Honeywell HF810-11WT00004K-R vs Honeywell HF811-01WT00004K-R: Specification Comparison
Both the HF810-11WT00004K-R and HF811-01WT00004K-R are fixed-mount corded 1D linear imager barcode scanners from Honeywell's HF800 series, positioned for industrial and warehouse deployment. Each shares the same scan technology, decode capability, connectivity options, IP rating, and warranty class, making them direct cross-shop candidates for buyers evaluating a fixed-mount 1D scanner solution for manufacturing lines, loading docks, or point-of-sale integration. The comparison centers on the documented spec differentiators between the two part numbers.
In This Guide
- What are the scan type, decode capability, and imaging performance differences between the HF810-11WT00004K-R and HF811-01WT00004K-R?
- How do the HF810-11WT00004K-R and HF811-01WT00004K-R differ in connectivity and system integration options?
- Which model is better suited for demanding physical environments based on IP rating, operating temperature, and weight?
- Which should you choose: the HF810-11WT00004K-R or the HF811-01WT00004K-R?
- Side-by-Side Specs
- FAQ
What are the scan type, decode capability, and imaging performance differences between the HF810-11WT00004K-R and HF811-01WT00004K-R?
Both units are fixed-mount linear imagers rated for 1D barcode decode only — neither supports 2D symbologies such as QR or Data Matrix. Both are specified with 2MP imaging resolution, and both are noted to handle high-density and damaged barcodes reliably.
No spec-documented difference in optical engine, scan rate, scan angle, or minimum element size is present in the provided data for either model. Buyers requiring verified differentiation at the imaging or decode-performance level should consult the manufacturer datasheets linked for each unit, as those deltas — if any — are not captured in the provided specifications.
How do the HF810-11WT00004K-R and HF811-01WT00004K-R differ in connectivity and system integration options?
Both models share identical corded connectivity: RS-232 and USB interfaces are specified for each. Neither model lists wireless, Ethernet, or auxiliary interface options in the provided specs.
The HF811-01WT00004K-R's card bullets explicitly call out POS and warehouse system integration via RS-232/USB, while the HF810-11WT00004K-R's bullets reference warehouse and manufacturing floor contexts. These are use-case framings, not spec-level differences — the physical interface set is identical per the provided data.
Which model is better suited for demanding physical environments based on IP rating, operating temperature, and weight?
Both models carry an IP42 dust and moisture protection rating. The HF810-11WT00004K-R has a documented operating temperature range of 0° to 50°C and is flagged Outdoor Ready: Yes, with explicit mention of loading dock suitability. Operating temperature and outdoor-ready status are not specified in the provided data for the HF811-01WT00004K-R.
The HF810-11WT00004K-R is listed at 0.4 lbs. No weight figure is provided for the HF811-01WT00004K-R. Both carry a 3-year warranty. Where environmental hardening data is a decision factor, the HF810-11WT00004K-R has more complete spec coverage in the provided data.
Which should you choose: the HF810-11WT00004K-R or the HF811-01WT00004K-R?
Our take: The HF810-11WT00004K-R is the stronger documented choice when operating temperature range and outdoor-readiness are decision criteria. It carries a confirmed 0° to 50°C operating range and an explicit Outdoor Ready designation absent from the HF811-01WT00004K-R's provided specs. It also includes a weight figure (0.4 lbs) not documented for the HF811. Beyond those three differentiators, the provided specifications for both units are materially identical: same HF800 series, same fixed-mount 1D linear imager type, same 2MP imaging, same IP42 rating, same RS-232/USB corded connectivity, same 1D-only decode capability, and the same 3-year warranty. Buyers whose deployments are exclusively interior, temperature-controlled environments may find the HF811-01WT00004K-R equally suitable, but should verify its environmental ratings directly against the manufacturer datasheet before committing.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Honeywell HF810-11WT00004K-R | Honeywell HF811-01WT00004K-R |
|---|---|---|
| Series / Family | HF800 | HF800 |
| Product Type | Scanner | Scanner |
| Scan Type | Fixed Mount Linear Imager | Fixed Mount Linear Imager |
| Decode Capability | 1D | 1D |
| Imaging Resolution | 2MP | 2MP |
| IP Rating | IP42 | IP42 |
| Connectivity | Corded RS-232 / USB | Corded RS-232 / USB |
| Operating Temperature | 0° to 50°C | — |
| Outdoor Ready | Yes | — |
| Damaged Barcode Handling | Yes | Yes |
| Weight | 0.4 lbs | — |
| Warranty | 3-year | 3-year |
| Part Number | HF810-11WT00004K-R | HF811-01WT00004K-R |
Frequently Asked Questions
Which should you choose: the HF810-11WT00004K-R or the HF811-01WT00004K-R?
The HF810-11WT00004K-R is the stronger documented choice when operating temperature range and outdoor-readiness are decision criteria. It carries a confirmed 0° to 50°C operating range and an explicit Outdoor Ready designation absent from the HF811-01WT00004K-R's provided specs. It also includes a weight figure (0.4 lbs) not documented for the HF811. Beyond those three differentiators, the provided specifications for both units are materially identical: same HF800 series, same fixed-mount 1D linear imager type, same 2MP imaging, same IP42 rating, same RS-232/USB corded connectivity, same 1D-only decode capability, and the same 3-year warranty. Buyers whose deployments are exclusively interior, temperature-controlled environments may find the HF811-01WT00004K-R equally suitable, but should verify its environmental ratings directly against the manufacturer datasheet before committing.
Is the HF810-11WT00004K-R or HF811-01WT00004K-R better for outdoor loading dock applications?
Based on the provided specs, the HF810-11WT00004K-R is the documented choice for loading dock use. It carries an explicit Outdoor Ready: Yes designation and a confirmed operating temperature of 0° to 50°C. The HF811-01WT00004K-R does not have outdoor-ready status or operating temperature documented in the provided specifications.
Do both the HF810-11WT00004K-R and HF811-01WT00004K-R support 2D barcodes like QR codes?
No. Both models are specified as 1D decode only in the provided data. Neither lists 2D symbology support such as QR Code, Data Matrix, or PDF417. Buyers requiring 2D decode capability should evaluate a different product line.
Are the RS-232 and USB connectivity options the same on both models?
Yes. Both the HF810-11WT00004K-R and HF811-01WT00004K-R list corded RS-232/USB as their connectivity in the provided specifications. No wireless or additional interface options are documented for either model.
