IP Camera Accessories | Mounts, Enclosures, Lenses, IR & Power

Deployment Considerations

Environmental protection and weather resistance
Mounting stability and load support
Power and voltage compatibility
Cable management and termination quality
Compliance with local safety standards

Sub categories

Showing Results for Accessories

Compare

Add to Cart The item has been added
Hanwha

SKU: NOP-IO168S

Hanwha NOP-IO168S Access Control I/O Expansion Panel

16-input/8-output I/O expansion for NOP Series access controllers
- 16 supervised inputs with filtering plus 8 Form-C relay outputs at 2A/30VDC
- OSDP Secure Channel with AES 128/256 encryption over single RS485 line
- Expandable to 24 outputs via plug-in module; supports up to 16 boards multi-drop
In stock · Ships same business day

$1,420.00 $952.99 Save $467.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: NOP-RI2MS

Hanwha NOP-RI2MS Reader Interface Expansion Panel

Reader expansion panel with 2 Wiegand/OSDP ports and 4 relay outputs
- Supports up to 4 OSDP readers across 2 ports with AES 128/256 encryption
- 6 supervised alarm inputs with filtering plus 4 Form-C relays rated 2A @ 30VDC
- RS485 multi-drop daisy-chains up to 16 boards on single control bus
Special Order · Ships in 2-3 weeks

$1,035.00 $694.99 Save $340.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: FC29-016958A

Hanwha PNM-C16013RVQ 4MP AI Dome Camera

360° 4MP AI dome with 20m IR and IK09 impact resistance
- 4-channel AI detects persons, faces, vehicles, and license plates
- IP66 weatherproof, operates -40°C to +55°C in extreme climates
- PoE+ powered with 4 concurrent streams and microSD storage
Special Order · Ships in 2-3 weeks

$27.99 $26.99 Save $1.00

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: PT02-001002A

Hanwha PT02-001002A Waterproof Camera Cable

Waterproof IP camera cable for outdoor Hanwha systems
- IP67-rated connector protection guards against moisture ingress
- Standard IP camera connectors compatible with Hanwha surveillance
- Rated for harsh outdoor and moisture-prone installation environments
Special Order · Ships in 2-3 weeks

$7.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: PT02-001002B

Hanwha PT02-001002B Waterproof Camera Cable

Waterproof cable for Hanwha outdoor IP camera systems
- Sealed connector design resists moisture and wet conditions
- Purpose-built compatibility with Hanwha camera installations
- White finish blends into outdoor mounting environments
Special Order · Ships in 2-3 weeks

$6.99

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBB-300PMW1

Hanwha SBB-300PMW1 Installation Plate

Aluminum mounting plate for Hanwha PTZ and fixed cameras
- M6 metric screw mount works with standard anchors; no proprietary hardware
- 110 x 181mm compact footprint fits tight spaces without structural drilling
- RAL9003 white powder coat resists corrosion in outdoor and high-humidity zones
In stock · Ships same business day

$32.00 $21.99 Save $10.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBC-140WB

Hanwha SBC-140WB Polycarbonate Skin Cover for TNV-C8011RW

Black polycarbonate skin cover for TNV-C8011RW panoramic camera
- Precision-fit housing maintains optical clarity without image quality loss
- Impact-resistant polycarbonate resists UV degradation in outdoor deployments
- Full camera access for focus adjustment, lens positioning, and maintenance
In stock · Ships same business day

$40.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: SBC-160B

Hanwha SBC-160B Indoor Skin Cover, Black

Black skin cover for Wisenet X Series Plus indoor dome cameras
- Fits XND-6081V, XND-6081RV, XND-6081VZ, XND-8081RV, XND-8081VZ models
- Fully paintable surface allows customization to match facility décor
- Durable construction for reliable indoor surveillance installations
Special Order · Ships in 2-3 weeks

$50.99

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBC-160BF

Hanwha SBC-160BF Black Skin Cover for XND Series Cameras

Black plastic skin cover for XND series cameras—swap without reconfiguring
- Fits XND-6081VZ, XND-8081VZ, XND-6081V, XND-6081RV, XND-8081RV models
- High-quality plastic resists rain, dust, and UV degradation outdoors
- 3-pack covers mounting hardware for clean, finished appearance
In stock · Ships same business day

$50.00 $33.99 Save $16.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: SBC-170CB

Hanwha SBC-170CB Black Magnetic Skin Cover

Black magnetic skin cover for Hanwha X series IP cameras
- Tool-free 3-point magnetic attachment installs in seconds without tools
- Dust, rain, and UV resistant construction for indoor and outdoor use
- Discrete black finish reduces visual impact while protecting lens and sensor
Special Order · Ships in 2-3 weeks

$35.99

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBC-170CW

Hanwha SBC-170CW White Magnetic Skin Cover

White magnetic skin cover for Hanwha X-series cameras, tool-free install
- 3-point magnetic system installs without tools, screws, or mounting holes
- Dust and rain protection with UV resistance for interior and exterior use
- High-quality plastic construction blends into ceilings and walls without contrast
In stock · Ships same business day

$35.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: SBC-200B

Hanwha SBC-200B Black Dome Camera Skin Cover

Protective dome covers for PNM-C16013RVQ cameras, 3-pack polycarbonate
- Pack of 3 polycarbonate covers shields 4MP AI IR mini dome from dust and debris
- Lightweight at 65g per cover with ø199.9mm diameter for easy installation
- RAL9005 black finish rated for outdoor surveillance deployments
Special Order · Ships in 2-3 weeks

$50.99

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBD-110GP

Hanwha SBD-110GP Gangbox Mounting Plate (5-Pack)

Standardized gangbox plate for 25+ Hanwha camera models across 4 families
- Five plates per pack; works with QND, XND, HCD, and LND series cameras
- IP66 and IK10 rated for outdoor durability; operates -40°C to +55°C
- Reduces parts inventory and installation time on multi-camera deployments
In stock · Ships same business day

$45.99

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Hanwha

SKU: SBD-110GP1

Hanwha SBD-110GP1 Universal Adapter Plate for IP Cameras

Universal adapter plate for 20 Hanwha IP camera models
- Compatible with QNV, QND, QNF, LND, QNE, and ANE series cameras
- White adapter plate with mounting hardware and installation guide included
- Durable construction for indoor and outdoor mounting applications
In stock · Ships same business day

$20.00 $13.99 Save $6.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: SBD-137WMA

Hanwha SBD-137WMA Wall Adapter Plate White

White wall adapter plate for Hanwha dome cameras ø137.5mm
- Aluminum construction with RAL9003 white finish resists corrosion
- Circular ø137.5 × 6.7mm design enables rotational camera positioning
- TR20 mount screw compatibility with QNV-C8083R and QNV-C9083R models
Special Order · Ships in 2-3 weeks

$20.00 $13.99 Save $6.01

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: SBD-140KMB

Hanwha SBD-140KMB Corner Mount Adapter

SUS304 stainless steel corner mount for Hanwha Q/QN/QNE/LND/ANE cameras
- White RAL9003 finish, 121×102.5mm compact size fits discrete corner installations
- SUS304 stainless steel resists corrosion in indoor and outdoor environments
- Compatible with 20+ Hanwha camera models across Q, QN, QNE, LND, and ANE series
Special Order · Ships in 2-3 weeks

$70.00 $52.99 Save $17.01

Add to Cart
The item has been added

What to Look For When Buying

The six decisions that matter most before you spec.

Match Bracket to Camera + Surface

A dome camera mounted on a textured wall needs a wall-mount adapter with a gasket; mounted on a pole it needs a pole-mount arm; mounted on an eave it may need a pendant. Third-party brackets exist but brand-specific brackets include proper camera cable routing and weather gasketing. Buying a $40 generic bracket to save on a $80 Axis bracket usually costs more in installation time.

Enclosure NEMA Rating

NEMA 3R = light rain; NEMA 4 = splash + driving rain; NEMA 4X = above + corrosion resistance (coastal, industrial); NEMA 6 = temporary submersion. For weather-exposed camera enclosures, NEMA 4X is the commercial standard. For mission-critical outdoor gear, pair NEMA 4X enclosure + IP67 camera + IK10 vandal rating.

C/CS-Mount Lens Selection

Box cameras use interchangeable C-mount (17.526mm flange) or CS-mount (12.5mm flange). Lens focal length + sensor size determines field of view: a 4mm lens on a 1/3" sensor gives ~60° horizontal FOV. Our DORI guide covers lens selection by scene distance. F-stop matters for low-light; P-iris for auto-exposure.

IR Illuminator Wavelength

850nm IR is more efficient but produces a faint visible red glow (deterrent or accidental giveaway, depending on use case). 940nm is truly covert but requires ~2x the power for the same effective range, and many cameras have lower sensitivity at 940nm. Match illuminator wavelength to camera IR-cut filter spec, or image washout results.

Power Supply Sizing & Distance

12VDC cameras at 100ft from a power supply drop significant voltage over 18-gauge wire — a camera rated for 12V may see 10.5V at the camera end under load, triggering brownout resets. For long runs, use a higher-voltage power supply (24VAC or 48VDC) and step down at the camera. UL-listed surveillance power supplies (Altronix) publish voltage-drop tables.

Cable Jacket Rating

Indoor Cat6 is rated CM (communications); plenum-rated CMP is required for above-drop-ceiling runs per NFPA 70. Outdoor/direct-burial Ethernet is a different product (CMX, direct-burial gel-filled). Mixing jacket ratings causes code violations and fire inspector rejections. Always spec by run environment, not lowest-cost SKU.

Technology Stack

The specs and acronyms that actually affect outdoor performance.

NEMA vs IP Rating Systems

NEMA is the US enclosure standard (NEMA 1-13); IP is the international standard (IP00-IP68). Rough crosswalk: NEMA 4 ≈ IP66, NEMA 4X ≈ IP66 + corrosion, NEMA 6 ≈ IP67. Some spec sheets list both; when only one is given, the crosswalk is approximate. For coastal, industrial, and food-processing environments, specify NEMA 4X or IP66 + stainless steel.

C-Mount vs CS-Mount Lenses

C-mount: 17.526mm flange focal distance. CS-mount: 12.5mm flange. CS cameras accept both lens types (C lenses need a 5mm adapter ring); C cameras accept only C lenses. Most modern box cameras are CS-mount for lens flexibility. Lens thread is 1-inch × 32 TPI on both.

F-Stop / Iris

F-stop = focal length ÷ aperture diameter. Lower F-stop (wider aperture) means more light, better low-light performance, shallower depth of field. F1.4 is very low-light capable; F1.8 is common commercial spec. P-iris (precise iris) lenses auto-adjust aperture based on scene lighting — reduces over-exposure during day, improves low-light at night.

850nm vs 940nm IR

IR illuminators at 850nm are more energy-efficient and the sensitivity of most camera IR-cut filters peaks here — but 850nm produces a faint visible red glow from the LEDs. 940nm is invisible to human eye but requires ~2x the power or shorter effective range. Many covert-deployment cameras are re-tuned for 940nm sensitivity.

UL-Listed Power Supplies

Underwriters Laboratories listed power supplies meet safety standards for overcurrent, overvoltage, and enclosure isolation. UL 294 specifies additional requirements for access control; UL 603 for security burglary; UL 1310 for Class 2 power. Insurance and code requirements increasingly specify UL-listed supplies — particularly in commercial and institutional installations.

Plenum vs Riser vs PVC Cable

Plenum-rated (CMP) cable uses low-smoke FEP jacket for use above suspended ceilings where smoke spreads through return-air plenums. Riser (CMR) is for vertical shaft runs between floors. PVC (CM) is for open office runs only. Using CM in plenum spaces violates NFPA 70 — costly inspector rejection if caught.

Typical Deployment Scenarios

New Construction Retrofit

Cat6A plenum cable pulled to camera locations with proper service loops, 2-gang electrical boxes at each dome location with weatherproof backbox, Cat6A patch panel at the IDF, UL-listed power supplies for any 12V/24V camera, labeled and tested before cameras are mounted.

Coastal / Corrosive Environment

NEMA 4X stainless-steel enclosures for outdoor cameras, 316-grade stainless brackets, silicone dielectric grease on every connector, hot-dipped galvanized or powder-coated steel poles. Budget 15-25% more on accessories vs. standard outdoor — and plan for 3-5 year inspection cycles rather than 10.

Box-Camera LPR Application

Box camera with 50-150mm telephoto lens, dedicated 850nm IR illuminator at same height as camera, pole-mount bracket with junction box, UL power supply for camera + illuminator. LPR-specific enclosures with anti-reflective glass to avoid nighttime IR bloom. Typical deployment: dedicated lane camera, not general-purpose surveillance.

Parking Garage Retrofit

Existing analog coax cable replaced via NVT Phybridge or similar PoE-over-coax, vandal-resistant dome enclosures at ground level, low-profile bullet cameras on ceiling, LED-plus-IR-compatible illuminators to handle harsh fluorescent lighting. Enclosures rated for vehicle-exhaust environment.

Frequently Asked Questions

Do I need the OEM bracket for my camera, or will a generic bracket work?

For most commercial installations, specify the OEM bracket. Brand-specific brackets include proper cable routing, gasketed weather seals, and mounting-hole patterns matched to the camera — which matters more than the cost savings of a generic bracket. Generic brackets are acceptable for indoor standard-dome cameras on flat surfaces; for outdoor, vandal-rated, or pendant applications, use OEM.

What NEMA rating do I need for outdoor camera enclosures?

NEMA 4 for most weather-exposed deployments (driving rain, snow). NEMA 4X for coastal, industrial, or food-processing environments (adds corrosion resistance — typically stainless steel or fiberglass construction). NEMA 6 for temporary submersion or flood-prone areas. The IP-rating equivalent is IP66 for NEMA 4, IP66 + corrosion for NEMA 4X, IP67 for NEMA 6.

How do I choose the right lens focal length for a box camera?

Work backward from the scene. Identify the farthest point you need identification-grade coverage, use our DORI guide to calculate required pixels-per-foot at that distance, and match lens focal length + sensor size to deliver that PPF. A 4mm lens on a 1/3" sensor covers ~60° horizontal FOV; a 12mm lens on the same sensor covers ~20°. Wide FOV = shorter identification distance.

What's the difference between 850nm and 940nm IR illuminators?

850nm is more energy-efficient — you get more effective range per watt — but produces a faint visible red glow from the LEDs. 940nm is truly invisible to the human eye but requires about 2x the power for equivalent range, and many cameras have lower sensor sensitivity at 940nm. For deterrent visibility or cost-efficient long-range, 850nm; for covert applications, 940nm.

Can I power an IP camera with a generic 12V wall-wart?

Not for a commercial deployment. Generic wall-warts are unregulated, not UL-listed for security applications, and typically don't include surge protection. Use a UL-listed surveillance power supply (Altronix AL series, UL 294 or UL 603) with battery backup where required. PoE is preferred when possible — single cable, centralized power management, UPS-backed.

What cable jacket rating do I need for in-ceiling runs?

Plenum-rated (CMP) cable is required for any run through a return-air plenum space above suspended ceilings (most commercial buildings). Riser (CMR) for vertical shafts between floors. PVC (CM) for open office spaces only. Using non-plenum cable in a plenum space is a fire-code violation under NFPA 70 and will be rejected by inspectors. Budget plenum cable for any building where you're not 100% sure of the return-air path.

Accessories

Deployment Considerations

Sub categories

Showing Results for Accessories

Hanwha NOP-IO168S Access Control I/O Expansion Panel

Hanwha NOP-RI2MS Reader Interface Expansion Panel

Hanwha PNM-C16013RVQ 4MP AI Dome Camera

Hanwha PT02-001002A Waterproof Camera Cable

Hanwha PT02-001002B Waterproof Camera Cable

Hanwha SBB-300PMW1 Installation Plate

Hanwha SBC-140WB Polycarbonate Skin Cover for TNV-C8011RW

Hanwha SBC-160B Indoor Skin Cover, Black

Hanwha SBC-160BF Black Skin Cover for XND Series Cameras

Hanwha SBC-170CB Black Magnetic Skin Cover

Hanwha SBC-170CW White Magnetic Skin Cover

Hanwha SBC-200B Black Dome Camera Skin Cover

Hanwha SBD-110GP Gangbox Mounting Plate (5-Pack)

Hanwha SBD-110GP1 Universal Adapter Plate for IP Cameras

Hanwha SBD-137WMA Wall Adapter Plate White

Hanwha SBD-140KMB Corner Mount Adapter

Browse by Product Family

What to Look For When Buying

Technology Stack

Typical Deployment Scenarios

Top Brands for Outdoor Deployments

Frequently Asked Questions

Related Categories

Engineering Reading
