Pelco EXFP1-8V9-EBT0-IR 8MP Explosion-Proof Bullet

Pelco EXFP1-8V9-EBT0-IR 8MP Explosion-Proof Bullet Camera

The Pelco EXFP1-8V9-EBT0-IR is a rugged, certified explosion-proof IP camera designed for hazardous environments where flammable gases, vapors, or combustible dusts may be present. Built from 316L stainless steel and rated ATEX, IECEx, and UL for Zone 1, Zone 2, Division 1, and Division 2 areas, this 8MP bullet delivers identification-grade imaging in the most demanding industrial and petrochemical applications.

Key Features

• 8MP resolution with motorized varifocal lens for flexible field-of-view adjustment
• 316L stainless steel housing rated IP67 and NEMA 4X for extreme weather protection
• Integrated 850 nm IR illumination for reliable day/night surveillance
• H.265 and H.264 video compression for efficient bandwidth and storage
• Wide temperature range: -40°C to +60°C for harsh climates
• IK10 vandal rating for impact resistance
• PoE+ powered with microSD local storage support
• ONVIF Profile S, T, G, and M compliant for multi-vendor integration
• HTTPS encryption for secure data transmission
• 5-year warranty for enterprise peace of mind

Technical Specifications

• Sensor & Optics: Motorized varifocal lens, F1.3 aperture with day/night switching
• Video Output: H.265 and H.264 compression; ONVIF compliant
• Connectivity: Ethernet and USB; PoE+ Class 3 power
• Environmental: IP67 and NEMA 4X rated; IK10 vandal resistant
• Certifications: ATEX, IECEx, UL; NDAA Section 889 compliant
• Operating Temperature: -40°C to +60°C
• Storage: microSD card support

Industrial Applications

Ideal for process monitoring, equipment surveillance, and perimeter protection in petrochemical plants, refineries, mining operations, pharmaceutical facilities, and grain handling plants. The motorized varifocal lens enables flexible positioning for corridors, equipment areas, and entry points without requiring camera repositioning.

Installation Considerations

Field wiring must comply with local electrical codes for the classified hazardous area. Conduit and gland entries are configured during installation—no pre-installed cable supplied. Verify the specific hazardous area classification against the camera's certifications before deployment.
