HES

HES · 5000-12/24D-630

HES 5000-12/24D-630 Dual-Voltage Electric Strike

Fail-secure strike with 12/24V DC selectable power for access control

• Dual-voltage operation (12V or 24V DC) eliminates SKU duplication across sites
• Fail-secure design locks on power loss or control signal failure for high-security areas
• Standard door frame form factor integrates with proximity readers and access panels

HES · 7440-628

HES 7440-628 Ultraline Electric Strike for Radius Jamb

Ultraline electric strike built for radius jamb frames in commercial doors

• Compact Ultraline profile fits tight radius jamb installations without frame mods
• Clear anodized aluminum resists corrosion in institutional and healthcare settings
• Integrates with standard 12VDC electric strike control systems and keypads

HES · 1500C-630-LMS

HES Complete electric strike Kit - 1500C-630-LMS

When you need to retrofit an electric strike into an existing frame without field fabricating brackets or hunting down compatible components, this

• Complete kit ships with strike body, faceplate, bracket, and hardware—no field fabrication needed.
• Integrated latchbolt monitor switch feeds real-time door status to your access control system.
• 630 satin stainless finish resists corrosion and aligns with standard commercial door hardware.

HES · 1500C-630

HES 1500C-630 -Complete Electric Strike Kit

When you're specifying electric strikes for commercial access control installations, you need a solution that handles the full scope of door hardware

• Complete kit ships with strike body, faceplates, and all mounting hardware in one order.
• 630 satin stainless finish resists corrosion and matches standard architectural hardware.
• Supports both failsafe and failsecure wiring configs for flexible security policy deployment.

HES · 1200LBDURO

HES 1200LBDURO Alarm Controls 1200LB Single Magnetic Lock

• 1,200 lb holding force on a UL-listed fail-safe lock rated for commercial doors.
• 12/24V DC field-selectable with built-in door position sensor and bi-color LED.
• DURO reinforced aluminum body with a lifetime warranty reduces service callbacks.

HES · 1200D

HES Alarm Controls 1200D Double Door Magnetic Lock 1 200lbs.

When you need to secure double doors in high-traffic commercial environments without the mechanical complexity of mortise locks or electric strikes

• Single housing delivers 1,200 lbs combined force (600 lbs/door) across both leaves.
• 12/24V DC field-selectable with built-in door position sensor and bi-color LED status.
• UL Listed, fail-safe, zero moving parts; backed by a lifetime warranty.

HES · 10620423

Hes Sb:1006-F-12/24D-Blk - 10620423

When you're specifying electric strikes for commercial access control installations, field adjustability and dual voltage capability eliminate

• Accepts 12VDC or 24VDC input, eliminating the need to stock separate voltage SKUs.
• Fail-secure design keeps the door locked during power loss, maintaining site security.
• Field-reversible faceplate and ANSI 1-1/4"×4-7/8" cutout simplify on-site retrofits.

HES · 10620408

Hes Sb:1006-12/24D-630-Lbm - 10620408

• 12/24V DC field-selectable operation eliminates separate SKUs across mixed-voltage deployments.
• Integrated LBM reports latchbolt status directly to access panels, removing add-on door sensors.
• UL 1034 and UL 10C (3-hr fire) listed; 1,500 lb static strength with 1,000,000-cycle endurance.

HES · 10600011

HES OPTION:5200-500 Filler Block - 10600011

When installing HES 5200 series electric strikes in frames with oversized prep or non-standard cutouts, you need a reliable way to fill gaps and

• Fills oversized or non-standard frame cutouts for proper 5200 series strike alignment.
• Satin stainless steel (630 finish) maintains structural integrity under repeated cycling.
• Field-installable direct replacement reduces retrofit callbacks caused by prep mismatches.

HES · 1006CS-F-630

HES 1006 Complete Pacs With Smart PAC III - 1006CS-F-630

When you need a fail-secure electric strike that combines proven mechanics with intelligent power management, the HES 1006 Complete PACS delivers a

• Fail-secure electric strike — doors stay locked on power loss
• Smart PAC III power supply with built-in status LEDs
• 1006 surface-mount strike in 630 stainless finish

HES · 1006CS-630

HES 1006 Complete Pacs for Latchbolt Locks - 1006CS-630

When you're integrating electric strikes into an access control deployment with latchbolt locksets, the last thing you need is to piece together

• Fail-secure mode keeps doors locked on power loss, meeting perimeter security posture.
• UL 1034 and UL 10C (3 hr fire) listings satisfy code requirements for commercial openings.
• 1,500 lb static strength and 1M-cycle rating handle high-traffic commercial door demands.

HES · 1006CLB-630

Hes 1006 Complete Pacs For Latchbolt Locks - 1006CLB-630

Retrofitting legacy mechanical latchbolt locks into access control systems typically means replacing hardware or field-fabricating strike solutions

• Fits standard ANSI A115.1 cylindrical cutout—no door prep modification required.
• Field-selectable fail-safe/fail-secure on 12/24V DC eliminates redundant SKUs.
• UL 10C 3-hour fire-rated with 1,500 lb static strength and 1M-cycle endurance.

HES · 1006-F-630

Hes 1006 Electric Strike Body Stainlss Steel - 1006-F-630

When you need a retrofit electric strike that handles high-traffic openings without tearing out the frame, the HES 1006 delivers a field-proven

• Fits ANSI A115.1 cylindrical cutout, minimizing frame modification on retrofit installs.
• 1,500 lb static / 70 ft-lb dynamic strength with 1,000,000-cycle endurance rating.
• UL 1034 and UL 10C (3-hour fire) listed; 12/24V DC field-selectable for flexible wiring.

HES · 1006-630

HES Fail Secure Universal 12/24VDC Electric Strike - 1006-630

Fail-secure electric strike designed for standard wooden and metal door frames in commercial access control installations

• Fail-secure operation keeps the door locked during power loss, protecting secured areas.
• Accepts 12V or 24VDC input, fitting existing power architectures without added conversion hardware.
• Universal frame footprint installs on wood or metal frames, reducing retrofit fabrication time.

HES · RP-20

HES RP-20 Radius Faceplate

Radius faceplate for curved door frames, direct HES strike fit

• Radius-curved profile seats flush on rounded door frames, eliminating installation gaps.
• Engineered for direct HES electric strike compatibility — no adapters or modifications needed.
• Lightweight at 0.1 lb; US-made construction suits institutional and commercial retrofits.

HES · RP-24SG

HES RP-24SG Single Gang Front Plate

Single gang front plate for HES RP-24 readers in standard wall boxes

• Fits standard North American single gang boxes—no extra framing or wall cutting needed.
• Direct mechanical fit for HES RP-24 reader systems eliminates adapters and custom mods.
• Domestically manufactured wall-mount plate at 1.1 lb keeps hardware inventory lightweight.

HES · DL-1

HES DL-1 Door Loop 18 inch .250 ID

18" door loop with .250" ID for HES electromechanical access systems

• 18-inch length fits standard hollow metal and wood frames with no extension splicing.
• .250" ID precision-matched to HES 5000/7000 series hardware, eliminating mechanical slop.
• Plastic end caps resist corrosion and block water intrusion at frame termination points.

HES · EXD-1L

HES EXD-1L Exit Delay System Module

Configurable exit delay relay for HES electromagnetic locks

• Centralizes exit delay logic for up to 92 doors from a single 0.25 lb module.
• Native 24VDC input integrates directly with standard access control panels and lock controllers.
• Wiegand communication lets credential readers trigger delay sequences without protocol conversion.

HES · DPS-W-BK

HES DPS-W-BK Door Position Switch for Wood Doors

Surface-mount door position switch for wood frames, no drilling

• Door position switch engineered for wood doors (black)
• Surface-mount install - no drilling or routing required
• Cuts install labor on wood door retrofit projects

HES · DPS-W-WH

HES DPS-W-WH Door Position Switch for Wood Doors

Wood door position switch with dry contact output for access control

• Engineered for wood door frames, eliminating retrofit fitment issues at installation.
• Delivers dry-contact open/closed binary feedback directly to access control panels.
• Lightweight at 0.05 lb, minimizing door hardware load on standard wood frame assemblies.
