CipherLab A2200NBUN0001 vs CipherLab A2564S2BKU0S1: Specification Comparison
Both the CipherLab A2200NBUN0001 and CipherLab A2564S2BKU0S1 are handheld barcode scanners in the same general device class, but they differ meaningfully in scan engine (2D imager vs. 1D linear imager) and connectivity (USB-corded vs. Bluetooth wireless). Buyers cross-shopping these two models are typically weighing 2D code capture capability and wired reliability against wireless mobility and 1D-optimized performance. This comparison covers scan engine capability, environmental durability, and connectivity and workflow fit—the three axes most likely to drive the purchase decision.
In This Guide
Which scanner handles the barcodes you actually need to read?
The A2200NBUN0001 uses a 2D scan engine and captures a broad symbology set spanning both 1D and 2D codes: QR Code, Data Matrix, PDF417, Aztec, MaxiCode, Micro QR Code, MicroPDF417, HanXin, Composite Codes, and a full 1D roster including Code 39, Code 128, UPC/EAN, GS1-128, Codabar, Interleave 2 of 5, ISBT-128, Italian and French Pharmacode, Matrix 2 of 5, MSI, Plessey, Telepen, Code 11, and Chinese 2 of 5. The scan pattern is presentation mode, meaning it is optimized for items presented to the scanner face—common in retail or healthcare check-in environments.
The A2564S2BKU0S1 uses a 1D linear imager with a 3 mil baseline resolution and a rated scan rate of 578 scans per second. Its symbology support is limited to 1D codes: Codabar, Code 39/93/128, GS1 DataBar (RSS), UPC/EAN/GS1-128, Industrial 2 of 5, Interleave 2 of 5, ISBT-128, Italian and French Pharmacode, Matrix 2 of 5, MSI, Plessey, Telepen, and Code 11. It cannot read 2D codes (QR, Data Matrix, PDF417, Aztec, etc.). Its 3 mil resolution is suited to high-density or degraded 1D labels. The A2200NBUN0001 spec does not state a discrete scan rate; the A2564S2BKU0S1 spec does not state minimum print contrast for the A2200NBUN0001 (the 15% figure is specific to the A2564S2BKU0S1).
Which unit holds up better in demanding physical environments?
The A2200NBUN0001 carries an IP52 rating—protected against limited dust ingress (no full dust-tight seal) and dripping water from a vertical direction. It is also rated for 1.5 m multiple drops onto concrete. Its storage temperature range is −40 °C to 60 °C (−40 °F to 140 °F). Physical dimensions are 83 × 80 × 150 mm and weight is stated at 320 g / 11 oz (with an additional figure of 380 g / 13 oz also listed in the specs, likely with cable or cradle).
The A2564S2BKU0S1 carries an IP65 rating—fully dust-tight and protected against water jets from any direction. IP65 is a materially higher ingress protection level than IP52 and is appropriate for washdown, outdoor, or consistently wet environments such as food processing, cold-chain logistics, or outdoor receiving docks. The A2564S2BKU0S1 spec does not state a drop rating, storage temperature range, or physical weight, so those comparisons cannot be made from the provided data.
Which scanner fits your cabling, mobility, and deployment workflow?
The A2200NBUN0001 connects via USB (corded). The spec lists an input voltage of 5 V, 2 A max, consistent with bus-powered USB operation. The scan pattern is presentation mode, making it most appropriate for fixed-station or countertop deployments where items are brought to the scanner. No wireless capability is specified.
The A2564S2BKU0S1 connects via Bluetooth wireless. This enables untethered operation across warehouse aisles, loading docks, or point-of-sale floors where workers move with the scanner rather than presenting items to a fixed station. Scan modes include auto-sense and continuous, offering more flexible activation options than a single presentation mode. The spec does not state battery capacity, Bluetooth version, or wireless range, so those parameters cannot be compared from the provided data. The A2564S2BKU0S1 is also available in two colors (Black and Register White) versus Black only for the A2200NBUN0001.
Which should you choose: the A2200NBUN0001 or the A2564S2BKU0S1?
Our take: The A2200NBUN0001 is the stronger choice when your workflow requires reading 2D codes—QR, Data Matrix, PDF417, Aztec, or Composite—at a fixed USB-connected station with moderate environmental demands. Its 2D engine covers every symbology the A2564S2BKU0S1 handles plus a wide 2D set the A2564S2BKU0S1 cannot read at all, and its 1.5 m concrete-drop rating provides a documented durability benchmark the A2564S2BKU0S1 spec does not supply. Conversely, the A2564S2BKU0S1 is the stronger choice for mobile, 1D-only workflows: its IP65 rating (versus IP52) makes it the correct pick for dusty, wet, or outdoor environments, and Bluetooth wireless eliminates cable management constraints in high-movement roles such as warehouse receiving or floor inventory. Buyers running exclusively 1D labels in harsh or mobile environments should favor the A2564S2BKU0S1; buyers needing 2D code capture or working at a fixed USB station should favor the A2200NBUN0001.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | CipherLab A2200NBUN0001 | CipherLab A2564S2BKU0S1 |
|---|---|---|
| Product Type | 2D Barcode Scanner | 1D Linear Imager Barcode Scanner |
| Scan Engine | 2D imager | 1D linear imager, 3 mil baseline resolution |
| Connectivity | USB (corded) | Bluetooth wireless |
| Form Factor | Handheld | Handheld |
| IP Rating | IP52 | IP65 |
| Drop Rating | 1.5 m multiple drops onto concrete | — |
| Scan Rate | — | 578 scans/second |
| Scan Modes | Presentation mode | Auto-sense and continuous |
| 2D Symbologies | QR Code, Data Matrix, PDF417, Aztec, MaxiCode, Micro QR, MicroPDF417, HanXin, Composite | None (1D only) |
| 1D Symbologies | Code 39, Code 128, UPC/EAN, GS1-128, Codabar, I 2 of 5, ISBT-128, Pharmacode, MSI, Plessey, Telepen, Code 11, Chinese 2 of 5, and more | Codabar, Code 39/93/128, GS1 DataBar, UPC/EAN, MSI, Plessey, Telepen, ISBT-128, Pharmacode, Code 11 |
| Min Print Contrast | — | 15% |
| Scan Range (Code 39) | — | 3 mil: 3–10 cm; 5 mil: 2–14 cm; 20 mil: 1.5–60 cm |
| Color Options | Black | Black, Register White |
| Weight | 320 g / 11 oz (380 g / 13 oz with accessory) | — |
| Dimensions | 83 × 80 × 150 mm (3.3 × 3.2 × 5.9 in) | — |
| Input Voltage | 5 V, 2 A max | — |
| Storage Temperature | −40 °C to 60 °C (−40 °F to 140 °F) | — |
| Warranty | 2-Year | 2-Year |
Frequently Asked Questions
Which should you choose: the A2200NBUN0001 or the A2564S2BKU0S1?
The A2200NBUN0001 is the stronger choice when your workflow requires reading 2D codes—QR, Data Matrix, PDF417, Aztec, or Composite—at a fixed USB-connected station with moderate environmental demands. Its 2D engine covers every symbology the A2564S2BKU0S1 handles plus a wide 2D set the A2564S2BKU0S1 cannot read at all, and its 1.5 m concrete-drop rating provides a documented durability benchmark the A2564S2BKU0S1 spec does not supply. Conversely, the A2564S2BKU0S1 is the stronger choice for mobile, 1D-only workflows: its IP65 rating (versus IP52) makes it the correct pick for dusty, wet, or outdoor environments, and Bluetooth wireless eliminates cable management constraints in high-movement roles such as warehouse receiving or floor inventory. Buyers running exclusively 1D labels in harsh or mobile environments should favor the A2564S2BKU0S1; buyers needing 2D code capture or working at a fixed USB station should favor the A2200NBUN0001.
Can the A2564S2BKU0S1 read QR codes or Data Matrix labels?
No. The A2564S2BKU0S1 is a 1D linear imager and its specified symbology list contains only 1D codes (Code 39, Code 128, UPC/EAN, GS1 DataBar, etc.). It cannot read 2D symbologies such as QR Code, Data Matrix, PDF417, or Aztec. If your labels include any 2D codes, the A2200NBUN0001 with its 2D scan engine is the appropriate choice.
Is the A2200NBUN0001 or A2564S2BKU0S1 better for food processing or outdoor receiving where the scanner may get wet?
The A2564S2BKU0S1 is the more appropriate choice for those environments. It carries an IP65 rating, meaning it is fully dust-tight and protected against water jets from any direction. The A2200NBUN0001 is rated IP52, which provides only limited dust protection and protection against vertical dripping water—not sufficient for washdown or sustained water exposure.
Can I use either scanner without a cable connected to a host computer?
Only the A2564S2BKU0S1 supports wireless operation; its spec lists Bluetooth as its connectivity method, allowing untethered use. The A2200NBUN0001 is a USB-corded scanner with no wireless capability specified, so it requires a physical connection to a host at all times.
