Hanwha XNO-6010R vs i-PRO S1536LA: Specification Comparison
Both the Hanwha XNO-6010R and the i-PRO WV-S1536LA are 2MP outdoor bullet IP cameras designed for perimeter surveillance, making them direct cross-shop candidates for installers evaluating fixed-lens versus motorized-varifocal optics at the same resolution tier. The XNO-6010R offers a wide fixed field of view with dual edge-storage slots and a broad analytics suite, while the S1536LA brings a 3.1× motorized zoom lens, 70m IR reach, AI sound classification, and FIPS 140-2 Level 3 security certification. This comparison covers imaging, installation, and integration trade-offs based solely on published specifications.
In This Guide
How do the imaging specs compare?
Both cameras use an approximately 1/2.8-inch 2MP CMOS sensor and capture 1080p at up to 60fps in H.265. The XNO-6010R carries a fixed 2.4mm lens with a 139° horizontal field of view, suited for wide-area coverage at close-to-medium range, and delivers IR illumination to 20m (65.6ft). Its minimum illumination in color is 0.055 lux, reaching 0 lux in IR mode. WDR is rated at 150dB via its SSDR/WDR engine. The S1536LA, by contrast, features a 2.9–9mm motorized varifocal lens with 3.1× optical zoom (extendable to 9.3× via extra zoom at 640×360), providing a 37–117° horizontal field of view in 16:9 mode—allowing remote reframing without physical lens changes. IR reach extends to 70m (229.7ft) at 30IRE / 50m at 50IRE, and color minimum illumination is 0.007 lux; B&W minimum illumination is 0.005 lux (F1.3, 1/30s). Dynamic range peaks at 144dB (Super Dynamic Level 31).
In summary: the XNO-6010R provides wider coverage (139° vs up to 117°) and a higher WDR rating (150dB vs 144dB), while the S1536LA provides more than 3× the IR range (70m vs 20m), over 7× better color low-light sensitivity (0.007 lux vs 0.055 lux), and remote optical zoom flexibility. DORI performance data (Detect/Observe/Recognize/Identify at wide and tele) is provided only for the S1536LA; the XNO-6010R does not publish DORI distances.
What about installation and environment?
Both cameras are IP66-rated for dust and water resistance, IK10-rated for impact resistance, and NEMA 4X-listed. The XNO-6010R is rated for operation from -30°C to +55°C and storage from -50°C to +60°C, weighing 1,220g (2.69 lb) in an aluminum housing measuring Ø70×296mm. It supports PoE IEEE 802.3af (Class 3, max 9.7W) or 12VDC (max 8.8W). The S1536LA operates from -40°C to +60°C (power-on range: -30°C to +60°C) and features an active anti-condensation system (Temish element, heater, and moisture absorption gel) not present in the XNO-6010R spec. It weighs approximately 2.4kg (5.3 lb) in an aluminum/resin/polycarbonate housing measuring Ø133×133×383mm, and draws up to 9.1W over PoE 802.3af (PoE Class listed as 0 in product attributes). The S1536LA also specifies wind resistance up to 40m/s (~89 mph). Both provide a CVBS/VBS composite monitor output for installation alignment.
Which fits your VMS and analytics better?
Both cameras support ONVIF Profile S, G, and T (the S1536LA adds Profile M). Both stream H.265, H.264, and MJPEG with CBR/VBR bitrate control and unicast/multicast delivery. The XNO-6010R supports up to 20 simultaneous unicast users and up to 10 stream profiles; the S1536LA supports up to 14 simultaneous users. Protocol support is broadly similar; the S1536LA adds SFTP and MQTT, which the XNO-6010R does not list. On security, the S1536LA carries FIPS 140-2 Level 3 certification and brute-force protection; the XNO-6010R lists 802.1X (EAP-TLS, EAP-LEAP), HTTPS/SSL, and IP filtering but does not publish FIPS certification.
For edge analytics, the XNO-6010R lists a broader named analytics set—directional detection, digital auto tracking, appear/disappear, enter/exit, loitering, virtual line, defocus, fog detection—plus business intelligence functions (people counting, queue management, heatmap). The S1536LA specifies 8 AI detection modes including AI sound classification (gunshot, yell, vehicle horn, glass break) and scene change detection; the XNO-6010R lists audio detection but does not specify AI sound classification categories. Both provide audio input and output; the S1536LA uses 3.5mm stereo mini jacks, the XNO-6010R uses a 2.5VDC selectable mic/line input and line out. The XNO-6010R provides dual microSD slots supporting up to 512GB; the S1536LA provides a single microSD slot up to 512GB. Alarm I/O: XNO-6010R has 1 input / 1 output; S1536LA has 3 alarm inputs, 1 alarm output, and 1 AUX output. The XNO-6010R warranty is 3 years; the S1536LA warranty is 5 years.
Which should you choose: the XNO-6010R or the S1536LA?
Our take: The XNO-6010R is the stronger choice when wide fixed-angle coverage (139° H), dual edge-storage slots, and a richer named analytics library—including people counting, queue management, and heatmap—are the primary requirements at a lower power draw (8.8W vs 9.1W). The S1536LA is the stronger choice when long-range IR reach (70m vs 20m), remote optical zoom (3.1× motorized varifocal), superior low-light sensitivity (0.007 lux color vs 0.055 lux), a wider operating temperature floor (-40°C vs -30°C cold-start), FIPS 140-2 Level 3 security compliance, AI sound classification (gunshot/yell/glass break), and a 5-year warranty (vs 3-year) are decision factors. For government, critical infrastructure, or cyber-hardened deployments requiring certified encryption and extended IR range, the S1536LA's spec sheet is materially stronger; for broad-area analytics and dual-slot redundancy on tighter budgets, the XNO-6010R's fixed-lens simplicity and analytics breadth hold clear value.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Hanwha XNO-6010R | i-PRO S1536LA |
|---|---|---|
| Resolution | 2MP (1920×1080) | 2MP (1920×1080) |
| Image Sensor | 1/2.8" 2MP CMOS | Approx. 1/2.8" type CMOS |
| Lens / Focal Length | 2.4mm fixed | 2.9–9mm motorized varifocal (3.1× optical zoom) |
| Horizontal Field of View | 139° | 37–117° (16:9) |
| Min. Illumination (Color) | 0.055 lux | 0.007 lux (30IRE) |
| Min. Illumination (B&W / IR) | 0 lux (IR mode) | 0.005 lux (50IRE, F1.3, 1/30s) |
| IR Range | 20m (65.6ft) | 70m (229.7ft) at 30IRE / 50m at 50IRE |
| Wide Dynamic Range | 150dB | Max. 144dB (Super Dynamic Level 31) |
| Max Frame Rate | 60fps | 60fps |
| Video Compression | H.265 / H.264 / MJPEG | H.265 / H.264 / MJPEG |
| IP Rating | IP66 / IP67 / NEMA 4X | IP66 / NEMA 4X |
| Impact Rating | IK10 | IK10 |
| Operating Temperature | -30°C to +55°C | -40°C to +60°C (power-on: -30°C to +60°C) |
| Power Input / PoE | PoE IEEE 802.3af Class 3 / 12VDC; max 9.7W (PoE) | PoE IEEE 802.3af; 9.1W / DC12V 710mA |
| Edge Storage | Dual microSD/SDHC/SDXC up to 512GB (2 slots) | Single microSD up to 512GB (1 slot) |
| Alarm I/O | 1 input / 1 output | 3 alarm inputs / 1 alarm output / 1 AUX output |
| ONVIF Profiles | S / G / T | S / G / T / M |
| Security Certification | 802.1X EAP-TLS/EAP-LEAP; HTTPS; signed firmware (no FIPS listed) | FIPS 140-2 Level 3; 802.1X; HTTPS; brute-force protection |
| Dimensions | Ø70×296mm (Ø2.76"×11.65") | Ø133×133×383mm (Ø5-1/4"×5-1/4"×15-3/32") |
| Weight | 1,220g (2.69 lb) | Approx. 2,400g (5.3 lb) |
| Warranty | 3 years | 5 years |
Frequently Asked Questions
Which should you choose: the XNO-6010R or the S1536LA?
The XNO-6010R is the stronger choice when wide fixed-angle coverage (139° H), dual edge-storage slots, and a richer named analytics library—including people counting, queue management, and heatmap—are the primary requirements at a lower power draw (8.8W vs 9.1W). The S1536LA is the stronger choice when long-range IR reach (70m vs 20m), remote optical zoom (3.1× motorized varifocal), superior low-light sensitivity (0.007 lux color vs 0.055 lux), a wider operating temperature floor (-40°C vs -30°C cold-start), FIPS 140-2 Level 3 security compliance, AI sound classification (gunshot/yell/glass break), and a 5-year warranty (vs 3-year) are decision factors. For government, critical infrastructure, or cyber-hardened deployments requiring certified encryption and extended IR range, the S1536LA's spec sheet is materially stronger; for broad-area analytics and dual-slot redundancy on tighter budgets, the XNO-6010R's fixed-lens simplicity and analytics breadth hold clear value.
Is the XNO-6010R or S1536LA better for low-light and nighttime surveillance?
The S1536LA is better on both published low-light metrics: its color minimum illumination is 0.007 lux versus the XNO-6010R's 0.055 lux, and its IR illumination reaches 70m (30IRE) compared to the XNO-6010R's 20m. If long-range night visibility is critical, the S1536LA has a material advantage per its specifications.
Which camera is easier to aim and reframe after installation?
The S1536LA includes a 2.9–9mm motorized varifocal lens with 3.1× optical zoom that can be adjusted remotely without physically handling the camera. The XNO-6010R uses a fixed 2.4mm lens; field of view is set at installation and cannot be changed remotely. For sites where reframing flexibility is needed post-install, the S1536LA's motorized zoom is a practical advantage.
Does either camera meet cybersecurity compliance requirements for government or critical infrastructure?
The S1536LA specifies FIPS 140-2 Level 3 certification, device certificates, IEEE 802.1X, brute-force protection, SFTP, and MQTT. The XNO-6010R lists HTTPS/SSL, 802.1X (EAP-TLS, EAP-LEAP), IP filtering, and signed/encrypted firmware but does not publish a FIPS 140-2 certification. For deployments where FIPS 140-2 Level 3 compliance is a hard requirement, only the S1536LA's spec sheet addresses it directly.
