Bosch NDE-8702-RX vs Bosch NDV-5702-A: Specification Comparison
Both the Bosch NDE-8702-RX FLEXIDOME 8100i and the NDV-5702-A are 2MP fixed dome network cameras sharing the same resolution class, frame rate, and compression suite. The comparison is relevant for buyers deciding between an outdoor-rated vandal-resistant unit and an indoor-optimized model within the same Bosch IP camera ecosystem. Key differentiators span sensor size, low-light sensitivity, environmental ratings, operating temperature range, impact protection, and analytics depth.
In This Guide
How do the imaging specs compare?
The NDE-8702-RX uses a larger 1/1.8" CMOS sensor versus the NDV-5702-A's 1/2.8" CMOS. That sensor size advantage translates directly into low-light performance: the NDE-8702-RX achieves 0.009 Lux color / 0.0007 Lux B/W, while the NDV-5702-A requires 0.021 Lux color / 0.004 Lux B/W — roughly 2.3× less sensitive in color and 5.7× less sensitive in B/W mode. Both cameras deliver 1920×1080 at 60 fps.
On dynamic range, the NDV-5702-A edges ahead at 144 dB WDR versus 141 dB for the NDE-8702-RX — a marginal 3 dB difference that is unlikely to be perceptible in most deployments. The NDE-8702-RX covers a 4.4–10 mm varifocal range; the NDV-5702-A offers a slightly wider 3.2–10.5 mm range, providing more flexibility at the wide end for tighter spaces. Both include Day/Night with integrated IR illumination. Both support H.265, H.264, and MJPEG with 4 simultaneous streams.
What about installation and environment?
The NDE-8702-RX is rated for outdoor deployment with IP66 ingress protection and IK11 impact resistance — the highest standard IK rating, designed to withstand significant mechanical shock. Its operating temperature spans -50°C to +60°C (-58°F to +140°F), making it suitable for extreme cold or heat environments. The NDV-5702-A is rated for indoor use with IP54 and IK10 impact protection, and operates between -20°C and +50°C (-4°F to +122°F) — a substantially narrower thermal envelope.
Both cameras are specified as PoE+ (802.3at) per the product data, though the NDV-5702-A datasheet additionally notes ~13W draw compatible with 802.3af. Mount options for the NDE-8702-RX include wall, ceiling, pole, pendant, and rack; the NDV-5702-A adds a corner mount option. The NDV-5702-A body is specified as polycarbonate and described as re-paintable. Physical dimensions are provided only for the NDV-5702-A: 148 mm diameter × 122 mm height, 920 g. No dimensions or weight are listed in the provided specs for the NDE-8702-RX.
Which fits your VMS and analytics better?
Both cameras are ONVIF-compliant and NDAA-compliant, and both support cloud connectivity and local microSD/SDHC/SDXC storage. The NDE-8702-RX carries a broader analytics package: IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy, plus a specified Deep Learning Processing Unit (DLPU) and the Trainer function. The NDV-5702-A supports IVA Pro Buildings and IVA Pro Privacy, but IVA Pro Perimeter is not listed in its provided specs — a meaningful gap for outdoor perimeter detection use cases.
On audio, both include a built-in microphone. The NDV-5702-A is additionally specified with two-way audio capability; no two-way audio is listed for the NDE-8702-RX in the provided specs. The NDV-5702-A lists explicit encryption protocols (TLS 1.2, TLS 1.3, AES 256, AES 128) and ONVIF Profile T. The NDE-8702-RX lists a crypto coprocessor (TPM) with RSA 4096-bit and AES/CBC 256-bit — a hardware security differentiator not present in the NDV-5702-A specs. The NDV-5702-A notes ONVIF Profile T and Auto-MDIX; equivalent ONVIF profile detail is not specified for the NDE-8702-RX.
Which should you choose: the NDE-8702-RX or the NDV-5702-A?
Our take: The NDE-8702-RX is the stronger choice when the deployment environment is outdoor, subject to vandalism, or exposed to extreme temperatures. It delivers a 2.3× low-light advantage in color (0.009 vs 0.021 Lux) and a 5.7× advantage in B/W (0.0007 vs 0.004 Lux), carries IK11 versus IK10 impact protection, and operates across a -50°C to +60°C range versus -20°C to +50°C. It also adds IVA Pro Perimeter analytics and a hardware TPM crypto coprocessor. The NDV-5702-A is the appropriate selection for controlled indoor environments where its marginally wider 3.2–10.5 mm lens range, 144 dB WDR (vs 141 dB), two-way audio, and re-paintable polycarbonate housing are valued, and where the narrower thermal and IP/IK ratings are acceptable. Platform integrators should note that only the NDV-5702-A explicitly lists ONVIF Profile T in the provided specs.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Bosch NDE-8702-RX | Bosch NDV-5702-A |
|---|---|---|
| Resolution | 2MP (1920×1080) | 2MP (1920×1080) |
| Max Frame Rate | 60 fps @ 1080p | 60 fps @ 1080p |
| Image Sensor | 1/1.8" CMOS | 1/2.8" CMOS |
| Lens / Focal Length | Varifocal 4.4–10 mm | Varifocal 3.2–10.5 mm |
| Min. Illumination (Color / B/W) | 0.009 Lux / 0.0007 Lux | 0.021 Lux / 0.004 Lux |
| Wide Dynamic Range | 141 dB | 144 dB |
| Video Compression | H.265, H.264, MJPEG | H.265, H.264, MJPEG |
| Multi-Streaming | 4 streams | 4 streams |
| IP Rating | IP66 | IP54 |
| IK / Impact Rating | IK11 | IK10 |
| Operating Temperature | -50°C to +60°C (-58°F to +140°F) | -20°C to +50°C (-4°F to +122°F) |
| Environment Rating | Outdoor | Indoor |
| Power Input / PoE Class | PoE+ (802.3at) | PoE+ (802.3at); ~13W (802.3af compatible) |
| Edge Storage | microSD/SDHC/SDXC | microSD/SDHC/SDXC |
| Audio | Built-in microphone (audio in) | Two-way audio |
| Video Analytics | IVA Pro Buildings, IVA Pro Perimeter, IVA Pro Privacy; DLPU | IVA Pro Buildings, IVA Pro Privacy |
| ONVIF | Yes | Profile T; Auto-MDIX |
| NDAA Compliant | Yes | Yes |
| Hardware Security | TPM crypto coprocessor; RSA 4096-bit; AES/CBC 256-bit | TLS 1.2; TLS 1.3; AES 256; AES 128 |
| Dimensions (Ø × H) | — | 148 mm × 122 mm |
| Weight | — | 920 g |
| Warranty | Manufacturer Warranty | Manufacturer Warranty |
Frequently Asked Questions
Which should you choose: the NDE-8702-RX or the NDV-5702-A?
The NDE-8702-RX is the stronger choice when the deployment environment is outdoor, subject to vandalism, or exposed to extreme temperatures. It delivers a 2.3× low-light advantage in color (0.009 vs 0.021 Lux) and a 5.7× advantage in B/W (0.0007 vs 0.004 Lux), carries IK11 versus IK10 impact protection, and operates across a -50°C to +60°C range versus -20°C to +50°C. It also adds IVA Pro Perimeter analytics and a hardware TPM crypto coprocessor. The NDV-5702-A is the appropriate selection for controlled indoor environments where its marginally wider 3.2–10.5 mm lens range, 144 dB WDR (vs 141 dB), two-way audio, and re-paintable polycarbonate housing are valued, and where the narrower thermal and IP/IK ratings are acceptable. Platform integrators should note that only the NDV-5702-A explicitly lists ONVIF Profile T in the provided specs.
Is the NDE-8702-RX or NDV-5702-A better for low-light performance?
The NDE-8702-RX is significantly better in low light. It achieves 0.009 Lux color and 0.0007 Lux B/W, compared to 0.021 Lux color and 0.004 Lux B/W for the NDV-5702-A. The NDE-8702-RX's larger 1/1.8" sensor versus the NDV-5702-A's 1/2.8" sensor is the primary driver of this difference.
Can the NDV-5702-A be used outdoors?
Based on the provided specifications, no. The NDV-5702-A is rated for indoor use with IP54 ingress protection and an operating range of -20°C to +50°C. The NDE-8702-RX is the outdoor-rated model, carrying IP66 and IK11 ratings with a -50°C to +60°C operating range.
Does either camera support two-way audio?
The NDV-5702-A is specified with two-way audio. The NDE-8702-RX lists a built-in microphone (audio in) but two-way audio output capability is not stated in the provided specifications. Verify with Bosch documentation before specifying the NDE-8702-RX for applications requiring two-way audio.
