DMP PP-6005B vs SDC IPRW300: Specification Comparison
The DMP PP-6005B and SDC IPRW300 are both wired proximity card readers intended for physical access control at doors. The PP-6005B is a supervised-loop reader designed exclusively for DMP panel ecosystems, reading 26-bit and 35-bit credentials. The IPRW300 outputs Wiegand and reads HID 125 kHz cards, targeting multi-door enterprise deployments with broad panel compatibility. Both mount at the door edge and operate at 16 VDC, making them surface-level alternatives a buyer evaluating a wired proximity reader could legitimately cross-shop.
In This Guide
- Which credential formats and communication protocols does each reader support?
- How many doors and users can each reader support, and how broadly does it integrate?
- How does each reader handle physical installation environment, mounting, and durability?
- Which should you choose: the PP-6005B or the IPRW300?
- Side-by-Side Specs
- FAQ
Which credential formats and communication protocols does each reader support?
The PP-6005B reads 26-bit and 35-bit proximity cards over a supervised loop connection wired directly to DMP control panels (734, 7073/7073A, 7173, and 7873 series). The supervised loop topology means the panel can detect wiring faults — an open or short on the reader line raises a tamper condition. No Wiegand or OSDP output is listed in the provided specs.
The IPRW300 reads HID 125 kHz proximity cards and outputs Wiegand, the industry-standard parallel interface supported by virtually every third-party access control panel on the market. Wiegand does not provide supervised tamper detection natively. The IPRW300 spec does not list 26-bit or 35-bit card support explicitly; it specifies HID 125 kHz Prox as the credential type.
Buyers with an existing DMP panel infrastructure will find the PP-6005B's supervised loop a direct fit. Buyers on any non-DMP platform — or those requiring open Wiegand interoperability — are limited to the IPRW300 side of this comparison.
How many doors and users can each reader support, and how broadly does it integrate?
The PP-6005B's provided specs state panel compatibility with DMP control panel systems only. No multi-door capacity figure or maximum credential count is listed in the available spec data.
The IPRW300 explicitly supports up to 63 doors and 250,000 user credentials per system. Its Wiegand output is listed as compatible with the SDC IPPro Single Door Controller and, per spec, 'most access control systems,' reflecting the near-universal adoption of Wiegand in the industry.
For enterprise or multi-tenant sites requiring large credential databases or multi-door management under a single system, the IPRW300 provides concrete, spec-documented capacity. The PP-6005B's scalability is bound by the DMP panel model it connects to; those figures are not provided in the specs supplied here.
How does each reader handle physical installation environment, mounting, and durability?
The PP-6005B measures 3.135" × 1.70" × 0.51" — a slim, low-profile form factor. Its specs describe a weatherized enclosure suitable for covered exterior door installations. Operating temperature range and IP rating are not listed in the provided specs. Mount type is wall. Weight is not specified.
The IPRW300 carries an IP67 ingress-protection rating, confirming dust-tight and temporary-immersion resistance per the IEC 60529 standard. Its operating temperature range is stated as -40°F to +149°F, covering extreme cold and heat. It weighs 2 lbs and supports surface or mullion mounting. Dimensions are not listed in the provided specs.
For exposed outdoor, industrial, or harsh-environment installations, the IPRW300's IP67 rating and -40°F lower limit are explicit, spec-documented qualifications. The PP-6005B's environmental durability is described qualitatively ('weatherized') without a rated IP value or temperature floor in the data provided.
Which should you choose: the PP-6005B or the IPRW300?
Our take: The IPRW300 is the stronger choice when the installation demands broad panel compatibility, large-scale deployments, or proven harsh-environment durability. Its Wiegand output integrates with virtually any access control system, its 250,000-credential / 63-door capacity is spec-documented, and its IP67 rating with a -40°F to +149°F operating range provides verifiable environmental qualification the PP-6005B's specs do not match. The PP-6005B's differentiating advantage is its supervised loop communication: the panel can detect wiring faults in real time, a security posture Wiegand cannot replicate. The PP-6005B also supports dual credential widths (26-bit and 35-bit) for mixed-card environments, while the IPRW300 specifies HID 125 kHz only. Choose the PP-6005B exclusively within a DMP panel ecosystem where supervised tamper detection is a requirement. Choose the IPRW300 for any non-DMP platform, multi-door enterprise site, or installation exposed to extreme temperatures or moisture.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | DMP PP-6005B | SDC IPRW300 |
|---|---|---|
| Product Type | Proximity Reader | Proximity Reader / Controller |
| Communication Protocol | Supervised loop | Wiegand output |
| Credential Type | 26-bit & 35-bit proximity card | HID 125 kHz Prox |
| Operating Voltage | 4.75–16 VDC | 16 VDC |
| Mount Type | Wall | Surface or mullion |
| Door Capacity | — | 63 |
| Max User Credentials | — | 250,000 |
| IP Rating | — | IP67 |
| Operating Temp | — | -40°F to +149°F |
| Dimensions | 3.135" × 1.70" × 0.51" | — |
| Weight | — | 2 lbs |
| Panel Compatibility | DMP panels (734, 7073/7073A, 7173, 7873) | SDC IPPro & most AC systems |
| Supervised Tamper Detection | Yes (supervised loop) | No (Wiegand) |
| Warranty | Manufacturer warranty (term not specified) | Lifetime |
| Wiring Type | Wired | Wired |
| Connectivity Standard | Proprietary DMP supervised loop | Wiegand (industry standard) |
Frequently Asked Questions
Which should you choose: the PP-6005B or the IPRW300?
The IPRW300 is the stronger choice when the installation demands broad panel compatibility, large-scale deployments, or proven harsh-environment durability. Its Wiegand output integrates with virtually any access control system, its 250,000-credential / 63-door capacity is spec-documented, and its IP67 rating with a -40°F to +149°F operating range provides verifiable environmental qualification the PP-6005B's specs do not match. The PP-6005B's differentiating advantage is its supervised loop communication: the panel can detect wiring faults in real time, a security posture Wiegand cannot replicate. The PP-6005B also supports dual credential widths (26-bit and 35-bit) for mixed-card environments, while the IPRW300 specifies HID 125 kHz only. Choose the PP-6005B exclusively within a DMP panel ecosystem where supervised tamper detection is a requirement. Choose the IPRW300 for any non-DMP platform, multi-door enterprise site, or installation exposed to extreme temperatures or moisture.
Is the PP-6005B or IPRW300 better for larger deployments?
The IPRW300 is the spec-documented choice for large deployments: it supports up to 250,000 user credentials across 63 doors. The PP-6005B's capacity is determined by the connected DMP panel model — no standalone credential or door count is listed in its provided specs.
Can I use either reader with a non-DMP access control panel?
The IPRW300 outputs standard Wiegand, which is compatible with the SDC IPPro controller and, per spec, most access control systems. The PP-6005B uses a supervised loop protocol and lists compatibility only with specific DMP panel models (734, 7073/7073A, 7173, 7873); using it with a non-DMP panel is not supported by the provided specs.
Which reader is better suited for outdoor or harsh-environment installations?
The IPRW300 carries an IP67 rating and a stated operating range of -40°F to +149°F, providing explicit, standards-backed environmental qualification. The PP-6005B is described as having a weatherized enclosure for covered exterior use, but no IP rating or temperature range is listed in its available specs.
