HES · EL-EPTL

HES EL-EPTL Electrical Power Transfer Module

Centralized 12V/24V power distribution for access control and security hubs

• Selectable 12V/24V output eliminates downstream converters, reducing BOM complexity.
• Distributes stabilized power to multiple access control devices from one module.
• Installs in wall enclosures or 19-inch racks; corner, recessed, and rack mounts supported.

HES · EL101

HES EL101 Extra Key for KA109A KA110A

Replacement key for HES KA109A and KA110A access control

• Compatible with both KA109A and KA110A units, simplifying multi-unit spare inventory.
• Cut to OEM mechanical specifications, ensuring consistent wear and reliable keying.
• No tools or programming required — deploy immediately upon receipt in the field.

HES · 1006-612-LBSM

HES Electric Strike (Satin Bronze Latchbolt - 1006-612-LBSM

N electric strike with a satin bronze latchbolt finish, designed for commercial door-control applications where access control systems require

• Electric door strike for commercial access control
• Satin bronze latchbolt finish for commercial entryways
• Low-voltage DC coil activation for hardwired control systems

HES · 1600-613E

HES Electric Strike Body Only 1600 Dark oxidized - 1600-613E

When you need a field-proven electric strike for retrofit projects or replacements in existing jambs, the HES 1600 series delivers reliable access

• Body-only design reuses existing 1600-series faceplates, cutting retrofit labor and parts cost.
• Dual-voltage 12/24V DC field-selectable operation fits virtually any access control panel.
• UL 1034 and UL 10C 3-hour fire-rated with 1,500 lb static strength for commercial-grade security.

HES · 1600-613E-DLM

HES Electric Strike Body Only 1600 Dual lock - 1600-613E-DLM

When you're replacing a failed strike body in an existing access control installation, you need the exact component—not a full kit with hardware

• Dual Lock Monitor (DLM) independently confirms latchbolt and deadbolt status in real time.
• 1,500 lb static strength with UL 1034 and UL 10C 3-hour fire listings meets strict code requirements.
• 12/24V DC field-selectable input simplifies retrofit into existing panel wiring without rewiring.

HES · 1600-613E-DLMS

HES Electric Strike Body Only 1600 Dual lock - 1600-613E-DLMS

When you're replacing or upgrading strike components in high-traffic commercial openings, you need drop-in compatibility without reworking the frame

• Drop-in fit to ANSI A115.2 cutouts eliminates frame modification on retrofit jobs.
• 12/24V DC field-selectable with DLMS monitors both latch and strike status in real time.
• UL 1034 and UL 10C 3-hour fire-rated; 1,500 lb static strength for high-traffic duty.

HES · 1600-613E-LM

HES Electric Strike Body Only 1600 Lock monitor - 1600-613E-LM

When you're replacing a failed strike mechanism or need a spare body for your existing HES 1600 frame, this electric strike body delivers the same

• Drop-in replacement body fits existing HES 1600 frames without disturbing door hardware.
• Integrated lock monitor delivers door-position feedback, eliminating separate DPS wiring.
• Fail-secure operation keeps the latch locked during any power interruption.

HES · 1600-605

HES Electric Strike Body Only Bright brass - 1600-605

When you need to replace a failed strike body in an existing HES 1600 series installation without tearing out the entire frame prep, this body-only

• Body-only swap preserves existing 1600 series faceplate and frame prep, cutting service labor.
• 1,500 lb static strength with UL 1034 and UL 10C 3-hour fire listing meets code requirements.
• 12/24V DC field-selectable operation draws just 0.13 A at 24V, minimizing panel load impact.

HES · 1600-605-LM

HES Electric Strike Body Only Lock monitor - 1600-605-LM

• Body-only format pairs with existing HES 1600 series faceplates for retrofit installs.
• Integrated lock monitor output enables forced-door and door-ajar alerts at the panel.
• Suits wood, hollow metal, and aluminum frames; supports fail-secure or fail-safe wiring.

HES · 1600-606-LM

HES Electric Strike Body Only Lock monitor - 1600-606-LM

When you need to replace a failed strike body without rewiring the entire frame prep, or you're upgrading an existing 1600 series installation to

• Body-only form factor swaps into existing 1600 series frames without re-prepping cutouts.
• Integrated lock monitor adds keeper position feedback to panels lacking position sensing.
• Supports forced-door and door-held-open alarms when wired to compatible access controllers.

HES · 1600-612-LM

HES Electric Strike Body Only Lock monitor - 1600-612-LM

When retrofitting access control into existing frames or replacing failed strike components, you need a field-proven electric strike body that

• Body-only format replaces failed strike internals without disturbing existing faceplates.
• Integrated lock monitor delivers real-time door status for forced-door and held-open alarms.
• Compatible with HES 1600 series faceplates, reducing retrofit labor on multi-phase deployments.

HES · 1600-605-LMS

HES Electric Strike Body Only Lock monitor and - 1600-605-LMS

• Integrated lock monitor confirms latch engagement, closing audit-trail gaps.
• Body-only format supports retrofit installs on existing cylindrical or mortise hardware.
• Monitor output feeds directly to access control panels for real-time alarm verification.

HES · 1600-606-LMS

HES Electric Strike Body Only Lock monitor and - 1600-606-LMS

When you need to retrofit an existing electric strike installation with lock monitoring capability, swapping out the entire assembly isn't always

• Drop-in body replacement retrofits existing HES 1600 series strikes without new frame prep.
• Integrated lock monitor delivers contact closure signal directly to your access control panel.
• Eliminates separate door position switches by confirming keeper engagement in one unit.

HES · 1600-612-LMS

HES Electric Strike Body Only Lock monitor and - 1600-612-LMS

When you need to retrofit an existing electric strike installation with monitoring capability or replace a damaged strike body without swapping the

• Strike body-only design enables frame retrofits without removing faceplate hardware.
• Integrated lock monitor output lets control panels distinguish forced-door from valid access.
• Compatible with existing HES 1600 series faceplates, minimizing re-cut and re-trim labor.

HES · 1600-606

HES Electric Strike Body Only Satin brass - 1600-606

• Drop-in body-only replacement for HES 1600 series cuts material and labor costs.
• Rated 1,500 lbs static strength with UL 1034 and UL 10C 3-hour fire listings.
• 12/24V DC field-selectable operation draws only 0.13 A at 24V DC.

HES · 1600-612

HES Electric Strike Body Only Satin bronze - 1600-612

• Body-only format lets you replace worn strike mechanisms without re-drilling or rewiring.
• Fits existing HES 1600 series mounting patterns and keeper geometry for drop-in service.
• Satin bronze finish aligns with standard architectural hardware for consistent aesthetics.

HES · EM-04

HES EM-04 RFID Key Fob for KP-300

Passive RFID key fob for HES KP-300 contactless access control

• Passive RFID fob requires no battery, eliminating maintenance cycles at any door count.
• Native KP-300 compatibility means zero middleware or reader reconfiguration on deployment.
• Wiegand output integrates directly with third-party controllers supporting Wiegand input.

HES · EM-10

HES EM-10 Proximity Cards for KP-300 Pack of 10

Proximity cards for HES KP-300 keypads, 10-pack replacement

• Contactless proximity technology works with KP-300 and standard readers
• Pack of 10 cards for credential replacement or access expansion
• US-manufactured access control credentials for multi-user facilities

HES · EPT-SC

HES EPT-SC Electrical Power Transfer SwingClear

Power distribution accessory for HES security control systems

• Electrical power transfer and routing for access control installations
• SwingClear cable management design simplifies installation and maintenance
• Compatible with HES security infrastructure for surveillance and access systems

HES · EPTL

HES EPTL Electrical Power Transfer Module

Centralized power module for multi-zone access control and security systems

• Distributes power to card readers, electronic locks, and door controls across multiple zones
• DIN-rail and enclosure-mount options for indoor/outdoor security cabinets and control panels
• Reduces voltage drop on long reader runs with direct integration to HES security architectures

HES · EXD-1L

HES EXD-1L Exit Delay System Module

Configurable exit delay relay for HES electromagnetic locks

• Centralizes exit delay logic for up to 92 doors from a single 0.25 lb module.
• Native 24VDC input integrates directly with standard access control panels and lock controllers.
• Wiegand communication lets credential readers trigger delay sequences without protocol conversion.

HES · FA-200

HES FA-200 D.P.D.T. Indicating Shunt Switch

D.P.D.T. relay switch with visual indicator for access control circuits

• D.P.D.T. configuration switches two independent circuits simultaneously from one trigger.
• Integrated visual indicator confirms relay state instantly—no multimeter needed on-site.
• Compact 2.5 × 2.5 × 0.77 in body fits tight enclosure installs at 0.1 lb.

HES · FA-200WIRED

HES FA-200WIRED DPDT Indicating Shunt Switch

DPDT indicating shunt switch for manual door strike control with status feedback

• DPDT contacts enable independent or sequenced control of solenoid and mag-lock hardware.
• 28VDC input integrates directly with standard access control power supplies and UPS modules.
• Illuminated alternate-action button confirms switch state instantly, simplifying field troubleshooting.

HES · FA-XDT-24

HES FA-XDT-24 Exit Delay Timer 24VDC

24VDC exit delay timer for controlled mag-lock and strike release

• Flush-mount design integrates into door frames without surface equipment
• Alarm output monitors delay conditions and integrates with access control
• Compatible with HES electronic locking hardware across standard architectures

HES · 1006-630

HES Fail Secure Universal 12/24VDC Electric Strike - 1006-630

Fail-secure electric strike designed for standard wooden and metal door frames in commercial access control installations

• Fail-secure operation keeps the door locked during power loss, protecting secured areas.
• Accepts 12V or 24VDC input, fitting existing power architectures without added conversion hardware.
• Universal frame footprint installs on wood or metal frames, reducing retrofit fabrication time.

HES · FMB9-4

HES FMB9-4 Post Shim Kit for Flex Mount B

Four-piece shim kit for Flex Mount B bracket alignment

• Four-piece shim kit corrects surface irregularities for precise Flex Mount B alignment.
• Eliminates post-installation rework by compensating for tolerance stackup during deployment.
• Compact form factor (1.1 × 8 × 0.2 in, 0.65 lb) minimizes carry load on multi-site jobs.

HES · FMK-SL

HES FMK-SL Flex Mount Kit for Sliding Gate

Flex mount kit for sliding gates—fits non-standard frames without welding

• Accommodates multiple frame angles and geometries for retrofit installations
• Eliminates on-site custom fabrication and shimming labor on variable frames
• Works with HES electric strike systems for sliding gate access control

HES · FMK-SW

HES FMK-SW Flex Mount Kit Swing Gate

Flex mount kit for swing gate access control integration

• Accommodates varied gate geometries without custom fabrication
• Compatible with HES access control components and readers
• 13.35 lb electromagnetic lock strike mount, US-made

HES · FP:H-2-630

HES FP:H-2-630 Satin Stainless Steel Faceplate

Satin stainless steel faceplate for HES 1006 electric strike

• 630 finish satin stainless steel resists corrosion in high-traffic areas
• Direct fit for HES/Hanchett 1006 electric strike installations
• Professional finished appearance suitable for commercial door assemblies

HES · FP:KD-630

HES FP:KD-630 Faceplate for 1006 Electric Strikes

Satin stainless steel faceplate for HES 1006 electric strikes

• Satin stainless steel construction resists corrosion in commercial indoor deployments.
• Direct-fit compatibility with HES 1006 electric strikes simplifies retrofit and new installs.
• Compact 5 x 1.5 x 0.1 in profile fits standard door prep without modification.

HES · FP:KM-630

HES FP:KM-630 Faceplate for 1006 Electric Strikes

Satin stainless steel replacement faceplate for HES 1006 electric strikes

• Direct drop-in replacement for HES 1006 electric strikes minimizes downtime.
• Satin stainless steel construction resists corrosion in standard commercial environments.
• Compact 4.8 x 1.8 x 0.2 in profile fits standard 1006 series strike cutouts.

HES · FP:N-2-630

HES FP:N-2-630 Satin Stainless Steel Faceplate

N-2 satin stainless faceplate for HES 1006 electric strikes

• 630-grade stainless steel with satin finish resists corrosion
• N-2 profile geometry aligns precisely with 1006 strike mechanism
• Direct replacement part for commercial access control installations

HES · FPK7410-313

HES FPK7410-313 7400 Modular Faceplate Kit

Dark bronze modular faceplate for HES 7400 series access control

• Anodized aluminum construction resists corrosion in high-traffic entries
• Modular design supports multiple mounting configurations and layouts
• Compatible with HES 7400 series for standardized multi-facility deployments

HES · FPK7410-335

HES FPK7410-335 7400 Modular Faceplate Kit

Black aluminum faceplate for HES 7400 systems with modular reader inserts

• Modular design supports mixed-technology deployments across multiple credential types
• Black anodized aluminum construction resists corrosion in indoor access control environments
• Configurable reader and button inserts simplify upgrades without hardware replacement

HES · FPK7410-628

HES FPK7410-628 7400 Series Modular Faceplate Kit

Modular faceplate kit for HES 7400 series wall-mount access control

• Satin aluminum construction with clear anodized finish resists corrosion
• Modular design integrates with HES 7400 series control systems
• Wall-mount configuration for flexible installation across facility layouts

HES · FPK7410-630

HES FPK7410-630 7400 Series Modular Faceplate Kit

Wall-mounted modular faceplate for HES 7400-series access control

• Satin stainless steel construction resists corrosion in indoor commercial use
• Modular design integrates directly with HES 7400-series hardware without modifications
• Professional finish suitable for offices, institutions, and secure facilities
