Pelco SRXE4-6V29-IMD-IR1 4MP Sarix Enterprise Dome

Pelco SRXE4-6V29-IMD-IR1 4MP Sarix Enterprise Dome Camera

The Pelco SRXE4-6V29-IMD-IR1 is a professional-grade indoor mini-dome camera built for high-security environments requiring FIPS 140-3 encryption and extended-range identification. Part of the Sarix Enhanced 4 Series, this camera combines a 4MP sensor, motorized varifocal lens, integrated infrared illumination, and advanced on-board analytics in a compact, vandal-resistant form factor.

Key Features

• 4MP resolution (2560 x 1440) at 60 fps with H.265, H.264, and Motion JPEG compression
• 1/1.8-inch progressive scan CMOS sensor with 130 dB SureVision WDR for high-contrast scenes
• 4.4–9.3 mm motorized varifocal lens with 32–109° horizontal field of view
• Integrated IR illumination delivering approximately 70 m at 850 nm wavelength
• Extreme low-light capability: 0.003 lux color, 0.001 lux mono, 0 lux with IR
• Smart Analytics: Person/Vehicle Detection, Direction Violation, Loitering, Beam Crossing, Crowd Detection, Audio Analytics, Tamper Alert
• FIPS 140-3 Level 3, TPM, Secure Boot, HTTPS, and 802.1X authentication
• ONVIF Profile S, T, G, and M compliant for platform-agnostic integration

Technical Specifications

• Durability: IP66 ingress protection, IK11 impact rating, -10°C to +65°C operating range
• Power & Connectivity: PoE+ (Class 3) or 12/24 Vdc; Ethernet-based
• Storage: microSD card support for local backup
• Compliance: NDAA Section 889, TAA compliant; 5-year warranty

Ideal Applications

Deploy the SRXE4-6V29-IMD-IR1 in government facilities, critical infrastructure, banking, healthcare, and enterprise campuses where cybersecurity, regulatory compliance, and long-range facial/object identification from ceiling mounts are mandatory. The motorized varifocal lens and wide WDR performance handle challenging lighting transitions in lobbies, corridors, stairwells, and controlled access points.

James Everett

This camera excels in FIPS 140-3–mandated environments where encryption at rest and in transit is non-negotiable. The 1/1.8-inch sensor and 130 dB WDR provide exceptional image quality in mixed-lighting scenarios common to indoor institutional settings. Smart Analytics reduce false alarms and enable proactive security operations.

Integration via ONVIF ensures vendor flexibility without proprietary lock-in. PoE+ power delivery simplifies installation. The 5-year warranty and TAA/NDAA compliance position this as a trusted choice for federal and regulated sectors.
