Digital Watchdog DWC-MF5Wi4TW vs Digital Watchdog DWC-MV95Wi28TW: Specification Comparison
Both the Digital Watchdog DWC-MF5Wi4TW and DWC-MV95Wi28TW are 5MP fixed-lens outdoor vandal dome cameras sharing the same IK10 impact rating, Smart IR illumination, True WDR 120dB, and PoE power delivery. They target the same resolution tier and camera category, making them genuine cross-shop candidates for installers evaluating outdoor perimeter or facility surveillance. Key differentiators lie in IR range, minimum illumination, lens selection, operating temperature envelope, built-in analytics depth, and network protocol breadth.
In This Guide
How do the imaging specs compare?
Both cameras resolve 5MP at 2592×1944 pixels and deliver True WDR at 120dB, but their sensors and low-light performance differ. The DWC-MF5Wi4TW uses a 1/2.8" CMOS sensor with a color minimum illumination of 0.16 lux, while the DWC-MV95Wi28TW uses a slightly larger 1/2.7" CMOS sensor and achieves 0.02 lux in color—an 8× improvement in color sensitivity that is meaningful in dim parking lots or corridors where white-light supplemental lighting is absent.
Lens options also diverge significantly. The MF5Wi4TW ships in three fixed focal-length variants (4.0mm at 82.3° HFOV, 6.0mm at 51.9°, and 8.0mm at 37.8°), giving installers angle-of-view flexibility at ordering time. The MV95Wi28TW offers only two focal lengths (2.8mm at 98.5° HFOV and 3.6mm at 81.4°), both wide-angle, suiting broad coverage at entrances or corridors. IR range is a clear differentiator: the MF5Wi4TW reaches 50 feet with Smart IR™ compensation, whereas the MV95Wi28TW doubles that at 100 feet, making it better suited for longer aisles, driveways, or perimeter fence lines.
What about installation and environment?
Both domes carry IK10 vandal ratings and PoE power, but their environmental ratings differ by one grade: the MF5Wi4TW is rated IP66 (dust-tight, high-pressure water jet), while the MV95Wi28TW carries IP67 (dust-tight, temporary immersion to 1 meter). For most rooftop or wall-mount outdoor deployments either rating is adequate, but the IP67 on the MV95Wi28TW provides additional margin in drainage channels, loading docks, or regions with heavy driving rain.
Operating temperature range is a meaningful installation differentiator. The MF5Wi4TW is specified from -4°F to 122°F (-20°C to 50°C), while the MV95Wi28TW extends to -22°F to 140°F (-30°C to 60°C), adding 18°F on the cold end and 18°F on the hot end—relevant for unheated northern climates or sun-baked enclosures. PoE power draw is comparable: MF5Wi4TW draws up to 7.2W (PoE Class 3); MV95Wi28TW draws up to 6.0W (PoE class not stated in provided specs). The MF5Wi4TW is smaller at 4.92"×1.88" and lighter at 0.88 lbs, versus the MV95Wi28TW at 4.59"×3.54" and 1.43 lbs; both mount via accessories sold separately.
Which fits your VMS and analytics better?
The MF5Wi4TW supports ONVIF-compatible CMS and includes the Genetec Protocol natively in its listed protocol stack, alongside SNMPv1/v2/v3 (MIB-2), Bonjour, Zeroconf/AutoIP, and Telnet. Its on-board IVA license covers intrusion, line crossing, counting line, loitering, enter/exit, tamper; an optional IVA+ license (noted for the MPF5Wi variants, not the MF5Wi4TW itself per specs) adds logical rules, object removed, tailgating, direction, stopped, appear/disappear, and object left. It supports 16 programmable privacy masks. The MV95Wi28TW's listed compatible VMS includes DW Spectrum, ExacqVision, and Milestone by name, and it adds IPv6, PPPoE, QoS, FTP, SMTP, ICMP, RTCP to its protocol stack. Its built-in analytics cover Object Classification (human vs. object differentiation), Line Crossing, Perimeter Intrusion, and Video Tampering Detection (scene change, blur, abnormal color)—all without an additional license per the provided specs.
On audio, the MF5Wi4TW provides one audio in/one audio out with G.711 compression; the MV95Wi28TW matches that I/O count but adds a built-in microphone and supports both G.711A and G.711U variants. Both offer Micro SD/SDHC/SDXC edge storage up to 1TB, dual-stream capability, and up to 30fps at all resolutions. The MF5Wi4TW adds alarm output notification and SD card recording notification to its operational alerts, while the MV95Wi28TW specifies Email and FTP server notifications. Both carry a 5-year warranty.
Which should you choose: the DWC-MF5Wi4TW or the DWC-MV95Wi28TW?
Our take: The DWC-MV95Wi28TW is the stronger choice when IR range, low-light color performance, or extreme-temperature operation are primary requirements. Its 100-foot Smart IR range doubles the MF5Wi4TW's 50-foot reach, its 0.02 lux color sensitivity is 8× better than the MF5Wi4TW's 0.16 lux, and its -22°F to 140°F operating range extends 18°F beyond the MF5Wi4TW in both directions—critical for unheated outdoor enclosures in cold climates. The MV95Wi28TW also carries IP67 versus IP66, adds a built-in microphone, and names DW Spectrum, ExacqVision, and Milestone VMS compatibility explicitly. Conversely, the DWC-MF5Wi4TW offers three focal-length options (4mm, 6mm, 8mm) versus two wide-angle-only choices on the MV95Wi28TW, includes Genetec Protocol natively, supports 16 privacy masks versus 4, and provides a local CVBS test output useful during commissioning. Choose the MF5Wi4TW where tighter focal-length control, a CVBS commissioning output, or Genetec-native integration is required on a standard outdoor installation.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Digital Watchdog DWC-MF5Wi4TW | Digital Watchdog DWC-MV95Wi28TW |
|---|---|---|
| Max Resolution | 5MP (2592 × 1944) | 5MP (2592 × 1944) |
| Image Sensor | 1/2.8" CMOS | 1/2.7" CMOS |
| Lens / Focal Length | 4.0mm, 6.0mm, 8.0mm Fixed | 2.8mm, 3.6mm Fixed |
| Horizontal FOV | 82.3° / 51.9° / 37.8° | 98.5° / 81.4° |
| Min Illumination (Color) | 0.16 lux | 0.02 lux |
| Min Illumination (B/W) | 0.0 lux | 0.0 lux |
| IR Range | 50 ft (Smart IR™) | 100 ft (Smart IR™) |
| Wide Dynamic Range | True WDR 120dB | True WDR 120dB |
| Max Frame Rate | 30fps at all resolutions | 30fps at all resolutions |
| Video Compression | H.264, H.265, MJPEG | H.264, H.265, MJPEG |
| IP Rating | IP66 | IP67 |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) | -22°F to 140°F (-30°C to 60°C) |
| Power Input / Max Draw | PoE Class 3, max 7.2W; DC12V max 5.9W | PoE, max 6.0W; DC12V max 6.0W |
| Edge Storage | Micro SD/SDHC/SDXC up to 1TB | Micro SD/SDHC/SDXC up to 1TB |
| Audio | 1 in / 1 out, G.711 | 1 in / 1 out + built-in mic, G.711A/U |
| Privacy Masks | 16 programmable | 4 programmable |
| Built-in Analytics | IVA license: intrusion, line crossing, counting line, loitering, enter/exit, tamper | Object Classification (human vs. object), Line Crossing, Perimeter Intrusion, Video Tampering Detection |
| Named VMS Compatibility | ONVIF CMS, Genetec Protocol (native) | ONVIF, DW Spectrum, ExacqVision, Milestone |
| Local Video Output | CVBS 1.0V p-p (75Ω) | — |
| IP Protocol | IPv4 | IPv4, IPv6 |
| Dimensions (H × W) | 4.92" × 1.88" (125 × 48 mm) | 4.59" × 3.54" (116.6 × 90 mm) |
| Weight | 0.88 lbs (0.4 kg) | 1.43 lbs (0.65 kg) |
| Warranty | 5 Year | 5 Year |
Frequently Asked Questions
Which should you choose: the DWC-MF5Wi4TW or the DWC-MV95Wi28TW?
The DWC-MV95Wi28TW is the stronger choice when IR range, low-light color performance, or extreme-temperature operation are primary requirements. Its 100-foot Smart IR range doubles the MF5Wi4TW's 50-foot reach, its 0.02 lux color sensitivity is 8× better than the MF5Wi4TW's 0.16 lux, and its -22°F to 140°F operating range extends 18°F beyond the MF5Wi4TW in both directions—critical for unheated outdoor enclosures in cold climates. The MV95Wi28TW also carries IP67 versus IP66, adds a built-in microphone, and names DW Spectrum, ExacqVision, and Milestone VMS compatibility explicitly. Conversely, the DWC-MF5Wi4TW offers three focal-length options (4mm, 6mm, 8mm) versus two wide-angle-only choices on the MV95Wi28TW, includes Genetec Protocol natively, supports 16 privacy masks versus 4, and provides a local CVBS test output useful during commissioning. Choose the MF5Wi4TW where tighter focal-length control, a CVBS commissioning output, or Genetec-native integration is required on a standard outdoor installation.
Is the DWC-MF5Wi4TW or DWC-MV95Wi28TW better for low-light color imaging?
The DWC-MV95Wi28TW is significantly better in low light. Its specified color minimum illumination is 0.02 lux, compared to 0.16 lux for the DWC-MF5Wi4TW—an 8× advantage in color sensitivity before the IR cuts in. Both reach 0.0 lux in black-and-white mode with IR active.
Which camera covers a longer distance at night?
The DWC-MV95Wi28TW, with its 100-foot Smart IR™ range, covers twice the nighttime distance of the DWC-MF5Wi4TW, which is rated at 50 feet. Both use Smart IR compensation to avoid overexposure on near subjects.
Can I use either camera with Genetec or Milestone VMS?
The DWC-MF5Wi4TW lists Genetec Protocol explicitly in its protocol stack and is ONVIF compatible, which covers most modern VMS platforms including Milestone. The DWC-MV95Wi28TW lists Milestone, ExacqVision, and DW Spectrum by name in its spec sheet and is also ONVIF compatible, but Genetec Protocol is not listed in the provided specifications for that model. If Genetec native integration is required, the MF5Wi4TW is the documented choice.
