IP Camera Accessories | Mounts, Enclosures, Lenses, IR & Power

Deployment Considerations

Environmental protection and weather resistance
Mounting stability and load support
Power and voltage compatibility
Cable management and termination quality
Compliance with local safety standards

Sub categories

Showing Results for Accessories

Compare

Out of stock
Geovision

SKU: 54-MT21000-SD00

Geovision 54-MT21000-SD00 GV-MOUNT 210 Mounting Bracket

Wall/ceiling mount bracket for Geovision IP PTZ cameras indoors and out
- Industrial-grade metal construction rated for outdoor environments
- Fits standard surveillance mounting infrastructure for PTZ deployment
- Lightweight at 2.65 lb; compact 13" × 6" × 9" form factor
Special Order · Ships in 2-3 weeks

$96.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 55-800EX-160

Geovision 55-800EX-160 GV-800 Express 16-Card System

16-card expansion module for GV-800 Express mid-to-large surveillance
- Scales recording and video analytics capacity across ONVIF IP cameras
- D-type module architecture integrates directly into GV-800 Express chassis
- Supports multi-camera deployments with modular expansion infrastructure
Special Order · Ships in 2-3 weeks

$548.99 $537.99 Save $11.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-D7H05-WBM

Geovision 81-D7H05-WBM Wall Box Mount

Metal wall box mount for fixed indoor Geovision camera installations
- Wall-mounted bracket supports stable, fixed camera positioning indoors
- Metal construction designed for Geovision surveillance system compatibility
- Lightweight at 1.0 lbs for straightforward installation on vertical surfaces
Special Order · Ships in 2-3 weeks

$97.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-MA13560-F081

Geovision 81-MA13560-F081 13.56MHz RFID Card Module

13.56MHz RFID module for access control panels, Mifare & ISO compatible
- Reads Mifare Classic, DESFire, and ISO 15693 cards at 13.56MHz ISO/IEC 14443 Type A
- Thin 0.05-inch profile fits space-constrained door readers and panel mounts
- OEM module integrates directly into third-party access control systems and intercoms
Special Order · Ships in 2-3 weeks

$3.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-MT100-000

Geovision 81-MT100-000 GV-MOUNT 100 Straight Tube

Straight tube mount for Geovision thermal cameras indoors and out
- Tube and junction design supports flexible thermal camera positioning
- Works with Geovision thermal imaging systems for standard installations
- White housing, 200 x 170 x 257.5 mm, rated for outdoor environments
Special Order · Ships in 2-3 weeks

$148.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-MT203-000

Geovision 81-MT203-000 GV-MOUNT 203 Wall Pendant Tube

Wall pendant tube mount for Geovision thermal imaging systems
- Pendant-style wall mount designed for thermal camera deployment
- Tube construction for indoor and protected environment installation
- Compatible with Geovision thermal imaging product lines
Special Order · Ships in 2-3 weeks

$127.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-MT21220-0001

Geovision 81-MT21220-0001 Wall-Ceiling Box Mount

Wall and ceiling box mount for IP PTZ cameras with integrated cable management
- Supports both wall and ceiling installation without requiring separate hardware
- Box bracket design handles motorized pan-tilt mechanisms and optical zoom weight
- Universal ONVIF-compliant mounting pattern fits standard IP PTZ camera interfaces
Special Order · Ships in 2-3 weeks

$25.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-MT300-000

Geovision 81-MT300-000 GV-MOUNT 300 Convex Corner Adapter

Convex corner adapter for Geovision cameras in indoor perimeter coverage
- White corner mount positions cameras on architectural edges for broader coverage
- Compatible with Geovision camera systems and standard mounting hardware
- Designed for indoor and controlled installation environments
Special Order · Ships in 2-3 weeks

$63.99

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: 81-PT135TG-0001

Geovision 81-PT135TG-0001 13.56MHz On-Metal RFID Tag

13.56MHz RFID stick tags engineered for reliable reads on metal surfaces
- On-metal design eliminates read failures on metallic equipment and asset surfaces
- 13.56MHz ISO/IEC 14443A frequency compatible with standard HF RFID readers
- 8-pack adhesive-backed stick tags for rapid deployment across access control zones
Special Order · Ships in 2-3 weeks

$53.99 $52.99 Save $1.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-1120B

Geovision GV-1120B 16-Channel 1.3MP System

16-channel 1.3MP analog capture card for PC-based surveillance
- 16 simultaneous CVBS channels at 1.3MP (1280×1024) per feed
- Real-time processing without frame loss on internal capture card
- Integrates with Geovision GV-Center VMS and standard PC workstations
Special Order · Ships in 2-3 weeks

$647.99 $634.99 Save $13.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-1240B

Geovision GV-1240B 16-Channel Promotion Package

16-channel H.265 system package for retail, corporate, and education
- 16-channel capacity with H.265 compression for medium-scale deployments
- Motion detection, tampering alerts, and scene-change analytics built in
- ONVIF, Milestone, and Genetec compatible with TLS/SSL encryption
Special Order · Ships in 2-3 weeks

$747.99 $732.99 Save $15.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-5016-95

Geovision GV-5016 16-Channel 480FPS Display Module

16-channel 480FPS display module for Geovision DVR expansion
- 480FPS aggregate processing across 16 channels with H.264 compression
- Dedicated display processing reduces DVR CPU load in multi-channel setups
- PCI-E x1 interface with 2GB dual-channel memory for real-time monitoring
Special Order · Ships in 2-3 weeks

$1,600.00 $1,072.99 Save $527.01

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-5016

Geovision GV-5016 16-Channel PCI Express Card

16-channel PCI Express capture card for multi-camera surveillance systems
- 16-channel simultaneous video capture via PCI Express interface
- LFH connectors for compact installation in standard server chassis
- Works with Geovision recording and management software platforms
Special Order · Ships in 2-3 weeks

$1,094.99 $1,072.99 Save $22.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-600-55

Geovision GV-600 16-Channel DVI PCI Card

16-channel PCI card for analog CCTV capture with H.265 compression
- Captures 16 simultaneous video streams via DVI analog input in single PCI slot
- H.265 compression reduces file sizes for efficient storage and bandwidth use
- Integrates with Geovision DVR systems and standard PCI surveillance servers
Special Order · Ships in 2-3 weeks

$174.99 $171.99 Save $3.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-650-55

Geovision GV-650 Composite Video Input Adapter

Composite video adapter bridges legacy analog cameras to Geovision DVR/NVR
- Integrates older CVBS composite sources into modern Geovision systems
- White connector adapter for cost-effective retrofit without replacing cameras
- Compatible with Geovision DVR and NVR platforms supporting analog input
Special Order · Ships in 2-3 weeks

$398.99 $390.99 Save $8.00

Add to Cart
The item has been added
Compare

Out of stock
Geovision

SKU: GV-650

Geovision GV-650 GV-650 Express D Type 8 Card

Type 8 expansion card for GV-650 EXPRESS surveillance systems
- Adds camera channels and recording capacity to existing GV-650 setups
- H.264 compression at 60 fps (NTSC) / 50 fps (PAL) with audio input
- Requires professional installation in GV-650 chassis expansion slot
Special Order · Ships in 2-3 weeks

$298.99 $293.99 Save $5.00

Add to Cart
The item has been added

What to Look For When Buying

The six decisions that matter most before you spec.

Match Bracket to Camera + Surface

A dome camera mounted on a textured wall needs a wall-mount adapter with a gasket; mounted on a pole it needs a pole-mount arm; mounted on an eave it may need a pendant. Third-party brackets exist but brand-specific brackets include proper camera cable routing and weather gasketing. Buying a $40 generic bracket to save on a $80 Axis bracket usually costs more in installation time.

Enclosure NEMA Rating

NEMA 3R = light rain; NEMA 4 = splash + driving rain; NEMA 4X = above + corrosion resistance (coastal, industrial); NEMA 6 = temporary submersion. For weather-exposed camera enclosures, NEMA 4X is the commercial standard. For mission-critical outdoor gear, pair NEMA 4X enclosure + IP67 camera + IK10 vandal rating.

C/CS-Mount Lens Selection

Box cameras use interchangeable C-mount (17.526mm flange) or CS-mount (12.5mm flange). Lens focal length + sensor size determines field of view: a 4mm lens on a 1/3" sensor gives ~60° horizontal FOV. Our DORI guide covers lens selection by scene distance. F-stop matters for low-light; P-iris for auto-exposure.

IR Illuminator Wavelength

850nm IR is more efficient but produces a faint visible red glow (deterrent or accidental giveaway, depending on use case). 940nm is truly covert but requires ~2x the power for the same effective range, and many cameras have lower sensitivity at 940nm. Match illuminator wavelength to camera IR-cut filter spec, or image washout results.

Power Supply Sizing & Distance

12VDC cameras at 100ft from a power supply drop significant voltage over 18-gauge wire — a camera rated for 12V may see 10.5V at the camera end under load, triggering brownout resets. For long runs, use a higher-voltage power supply (24VAC or 48VDC) and step down at the camera. UL-listed surveillance power supplies (Altronix) publish voltage-drop tables.

Cable Jacket Rating

Indoor Cat6 is rated CM (communications); plenum-rated CMP is required for above-drop-ceiling runs per NFPA 70. Outdoor/direct-burial Ethernet is a different product (CMX, direct-burial gel-filled). Mixing jacket ratings causes code violations and fire inspector rejections. Always spec by run environment, not lowest-cost SKU.

Technology Stack

The specs and acronyms that actually affect outdoor performance.

NEMA vs IP Rating Systems

NEMA is the US enclosure standard (NEMA 1-13); IP is the international standard (IP00-IP68). Rough crosswalk: NEMA 4 ≈ IP66, NEMA 4X ≈ IP66 + corrosion, NEMA 6 ≈ IP67. Some spec sheets list both; when only one is given, the crosswalk is approximate. For coastal, industrial, and food-processing environments, specify NEMA 4X or IP66 + stainless steel.

C-Mount vs CS-Mount Lenses

C-mount: 17.526mm flange focal distance. CS-mount: 12.5mm flange. CS cameras accept both lens types (C lenses need a 5mm adapter ring); C cameras accept only C lenses. Most modern box cameras are CS-mount for lens flexibility. Lens thread is 1-inch × 32 TPI on both.

F-Stop / Iris

F-stop = focal length ÷ aperture diameter. Lower F-stop (wider aperture) means more light, better low-light performance, shallower depth of field. F1.4 is very low-light capable; F1.8 is common commercial spec. P-iris (precise iris) lenses auto-adjust aperture based on scene lighting — reduces over-exposure during day, improves low-light at night.

850nm vs 940nm IR

IR illuminators at 850nm are more energy-efficient and the sensitivity of most camera IR-cut filters peaks here — but 850nm produces a faint visible red glow from the LEDs. 940nm is invisible to human eye but requires ~2x the power or shorter effective range. Many covert-deployment cameras are re-tuned for 940nm sensitivity.

UL-Listed Power Supplies

Underwriters Laboratories listed power supplies meet safety standards for overcurrent, overvoltage, and enclosure isolation. UL 294 specifies additional requirements for access control; UL 603 for security burglary; UL 1310 for Class 2 power. Insurance and code requirements increasingly specify UL-listed supplies — particularly in commercial and institutional installations.

Plenum vs Riser vs PVC Cable

Plenum-rated (CMP) cable uses low-smoke FEP jacket for use above suspended ceilings where smoke spreads through return-air plenums. Riser (CMR) is for vertical shaft runs between floors. PVC (CM) is for open office runs only. Using CM in plenum spaces violates NFPA 70 — costly inspector rejection if caught.

Typical Deployment Scenarios

New Construction Retrofit

Cat6A plenum cable pulled to camera locations with proper service loops, 2-gang electrical boxes at each dome location with weatherproof backbox, Cat6A patch panel at the IDF, UL-listed power supplies for any 12V/24V camera, labeled and tested before cameras are mounted.

Coastal / Corrosive Environment

NEMA 4X stainless-steel enclosures for outdoor cameras, 316-grade stainless brackets, silicone dielectric grease on every connector, hot-dipped galvanized or powder-coated steel poles. Budget 15-25% more on accessories vs. standard outdoor — and plan for 3-5 year inspection cycles rather than 10.

Box-Camera LPR Application

Box camera with 50-150mm telephoto lens, dedicated 850nm IR illuminator at same height as camera, pole-mount bracket with junction box, UL power supply for camera + illuminator. LPR-specific enclosures with anti-reflective glass to avoid nighttime IR bloom. Typical deployment: dedicated lane camera, not general-purpose surveillance.

Parking Garage Retrofit

Existing analog coax cable replaced via NVT Phybridge or similar PoE-over-coax, vandal-resistant dome enclosures at ground level, low-profile bullet cameras on ceiling, LED-plus-IR-compatible illuminators to handle harsh fluorescent lighting. Enclosures rated for vehicle-exhaust environment.

Frequently Asked Questions

Do I need the OEM bracket for my camera, or will a generic bracket work?

For most commercial installations, specify the OEM bracket. Brand-specific brackets include proper cable routing, gasketed weather seals, and mounting-hole patterns matched to the camera — which matters more than the cost savings of a generic bracket. Generic brackets are acceptable for indoor standard-dome cameras on flat surfaces; for outdoor, vandal-rated, or pendant applications, use OEM.

What NEMA rating do I need for outdoor camera enclosures?

NEMA 4 for most weather-exposed deployments (driving rain, snow). NEMA 4X for coastal, industrial, or food-processing environments (adds corrosion resistance — typically stainless steel or fiberglass construction). NEMA 6 for temporary submersion or flood-prone areas. The IP-rating equivalent is IP66 for NEMA 4, IP66 + corrosion for NEMA 4X, IP67 for NEMA 6.

How do I choose the right lens focal length for a box camera?

Work backward from the scene. Identify the farthest point you need identification-grade coverage, use our DORI guide to calculate required pixels-per-foot at that distance, and match lens focal length + sensor size to deliver that PPF. A 4mm lens on a 1/3" sensor covers ~60° horizontal FOV; a 12mm lens on the same sensor covers ~20°. Wide FOV = shorter identification distance.

What's the difference between 850nm and 940nm IR illuminators?

850nm is more energy-efficient — you get more effective range per watt — but produces a faint visible red glow from the LEDs. 940nm is truly invisible to the human eye but requires about 2x the power for equivalent range, and many cameras have lower sensor sensitivity at 940nm. For deterrent visibility or cost-efficient long-range, 850nm; for covert applications, 940nm.

Can I power an IP camera with a generic 12V wall-wart?

Not for a commercial deployment. Generic wall-warts are unregulated, not UL-listed for security applications, and typically don't include surge protection. Use a UL-listed surveillance power supply (Altronix AL series, UL 294 or UL 603) with battery backup where required. PoE is preferred when possible — single cable, centralized power management, UPS-backed.

What cable jacket rating do I need for in-ceiling runs?

Plenum-rated (CMP) cable is required for any run through a return-air plenum space above suspended ceilings (most commercial buildings). Riser (CMR) for vertical shafts between floors. PVC (CM) for open office spaces only. Using non-plenum cable in a plenum space is a fire-code violation under NFPA 70 and will be rejected by inspectors. Budget plenum cable for any building where you're not 100% sure of the return-air path.

Accessories

Deployment Considerations

Sub categories

Showing Results for Accessories

Geovision 54-MT21000-SD00 GV-MOUNT 210 Mounting Bracket

Geovision 55-800EX-160 GV-800 Express 16-Card System

Geovision 81-D7H05-WBM Wall Box Mount

Geovision 81-MA13560-F081 13.56MHz RFID Card Module

Geovision 81-MT100-000 GV-MOUNT 100 Straight Tube

Geovision 81-MT203-000 GV-MOUNT 203 Wall Pendant Tube

Geovision 81-MT21220-0001 Wall-Ceiling Box Mount

Geovision 81-MT300-000 GV-MOUNT 300 Convex Corner Adapter

Geovision 81-PT135TG-0001 13.56MHz On-Metal RFID Tag

Geovision GV-1120B 16-Channel 1.3MP System

Geovision GV-1240B 16-Channel Promotion Package

Geovision GV-5016 16-Channel 480FPS Display Module

Geovision GV-5016 16-Channel PCI Express Card

Geovision GV-600 16-Channel DVI PCI Card

Geovision GV-650 Composite Video Input Adapter

Geovision GV-650 GV-650 Express D Type 8 Card

Browse by Product Family

What to Look For When Buying

Technology Stack

Typical Deployment Scenarios

Top Brands for Outdoor Deployments

Frequently Asked Questions

Related Categories

Engineering Reading
