Panduit CJSLRCAPBU-X 45° Angled Wire Cap for Cat 6A Shielded Jack
The Panduit CJSLRCAPBU-X is a shielded 45° angled wire cap engineered specifically for terminating Panduit Cat 6A shielded TG-style modular jacks in the Pan-Net copper system. The angled design routes patch cords away from panel faces at a controlled 45° exit angle, reducing cable stress at the termination point while maintaining full end-to-end shielding continuity required for 10GBASE-T performance over twisted-pair copper. This left/right orientation cap accommodates bidirectional cable routing in high-density patch panel and wall-plate deployments where horizontal or vertical cable management pathways demand predictable exit geometry. Each cap snaps securely onto Panduit TG jack housings to preserve the 360° shield connection from plug to jack to backbone infrastructure, preventing EMI ingress that degrades alien crosstalk performance in tightly bundled Cat 6A channel links.
Key Features
- 45° angled wire exit reduces bend radius stress on Cat 6A cables at termination points
- Left/right orientation supports bidirectional horizontal cable routing in patch panels and surface-mount boxes
- Maintains full shielding continuity for Panduit TG-style shielded jacks per TIA-568.2-D alien crosstalk requirements
- Blue housing provides visual port identification in multi-service or VLAN-segregated network installations
- Snap-fit attachment to Panduit TG jack modules - no tools or fasteners required for cap installation
- Packaged in cartons of 100 (10 per inner package) for large-scale datacenter and enterprise campus deployments
In structured cabling installations where Cat 6A shielded links are specified for 10GBASE-T Ethernet, maintaining unbroken shield continuity from patch cord plug through the jack and into the permanent link is non-negotiable. The CJSLRCAPBU-X wire cap completes the shield termination by enclosing the wire pairs and cable jacket in a conductive housing that bonds to the TG jack's internal shield. The 45° exit angle is purpose-built for scenarios where cables must route horizontally along a wall or rack rail immediately after leaving the jack - common in high-density patch panels, under-desk consolidation points, and zone enclosures where vertical space behind the faceplate is limited. Unlike straight or 90° caps that force sharp bends or consume excessive depth, the 45° geometry splits the difference: cables exit at a natural angle that aligns with horizontal cable managers or baseboard pathways while keeping the installed depth shallow enough for standard 2-inch back boxes and 1RU patch panels.
The left/right orientation designation means the cap is designed to route cables either left or right from the jack's centerline when viewed from the front. This bidirectional flexibility is critical in patch panel layouts where alternating jacks feed cables to opposite sides of the panel frame, or in multi-gang wall plates where some jacks serve workstations to the left and others to the right. The blue color coding integrates into structured cabling color schemes - commonly used to denote specific VLANs, service tiers, or physical zones in large enterprise and datacenter networks. Installers can use cap color as a visual confirmation layer alongside port labels, reducing mis-patch incidents during MAC moves or troubleshooting. The cap snaps onto the rear of the TG jack module after conductors are terminated and the cable jacket is seated - installation takes seconds per jack and requires no additional hardware, making it practical even in 48-port or 96-port panel builds where time per termination directly impacts labor cost.
This wire cap is part of the Panduit Pan-Net copper cabling system, engineered to meet and exceed TIA-568.2-D Category 6A channel performance requirements including alien crosstalk (ANEXT/AFEXT) margins that safeguard 10GBASE-T link integrity in high-density bundle environments. When specified as part of a complete Pan-Net channel - Panduit shielded cable, TG jacks, angled wire caps, shielded patch cords, and bonded patch panels - the system is backed by Panduit's 25-year application assurance warranty covering both component performance and installed channel certification. For datacenter operators, enterprise IT teams, and AV integrators deploying 10G copper infrastructure for IP cameras, access points, or server top-of-rack connections, using manufacturer-matched shielding accessories like the CJSLRCAPBU-X eliminates the single-point-of-failure risk introduced by mixing third-party termination components that may not maintain the shield bond required for certified alien crosstalk performance.
