Pelco P2230L-FW1 Spectra Professional 2 2MP 30x PTZ Flush Wall Camera
The Pelco P2230L-FW1 is a 2MP PTZ dome camera engineered for flush wall-mount installation in demanding indoor surveillance environments. The Spectra Professional 2 series combines 30× optical zoom with continuous 360° pan and proportional tilt control, enabling operators to track subjects across large transit terminals, retail concourses, arenas, and casinos without repositioning fixed cameras. Its recessed flush wall-mount design eliminates pendant or surface-mount visibility where aesthetics or spatial constraints matter.
Key Features
- 2MP resolution with 1920 × 1080 maximum output at 60 fps
- 30× optical zoom with 4.3–129 mm focal length range (77° wide to 2.6° tele HFOV)
- Continuous 360° pan and −90° to +1° tilt with proportional speed control
- 256 programmable presets for rapid scene recall
- 120 dB SureVision wide dynamic range for backlit and high-contrast scenes
- H.265, H.264, and Motion JPEG video compression
- Auto-tracker, EIS (electronic image stabilization), and motion detection analytics
- IP66/IP67 ingress protection and IK10 impact rating
- −10°C to +60°C operating temperature range
- PoE+ power support (confirm PoE+ availability in your network)
- ONVIF Profile S, T, G, and M compliance for third-party VMS integration
- 5-year manufacturer warranty
Technical Highlights
The 1/2.8-inch progressive scan CMOS sensor provides full-frame capture at 60 fps, ideal for smooth pan-tilt-zoom tracking of moving subjects. The 30× zoom range transitions smoothly from wide environmental context (77° HFOV) to identification-grade magnification (2.6° HFOV), allowing operators to frame subjects at range without repositioning the camera. SureVision WDR technology handles mixed lighting and silhouette conditions common in transit hubs and retail environments.
Flush wall integration requires careful planning—confirm wall cavity depth and construction type before ordering. Installation in drywall, masonry, or composite surfaces demands proper backing support and weathersealing. The IP66/IP67 ratings ensure dust and moisture resistance during and after installation.
Applications
- Transit terminals and airport concourses
- Retail and shopping centers with large sightlines
- Arenas and sports venues
- Casino gaming floors and common areas
- Educational institutions with large gathering spaces
- Museums and cultural facilities where pendant domes are aesthetically unacceptable
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The P2230L-FW1 targets deployments where form factor and zoom capability matter equally. Its 2MP resolution is adequate for behavioral tracking and operator-directed motion but may limit post-event forensic zoom and license plate capture at extreme distances. Organizations requiring higher detail should evaluate 4MP+ variants or assess zoom-to-resolution trade-offs for their sightlines.
The flush wall-mount form factor eliminates visual clutter in public spaces but introduces installation complexity. Poor cavity installation or weathersealing failures can compromise IP ratings. Budget for professional installation and post-installation testing.
ONVIF multi-profile support ensures broad VMS compatibility (Milestone, Genetec, Exacq, etc.), avoiding vendor lock-in. PoE+ is a deployment advantage in spaces where 24 Vac wiring is unavailable, though confirm your network infrastructure supports the power budget.
Available in White.
