Network Video Recorders (NVRs)

Plan Your Deployment

Camera count and resolution requirements
Retention period and storage capacity planning
Throughput and recording bandwidth limits
RAID configuration and redundancy strategy
Remote access and VMS integration needs

Sub categories

Showing Results for Network Video Recorders (NVRs)

Compare

Add to Cart The item has been added
Hanwha

SKU: HRX-434

Hanwha HRX-434 4-Channel Pentabrid DVR Recorder

4-channel pentabrid DVR with 8MP analog + 6 IP cameras, H.265 compression
- Records 4 analog formats (AHD/HDTVI/HDCVI/CVBS) on same connectors; auto-detects signal type
- 8MP @ up to 30fps per channel with H.265 codec reduces storage 40–50% vs H.264
- Dual HDMI + VGA simultaneous output; 6-channel playback bandwidth 32 Mbps; 6TB SATA max
In stock · Usually Ships Same Business Day

$334.00 $247.99 Save $86.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: HRX-435

Hanwha HRX-435 4-Channel Pentabrid DVR Recorder

4-channel pentabrid DVR with 8MP analog + 6 IP, dual 12TB HDD
- Mix AHD/HDTVI/HDCVI/CVBS analog with up to 6 IP cameras on one recorder
- 8MP analog @ 8fps, H.265/H.264/MJPEG compression, dual SATA slots
- 4 alarm inputs, 2 relay outputs, HDMI + VGA simultaneous display
In stock · Usually Ships Same Business Day

$400.00 $296.99 Save $103.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-435-12TB

Hanwha HRX-435-12TB 8MP Pentabrid DVR Recorder

4-channel pentabrid DVR with 8MP analog + IP expansion, 12TB storage
Special Order · Usually Ships in 2-3 Weeks

$1,840.00 $1,362.99 Save $477.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: HRX-435-2TB

Hanwha HRX-435-2TB 8MP Pentabrid DVR Recorder

4-channel pentabrid DVR with 8MP analog + 6 IP cameras, 2TB expandable
In stock · Usually Ships Same Business Day

$640.00 $473.99 Save $166.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-435-4TB

Hanwha HRX-435-4TB 8MP 4-Channel Pentabrid DVR

4-channel pentabrid DVR with 8MP analog + 6 IP, 4TB expandable
Special Order · Usually Ships in 2-3 Weeks

$880.00 $651.99 Save $228.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-435-6TB

Hanwha HRX-435-6TB Pentabrid DVR 8MP 6TB

4-channel pentabrid DVR handles analog + IP cameras, 8MP, 6TB storage
Special Order · Usually Ships in 2-3 Weeks

$1,120.00 $829.99 Save $290.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-435-8TB

Hanwha HRX-435-8TB Pentabrid DVR 8MP 4-Channel

4-channel pentabrid DVR with 8MP analog + IP, 8TB storage
Special Order · Usually Ships in 2-3 Weeks

$1,360.00 $1,006.99 Save $353.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-835A-16TB

Hanwha HRX-835A 8MP Pentabrid DVR 16TB

8MP pentabrid DVR with 16TB storage for mixed analog and IP cameras
Special Order · Usually Ships in 2-3 Weeks

$2,987.00 $2,211.99 Save $775.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-835A

Hanwha HRX-835A 8MP Pentabrid DVR Recorder

8MP pentabrid DVR with 8 analog + 10 IP channels for mixed camera systems
Special Order · Usually Ships in 2-3 Weeks

$1,067.00 $789.99 Save $277.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-835A-12TB

Hanwha HRX-835A-12TB 8MP Pentabrid DVR 12TB

8-channel hybrid DVR mixing analog + 10 IP cameras up to 8MP
Special Order · Usually Ships in 2-3 Weeks

$2,507.00 $1,855.99 Save $651.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-835A-24TB

Hanwha HRX-835A-24TB 8MP Pentabrid DVR Recorder

8-channel pentabrid DVR with 24TB storage for analog and IP cameras
Special Order · Usually Ships in 2-3 Weeks

$3,947.00 $2,921.99 Save $1,025.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: HRX-835A-4TB

Hanwha HRX-835A-4TB 8-Channel Pentabrid DVR 4TB

8-channel pentabrid DVR for mixed analog/IP camera systems with 4TB storage
In stock · Usually Ships Same Business Day

$1,547.00 $1,145.99 Save $401.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: HRX-835A-6TB

Hanwha HRX-835A-6TB 8-Channel Pentabrid DVR with 6TB Storage

8-channel pentabrid DVR mixing analog and IP cameras on one recorder
In stock · Usually Ships Same Business Day

$1,787.00 $1,322.99 Save $464.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: HRX-835A-8TB

Hanwha HRX-835A-8TB Pentabrid 8MP DVR Recorder

8-channel pentabrid DVR—analog + 10 IP cameras, 8MP, 8TB storage
Special Order · Usually Ships in 2-3 Weeks

$2,027.00 $1,500.99 Save $526.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: PRN-1600B2-16TB

Hanwha PRN-1600B2 16-Channel 8K NVR 16TB

16-channel 8K NVR with 16TB storage and AI analytics for enterprise surveillance
Special Order · Usually Ships in 2-3 Weeks

$8,120.00 $6,081.99 Save $2,038.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: PRN-1600B2-8TB

Hanwha PRN-1600B2 16-Channel NVR 8TB 32MP

16-channel 32MP NVR with 8TB storage and AI search for enterprise surveillance
Special Order · Usually Ships in 2-3 Weeks

$7,160.00 $5,362.99 Save $1,797.01

Add to Cart
The item has been added

What to Look For When Buying

The decisions that matter most before you spec.

Real Bitrate vs. Rated Camera Count

NVRs are often rated for more cameras than they can actually process simultaneously at rated resolution and frame rate. Before purchase, calculate total ingress bitrate: sum camera bitrate × number of cameras, then confirm the NVR's sustained throughput (not peak). See Why Your NVR Can't Handle Its Rated Camera Count for real-world examples.

Storage Throughput & Disk Selection

NVR write speed is limited by disk throughput, not capacity alone. A 4-camera 4K system can exceed 100 Mbps sustained writes; mismatched drive selection causes dropped frames and gaps. Pair your NVR with surveillance-grade drives rated for 24/7 streaming and validate RAID configuration matches your retention math.

Retention Calculation & Scaling

Storage lifetime depends on bitrate, motion-detection settings, and frame-rate. A 30-day retention target for 16 cameras at 4 Mbps each = ~1.7 TB minimum. Factor in overhead, RAID redundancy, and growth. Read Retention Math for IP Cameras: Bitrate, Motion, Storage Traps to avoid undersizing.

Network & Power Infrastructure Readiness

Large NVR deployments collapse when backbone switches, PoE injectors, or UPS capacity aren't sized for sustained load. Why Surveillance Networks Collapse at the Core explains bandwidth and redundancy planning. Verify your switch, network cabling, and power distribution before finalizing the recorder choice.

Vendor Support & Software Compatibility

NVR firmware, mobile app stability, and remote access reliability vary widely. Select brands like Hikvision, Hanwha, Axis, and Vivotek with proven field track records and transparent changelog/SLA terms. Evaluate Video Management Software (VMS) integration early to avoid vendor lock-in.

Redundancy, Failover & Incident Reliability

Single NVR failure or network outage can blind an entire facility during critical incidents. Architect dual-recorder setups, redundant storage, or Why Surveillance Systems Fail During Incidents to ensure continuous recording. For multi-site deployments, plan for isolated recording at each location and centralized backup.

Technology Stack

The specs and acronyms that actually affect network video recorders (nvrs) performance.

Bitrate (Mbps)

The sustained network and storage bandwidth required per camera stream. Measured in megabits per second. Lower bitrate = longer retention on same storage; too low = lost detail. NVR throughput (e.g., 200 Mbps) must exceed sum of all camera bitrates to avoid frame drops.

PoE Budget (Watts)

Power delivered over Ethernet to cameras. Standard PoE = 15W per port; PoE+ = 30W; PoE++ = 60W or more. Verify NVR's built-in PoE power supply or external injector can supply total wattage for all connected cameras simultaneously, not just nameplate rating.

RAID Configuration (0, 1, 5, 6, 10)

Storage redundancy method. RAID 1 (mirroring) = 50% usable capacity but fast recovery; RAID 5 (striping + parity) = ~67–75% usable, slower rebuild; RAID 6 = dual-parity, safest but slower writes. Choose based on RTO/RPO and disk failure tolerance for your facility.

Frame Rate (FPS) & Resolution

Higher resolution and frame rate increase bitrate non-linearly. 4K 30 FPS ≈ 50–100 Mbps per camera; 1080p 30 FPS ≈ 4–8 Mbps. NVR must deliver rated FPS across all channels simultaneously; frame-rate reduction under load is common and often undisclosed in specs.

Onboard Storage vs. Expansion

Some NVRs include 1–8 TB of internal drive bays; others accept only external SAN or NAS. Modular expansion via USB, SATA, or NAS allows scaling beyond internal capacity but introduces network latency and single-point-of-failure risk if not redundant.

HDMI/VGA Output & Multi-Monitor

Direct video output for live playback and alarm response. Dual HDMI or DVI enables multi-monitor wall displays for SOC operations. Check Monitors & Displays for compatible wall-mount and Joystick & Keyboard Controls for operator interfaces.

Typical Deployment Scenarios

Small Office (8 Cameras, 30-Day Retention)

One 8-channel compact NVR (e.g., entry-level Hikvision or Hanwha model) with 2–4 TB internal RAID 1 storage. Built-in PoE switch powers cameras; single gigabit uplink to office network. Total bitrate ~32–48 Mbps; UPS protects against brief power loss. Cost: $800–$1,500 all-in.

Retail Chain (4 Stores, 16 Cameras Each, Centralized Backup)

Four 16-channel mid-range NVRs deployed locally at each store location, each with 4–6 TB RAID 5 storage for 14-day retention. Nightly backup to central NAS or cloud via WAN. If one location's NVR fails, other three continue recording; central system rebuilds from backups. Requires network redundancy and Why Surveillance Standards Collapse After the Third Location planning.

Campus/Large Facility (64+ Cameras, Hybrid Storage)

One or two enterprise-class 64-channel rackmount NVRs in data center with 24–48 TB SAN or modular expansion. Satellite 16-channel NVRs at building entrances for local failover. Total bitrate 400+ Mbps; redundant gigabit backbone, dual switches, and Why Large Surveillance Systems Fail: Storage Throughput Reality mitigation. Integrate Video Management Software (VMS) for unified search and forensics.

High-Resolution Mixed Deployment (32 × 1080p + 8 × 4K, 60-Day Retention)

32-channel NVR rated for 4K + lower-res mixing. 1080p cameras = ~6 Mbps each (192 Mbps); 4K = ~60 Mbps each (480 Mbps); total ~672 Mbps. Verify NVR sustains this; may require two units or careful frame-rate reduction. 12–16 TB RAID 6 storage. Cross-reference Retention Math for IP Cameras: Bitrate, Motion, Storage Traps to confirm math.

Frequently Asked Questions

What's the difference between an NVR and a DVR?

A DVR (Digital Video Recorder) uses analog coax cameras and a capture card; an NVR (Network Video Recorder) receives IP camera streams over Ethernet. NVRs are now standard because they enable remote access, higher resolution, PoE power, and easier scaling. DVRs are legacy for most new deployments.

How do I calculate how much storage I need?

Multiply bitrate per camera (Mbps) × number of cameras × 86,400 seconds/day × retention days ÷ 8 bits/byte = total bytes. Example: 5 cameras × 5 Mbps × 86,400 × 30 days ÷ 8 = ~810 GB. Add 20–30% overhead for RAID and metadata. See Retention Math for IP Cameras: Bitrate, Motion, Storage Traps for detailed examples.

Can I mix camera brands and resolutions on one NVR?

Yes, most modern NVRs accept ONVIF-compliant IP cameras from any vendor (Hikvision, Axis, Vivotek, etc.) and mix 1080p, 2MP, 4K, and other resolutions on the same recorder. However, bitrate and frame-rate planning becomes critical; lower frame rates or bitrate reduction may occur if total throughput is exceeded.

What happens if my NVR storage fills up?

Most NVRs default to overwrite mode: oldest video is deleted to make room for new recording. Some support redundancy via dual RAID arrays or remote backup. Prevent accidental loss by setting up automated export to NAS, VMS archive, or cloud; verify RAID type protects against single-disk failure.

Do I need a separate switch if my NVR has PoE?

If your NVR has integrated PoE ports and all cameras connect directly to it, no external switch is needed. However, if you have more cameras than PoE ports or need network redundancy, add a managed PoE switch upstream. Always verify the NVR's PoE wattage budget covers all cameras simultaneously.

What's the best way to ensure my NVR doesn't fail during an incident?

Deploy Why Surveillance Systems Fail During Incidents architecture: local recording at multiple sites, UPS backup, network redundancy, and regular backup to offsite NAS or cloud. Test failover quarterly. Use RAID 6 or mirrored storage, and avoid single points of failure in power, network, and storage paths.
