TP-Link EAP115-BRIDGE KIT 5GHz Wireless Bridge
Overview
The EAP115-BRIDGE KIT is a long-range 5GHz wireless bridge designed to extend network connectivity across outdoor surveillance deployments where running Ethernet is impractical. Delivers 300 Mbps throughput over point-to-point (PTP) or point-to-multipoint (PTMP) links up to 5 km, powered by 12V DC or 24V passive PoE — no separate power supply required on PoE sites. IP65 weatherproof rating and 6 kV lightning protection handle outdoor mounted installations. Operates indoors or outdoors, bridging IP cameras, access control readers, and intercoms across building campuses, parking structures, or remote perimeters where wireless is the only practical option.
Compatibility
Works with any IP camera, access control panel, intercom, or network device that accepts standard RJ45 Ethernet — no vendor lock-in. Supports ONVIF-compliant devices and integrates with Omada SDN Controller for centralized management across multiple EAP115 units. Compatible with standard PoE infrastructure (802.3af passive PoE at 24V). Auto-pairing feature simplifies field commissioning when linking multiple bridge units across a campus.
Installation Notes
Three 10/100 Mbps RJ45 ports allow one uplink and two local device connections per unit, or daisy-chain multiple bridges using PTP mode. Mount outdoors using weatherproof bracket (not included — verify mounting hardware separately). Position units with clear line-of-sight; dense foliage or metal obstacles degrade the 5 km maximum range. Lightning protection activates on direct or nearby strikes; pair with surge-rated PoE injectors on long cable runs. Operating temperature range is not specified in source evidence — confirm environmental suitability before deployment in extreme climates.
What's in the Box
- 1x EAP115-BRIDGE KIT Access Point
- 1x Power adapter (12V DC)
- 1x RJ45 Ethernet cable
