Pelco P2230L-FW1 Spectra Pro 2 2MP 30x PTZ Dome

Pelco P2230L-FW1 Spectra Pro 2 2MP 30x PTZ Dome

The Pelco P2230L-FW1 is a professional-grade PTZ dome camera from the Spectra Professional 2 series, engineered for demanding indoor surveillance applications requiring high-resolution detail capture and exceptional low-light performance. This flush wall-mount configuration delivers 2MP resolution at 60 fps with industry-leading 120 dB SureVision WDR technology, making it ideal for environments with extreme lighting contrasts.

Key Features

• 2MP resolution at 1920×1080, 60 fps for smooth motion tracking
• 30x optical zoom with 4.3–129 mm lens focal length
• 120 dB SureVision Wide Dynamic Range for high-contrast scenes
• 360° continuous pan with -90° to +1° tilt range
• 256 preset positions for rapid scene recall
• IP66/IP67 ingress protection; IK10 impact rating
• PoE+ powered with -10°C to +60°C operating range
• H.265, H.264, and Motion JPEG compression
• Auto-tracker, EIS, and motion detection analytics
• ONVIF Profile S, T, G, M compliant

Technical Highlights

The 1/2.8-inch progressive scan CMOS sensor captures fine detail across the 77° wide field of view down to 2.6° in telephoto mode. The 60 fps frame rate eliminates motion blur during fast-moving pursuit scenarios, while 120 dB SureVision WDR simultaneously balances bright windows and shadowed interiors—critical in airport terminals, casino floors, and retail concourses. Built-in auto-tracker enables operator-free target following, and Electronic Image Stabilization compensates for vibration in flush-mounted installations.

Installation and Integration

Flush wall-mount design requires adequate wall cavity depth; verify structural construction before ordering. The camera integrates seamlessly with Pelco management systems via full ONVIF Profile compliance and PoE+ networking. IP66/IP67 sealing and IK10 vandal resistance ensure long-term reliability in semi-outdoor and public-access environments. 5-year warranty included.

Applications

Ideal for airport terminals, casino gaming floors, retail environments, transportation hubs, and entertainment venues where high-frame-rate motion capture and dynamic lighting control are essential.
