Axis FA1080-E Thermal IP Camera Sensor Unit

Axis FA1080-E Thermal IP Camera Sensor Unit

The Axis FA1080-E Thermal Sensor Unit (SKU: 01728-001) is a specialized thermal imaging module designed to integrate with the AXIS FA54 Main Unit for comprehensive 24/7 surveillance. This uncooled microbolometer sensor delivers reliable heat-based detection in complete darkness, through smoke, fog, and adverse weather conditions—making it ideal for perimeter security, critical infrastructure monitoring, and outdoor surveillance applications where traditional visible-light cameras fall short.

Key Features

• Uncooled microbolometer thermal sensor with <100 mK thermal sensitivity (NETD)
• 208x156 thermal resolution for efficient processing and storage
• Dual lens options: 2.2 mm (63° field of view) and 4 mm (35.4° field of view)
• 8.3 fps frame rate for smooth thermal video streaming
• IP66-rated for outdoor deployment in harsh environments
• Operating range: -30 to 55°C for extreme temperature conditions
• Wired connectivity for stable, continuous operation
• Multi-channel configuration supporting up to four thermal sensors

Technical Specifications

The FA1080-E sensor achieves exceptional thermal sensitivity below 100 mK, enabling detection of subtle temperature variations critical for identifying people and vehicles. The 208x156 pixel thermal array provides adequate resolution for long-range perimeter monitoring without excessive bandwidth demands. Dual focal length options (2.2 mm and 4 mm) allow deployment flexibility: the wider 63° field of view suits broad area coverage, while the narrower 35.4° variant targets specific zones requiring deeper focal depth. With an 8.3 fps capture rate, the sensor balances real-time responsiveness with efficient network utilization.

The IP66 weatherproof rating and -30 to 55°C operating temperature range ensure reliable performance in demanding outdoor environments including construction sites, industrial facilities, border security, and infrastructure perimeters. The wired connection eliminates wireless connectivity issues and ensures stable data transmission.

Applications

• Perimeter security for critical infrastructure and industrial sites
• Construction site and asset protection
• Border and maritime surveillance
• Wildfire and industrial fire detection
• Search and rescue operations
• Vehicle and personnel detection in low-light environments

Eden Phillips

The FA1080-E represents a mature thermal imaging platform optimized for integration into multi-sensor surveillance systems. Its uncooled microbolometer design eliminates the maintenance and operational complexity of cooled sensors while maintaining excellent thermal discrimination below 100 mK. The dual-lens configuration addresses real-world deployment scenarios—organizations can standardize on a single sensor platform while selecting appropriate optics per installation requirements.

The 208x156 native resolution is purposefully conservative for thermal imaging, reflecting the physics of radiometric detection where thermal contrast matters more than pixel density. This restraint delivers meaningful bandwidth and storage advantages in continuous-operation security deployments. The 8.3 fps frame rate, while modest compared to visible-spectrum cameras, aligns with typical human and vehicle movement patterns and minimizes network overhead.

IP66 durability and the extended -30 to 55°C temperature range position this sensor for true outdoor-ready installations. Integration with the FA54 Main Unit enables sophisticated multi-camera deployments with coordinated thermal monitoring across expansive perimeters. The wired architecture ensures operational reliability superior to wireless alternatives in security-critical applications.
