Geovision AVD270W-0010 vs Geovision BL110-D01: Specification Comparison
Both the Geovision AVD270W-0010 and the Geovision BL110-D01 are PoE-powered, bullet-form-factor IP cameras targeting fixed surveillance installations. The AVD270W-0010 is a 2MP (1080p) varifocal model with H.265 compression, while the BL110-D01 is a 1.3MP fixed-lens H.264 camera. Although they share the same brand, form factor, and general use case, they sit in adjacent—though overlapping—resolution classes (2MP vs. 1.3MP), making them a realistic cross-shop for buyers deciding between a legacy lower-resolution deployment and a current-generation upgrade.
In This Guide
How do the imaging specs compare?
The AVD270W-0010 delivers 1080p (2MP) resolution from a 1/2.8" sensor at up to 30 fps, paired with a varifocal 2.8–12mm lens that sweeps the field of view from approximately 108° down to 30° without an optic swap. It also includes WDR for high-contrast scenes and an IR Day/Night cut filter for low-light performance. The BL110-D01 is rated at 1.3MP; no sensor size, frame rate, lens focal length, WDR capability, or IR illumination data are provided in the available specifications.
On compression, the AVD270W-0010 uses H.265, which typically achieves 40–50% bitrate savings versus H.264 at equivalent quality. The BL110-D01 encodes in H.264 with dual-stream support, enabling independent bitrates for recording and live view—a practical feature for bandwidth-constrained networks. No H.265 or dual-stream capability is specified for the AVD270W-0010.
What about installation and environment?
The AVD270W-0010 carries IP67 and IK10 ratings, meaning it is protected against temporary immersion and resists 20-joule vandal impacts—suitable for perimeter and exposed locations. Its specified operating range is −40°C to 60°C, covering extreme cold and heat. It measures Φ120 × 334 mm and weighs 0.74 kg (1.63 lb). Mounting options include wall, ceiling, pole, pendant, corner, and rack configurations. Power is supplied via 802.3af PoE at under 13W.
The BL110-D01 is rated IP66, providing protection against powerful water jets but not immersion, and no IK impact rating is specified. No operating temperature range, physical dimensions, or weight are listed in the available specifications. Mounting is limited to wall and eave positions. Power is described as PoE, but the specific PoE standard and wattage are not stated. Two-way audio is noted for the BL110-D01; no audio capability is specified for the AVD270W-0010.
Which fits your VMS and analytics better?
Both cameras are documented as ONVIF-compatible, simplifying integration with third-party NVR and VMS platforms. The AVD270W-0010 is described as compatible with ONVIF-compliant IP-based VMS systems; the BL110-D01 is similarly listed as ONVIF-compliant with NVR/VMS platforms. Neither model has edge analytics, on-board storage, or SD card capability listed in the provided specifications.
The BL110-D01 includes two-way audio, which may be relevant for intercommunication or audio-event recording applications. No audio input or output is specified for the AVD270W-0010. Connectivity for the BL110-D01 is listed as Ethernet; the AVD270W-0010 specifies PoE as its connectivity method. No alarm I/O, analytics features, or proprietary VMS integrations are listed for either model in the available data.
Which should you choose: the AVD270W-0010 or the BL110-D01?
Our take: The AVD270W-0010 is the stronger choice when image quality, vandal resistance, and harsh-environment deployment are the primary requirements. It leads with a 2MP (1080p) sensor versus the BL110-D01's 1.3MP, adds H.265 compression for lower storage and bandwidth overhead compared to H.264, and holds an IK10 impact rating plus IP67 ingress protection against IP66 (and no IK rating) on the BL110-D01. Its −40°C to 60°C operating range is fully specified; no equivalent data is available for the BL110-D01. The varifocal 2.8–12mm lens also provides on-site FOV adjustment that a fixed-lens camera cannot match. The BL110-D01 offers two-way audio—absent from the AVD270W-0010's spec sheet—and dual-stream H.264, which may suit legacy VMS platforms or sites where audio intercommunication is required. Buyers on a tight budget replacing older 1.3MP infrastructure may find the BL110-D01 adequate, but the AVD270W-0010 represents a more capable and future-ready deployment.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Geovision AVD270W-0010 | Geovision BL110-D01 |
|---|---|---|
| Resolution | 2MP (1080p) | 1.3MP |
| Image Sensor Size | 1/2.8" | — |
| Lens / Focal Length | Varifocal 2.8–12mm | — |
| IR / Night Vision | IR; Day/Night ICR | — |
| WDR | Yes | — |
| Max Frame Rate | 30 fps | — |
| Video Compression | H.265 | H.264 (dual-stream) |
| IP Rating | IP67 | IP66 |
| IK / Impact Rating | IK10 | — |
| Operating Temperature | -40°C to 60°C | — |
| Power Input / PoE Standard | 802.3af (under 13W) | PoE (standard not specified) |
| Audio | — | Two-way |
| Mount Types | Wall; Ceiling; Pole; Pendant; Corner; Rack | Wall; Eave |
| Form Factor | Bullet | Bullet |
| VMS Compatibility | ONVIF-compatible IP-based VMS | ONVIF-compliant NVR/VMS |
| Dimensions | Φ120 × 334 mm (Φ4.72" × 13.15") | — |
| Weight | 0.74 kg (1.63 lb) | — |
Frequently Asked Questions
Which should you choose: the AVD270W-0010 or the BL110-D01?
The AVD270W-0010 is the stronger choice when image quality, vandal resistance, and harsh-environment deployment are the primary requirements. It leads with a 2MP (1080p) sensor versus the BL110-D01's 1.3MP, adds H.265 compression for lower storage and bandwidth overhead compared to H.264, and holds an IK10 impact rating plus IP67 ingress protection against IP66 (and no IK rating) on the BL110-D01. Its −40°C to 60°C operating range is fully specified; no equivalent data is available for the BL110-D01. The varifocal 2.8–12mm lens also provides on-site FOV adjustment that a fixed-lens camera cannot match. The BL110-D01 offers two-way audio—absent from the AVD270W-0010's spec sheet—and dual-stream H.264, which may suit legacy VMS platforms or sites where audio intercommunication is required. Buyers on a tight budget replacing older 1.3MP infrastructure may find the BL110-D01 adequate, but the AVD270W-0010 represents a more capable and future-ready deployment.
Is the AVD270W-0010 or BL110-D01 better for low light?
Only the AVD270W-0010 has documented IR illumination and a Day/Night ICR filter in the provided specifications. The BL110-D01 has no IR or low-light spec listed, so a direct comparison cannot be made from available data. If IR night vision is required, the AVD270W-0010 is the only confirmed option between these two.
Which camera is better suited for outdoor vandal-prone locations?
The AVD270W-0010 is rated IK10 (20-joule impact resistance) and IP67 (temporary immersion), making it the specified choice for vandal-prone or perimeter locations. The BL110-D01 carries IP66 for weather resistance but has no IK impact rating in the available specifications.
Can either camera be used with my existing H.264-based NVR?
Both cameras are listed as ONVIF-compliant, so either should integrate with an ONVIF-capable NVR regardless of compression preference. The BL110-D01 natively encodes H.264; the AVD270W-0010 uses H.265, but most current-generation NVRs support both codecs. Verify your NVR's H.265 decode capability before deploying the AVD270W-0010 on older hardware.
