Frame Rate:
20fps
Sensor Type:
1/3" (4 MP) progressive scan CMOS
Minimum Illumination:
0.03 Lux (B/W, IR)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Auto-Iris:
No
Day/Night:
IR cut filter
Digital Noise Reduction:
3D DNR
Features:
120 dB
Angle Adjustment (Bracket:
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
Focal Length:
2.8 mm, 4 mm, or 6 mm
Aperture:
ƒ/2.0
Focus:
No
Field of View:
52° H / 29° V / 63° D
Lens Mount:
M12
IR Distance:
2.8 mm/4 mm: up to 65 ft (20 m); 6 mm: up to 100 ft (30 m)
Wavelength:
850 nm
Video Compression:
H.265+/H.265/H.264+/H.264/MJPEG
H.264 Type:
Baseline profile/main profile/high profile
H.264:
Main stream
Video Bit Rate:
32 Kbps to 16 Mbps
Region of Interest:
One fixed region for main stream and sub-stream
Max Resolution:
2560 × 1440
Main Stream:
20fps@2560x1440, 30fps@1080p
Sub-Stream:
30 fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:
BLC, 3D DNR
Image Setting:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or Web browser
Day Night Switch:
Day, night, auto, scheduled
Nework Storage:
Supports NAS (NFS,SMB/CIFS)
Alarm Trigger:
Motion detection, tampering, network loss, HDD error
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1x, QoS, IPv6, UDP, Bonjour
General Function:
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live Views:
Up to 6 channels
User/Host:
32 users; 3 levels
Client:
iVMS-4200, Hik-Connect
Web Browser:
IE 8+, Chrome 31 to 44, Firefox 30.0 to 51, Safari 8.0+
Communication Interface:
1-Port RJ-45 10M/100M self-adaptive Ethernet port
Operating Temperature:
-30° to 60°C
Power Type:
12 VDC / PoE 802.3af
Power Consumption and Current:
12 VDC 0.5A / PoE 6.5W max
Protection Level:
IP67
Material:
Metal
Dimensions:
Camera: Ø4.3" x 3.7" (Ø110 mm x 93.2 mm)
Weight:
Camera: 0.80 lbs (360 g)
Housing Color:
White
