 | IP66 |
| IK / Impact Rating | Not specified | IK10 |
| Operating Temperature | Not specified | -40°C to +55°C |
| Power Input / PoE Class | PoE+ (802.3at) / Class 3 | PoE (802.3af) Class 3 or 12VDC |
| Edge Storage | microSD (capacity not specified) | Micro SD/SDHC/SDXC 2-slot, up to 512GB |
| Audio | Not specified | Mic/line in (built-in mic), line out |
| Alarm I/O | Not specified | 1 input / 1 output |
| Analytics | Not specified | Directional, loitering, enter/exit, people counting, heatmap, +more |
| Environment Rating | Indoor | Outdoor |
| Weight | 2.2 lb | 1.73 lb |
| Warranty | 5-year | 3-year |
Frequently Asked Questions
Which should you choose: the A8014R or the XNF-8010RV?
The XNF-8010RV is the stronger choice when the installation is outdoor, vandal-exposed, or requires long-range IR coverage and deep on-camera analytics. Three concrete spec deltas illustrate this: IR range is 15m on the 8010RV versus 0.5m on the A8014R, making the 8010RV the only viable option for unlit or low-ambient-light scenes beyond arm's reach; IP/IK rating is IP66/IK10 versus IP42, a difference that determines whether the camera can be mounted outdoors or in washdown environments at all; and WDR is a documented 120dB on the 8010RV, while the A8014R's WDR is listed as a feature without a decibel value. The A8014R warrants consideration for indoor ceiling deployments where PoE+ infrastructure is already in place, exact sensor size and low-light figures are confirmed acceptable for the site, and the shorter 185° field of view is sufficient — but buyers should verify its unlisted illumination and temperature specs against site conditions before specifying.
Is the XNF-A8014R or XNF-8010RV better for low-light surveillance?
Based on the provided specifications, the XNF-8010RV is the documented choice for low-light use: it specifies 0.1 Lux color sensitivity, 0 Lux in IR mode, and 15m of IR range. The XNF-A8014R lists built-in IR as a feature but specifies only a 0.5m IR range and does not state a minimum illumination figure, so its low-light performance in spaces larger than roughly 0.5m cannot be confirmed from the available specs.
Can the XNF-8010RV be installed outdoors while the A8014R cannot?
Yes. The XNF-8010RV carries an IP66 rating (dust-tight and protected against powerful water jets) and IK10 impact resistance, which are standard thresholds for outdoor and vandal-resistant installations. The XNF-A8014R is rated IP42, which provides only limited protection against solid objects and dripping water — the manufacturer's specification sheet designates it for indoor environments only.
Which camera offers more on-board analytics for retail or people-flow applications?
The XNF-8010RV specifies people counting, queue management, and heatmap as built-in business intelligence features, alongside eight video analytics functions including loitering, enter/exit, and directional detection. The XNF-A8014R's analytics capabilities are not detailed in the provided specifications, so a direct comparison on this point cannot be made from the available data.
