Vivotek AP-PSP-050 16KV Outdoor PoE Surge Protector

Vivotek AP-PSP-050 16KV Outdoor PoE Surge Protector Module

The Vivotek AP-PSP-050 is a professional-grade surge protection module engineered to safeguard outdoor PoE-powered surveillance and network equipment from damaging electrical surges. With 16KV surge protection capability and a robust IP67 weatherproof rating, this dual-port module delivers reliable protection in harsh outdoor environments where lightning strikes and power fluctuations pose significant risks to sensitive electronics.

Key Features

• 16KV maximum discharge current protection (8KA per line)
• Dual 2-port RJ45 connectors for flexible deployment
• IP67 waterproof rating for outdoor installation
• Ultra-fast 5ns response time to detect and suppress surges
• Support for Gigabit Ethernet pass-through (10/100/1000 Mbps)
• PoE support up to 95W with 60VDC maximum operation voltage
• Compact dimensions (186.2 x 50 x 32 mm) for easy mounting

Technical Highlights

The AP-PSP-050 provides comprehensive surge protection across multiple modes: 20KV common mode protection and 4KV differential mode protection with clamping voltages as low as 600V line-to-ground and 20V line-to-line. Signal integrity is maintained with minimal insertion loss (1 dB @ 10/100MHz) and excellent return loss (-20 dB), ensuring uninterrupted data transmission. The module operates reliably across extreme temperatures (-40°C to 85°C) and maintains an impressive MTBF of 1,132,887 hours.

Applications

• Outdoor IP camera surveillance systems
• Wireless access point installations
• Outdoor network infrastructure protection
• Lightning-prone geographical regions
• Remote monitoring stations and field deployments

With certifications including CE, FCC, VCCI, and compliance with ITU-T K.21 and IEC-61643-21 surge standards, the AP-PSP-050 meets international safety and performance requirements. A 12-month warranty backs the investment in network protection.
