ACTi A423 6MP Zoom Bullet Camera
ACTi A423 6MP Zoom Bullet Camera Overview The ACTi A423 is a 6MP motorized zoom bullet designed for outdoor perimeter and wide-area surveillance where…
ACTi A423 6MP Zoom Bullet Camera
$854.00
$708.99
Your recommended setup
Review items below — quantities update pricing automatically.
Item
Qty
Status
Price
Optional Add-Ons recommended
Services optional
Bundle Summary
Bundle Subtotal:
$0.00
Optional Add-Ons:
$0.00
Services:
$0.00
Total:
$0.00
Overview
SKU:
A423
Condition:
New
No Bots, Just Experts
Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.
Send Laura a Message
Senior Specialist · Typically replies within 1 business day
Description
ACTi A423 6MP Zoom Bullet Camera
Overview
The ACTi A423 is a 6MP motorized zoom bullet designed for outdoor perimeter and wide-area surveillance where you need optical magnification without resolution loss. The 5x zoom lens (2.7–13.5mm) lets you frame subjects at distance—critical for parking lots, building facades, and entry corridors where fixed focal lengths force you to choose between wide coverage and detail capture. Its 150dB extreme WDR handles mixed lighting (sun-blasted areas adjacent to shadows) without halo artifacts or washout. IR LED (850nm, 85m range) extends operation into complete darkness at 0.003 lux minimum illumination. Rated IP68 (dust and water immersion proof) and IK10 (impact resistant), the A423 survives vandal-prone and harsh-weather deployments across −40°C to +60°C operating range.
Compatibility
The A423 integrates into any ONVIF-compliant VMS platform (Profile S, G, T, M support). It connects via single 10/100 Base-T Ethernet port with RJ-45 pigtail connector. PoE++ (802.3bt) Class 3 powers the zoom motor and IR array at up to 95W; legacy DC 12V or PoE Class 3 (802.3af) backup inputs are supported. H.265, H.264, and MJPEG compression allow bandwidth optimization across mixed-bandwidth networks. Deep Learning-based people and vehicle detection (DLPU) and video motion detection (VMD) trigger alerts in third-party platforms supporting ONVIF event schemas. Audio input (2-way, line-in/line-out) integrates ambient sound capture for incident verification.
Installation Notes
Mount via pole or corner-mount accessories (sold separately). Lens adjustment spans pan 0°–355°, tilt 0°–90°, and full 360° rotation for repositioning without remounting hardware. Electronics cooling is passive; ensure airflow around the lens barrel in direct sun. 95W PoE++ demand requires IEEE 802.3bt-capable switches or injectors—standard PoE injectors (13W budget) will not support zoom and IR simultaneously. RJ-45 pigtail connector requires weatherproof termination or pre-terminated cables in outdoor installations.
Specifications
Resolution:
6MP (3864 x 2192)
Ip Rating:
IP68
Ik Rating:
IK10
Poe Power:
PoE++ (802.3bt) Class 3
WDR:
Extreme WDR 150dB
Ir Lowlight:
IR; 850nm
Compression:
H.265; H.264; MJPEG
ONVIF:
Yes
Audio:
Audio input; 2-way; Line-in; Line-out
Analytics:
Deep Learning (DLPU); VMD
Lens Focal Length:
2.7-13.5 mm (5x optical zoom)
Mount Type:
Pole; Corner
Color:
Min. Illumination 0.003 lux
Product Type:
Zoom Bullet
Application:
Environment Outdoor
Print Resolution:
6MP
Lens:
2.7–13.5mm (5x optical zoom); Board mount
Ethernet Rate:
Port 1 x Ethernet (10/100 Base-T), RJ-45 pigtail connector
Gps:
Position Manual setting
Power Supply:
DC 12V, PoE Class 3 (IEEE802.3af)
Operating Temp:
-40°C ~ 60°C (-40°F ~ 140°F)
Mounting:
Accessories - Camera Mount
Brand:
ACTi
MPN:
A423
Type:
6MP Zoom Bullet Camera
ip_rating:
IP68
ik_rating:
IK10
poe_power:
PoE++ (802.3bt) Class 3
ir_lowlight:
IR; 850nm
lens_focal_length:
2.7-13.5 mm (5x optical zoom)
mount_type:
Pole; Corner
Product_Type:
Zoom Bullet
Print_Resolution:
6MP
Ethernet_Rate:
Port 1 x Ethernet (10/100 Base-T), RJ-45 pigtail connector
Power_Supply:
DC 12V, PoE Class 3 (IEEE802.3af)
Dimensions:
(L x W x H): 297.1mm x 96.2mm x 91.5mm (11.7" x 3.8" x 3.6")
Operating_Temp:
-40°C to 60°C (-40°F to 140°F)
Warranty:
3 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty
Wattage:
95W
Compatible With:
flexible
Connector:
RJ-45
PoE:
PoE
PoE_Power:
PoE++ (802.3bt) Class 3; DC 12V; PoE Class 3 (802.3af)
IR_Lowlight:
IR LED (850nm, 85m); 0.003 lux color; 0 lux B/W (IR on)
Form_Factor:
Bullet
Max_FPS:
30 fps
IR_Range:
85m
Sensor_Size:
1/2.4 inch
Min_Illumination:
0.003 lux (color); 0 lux (B/W with IR on)
Certifications:
UL Taiwan IoT Cybersecurity Certification
VMS_Compatibility:
ONVIF Profile S; Profile G; Profile T; Profile M
PoE_Wattage:
95W
PTZ_Range:
Pan 0°–355°; Tilt 0°–90°; Rotation 0°–360°
