i-PRO WV-CW634F Super Dynamic 6 Vandal-Resistant Fixed Camera

i-PRO WV-CW634F Vandal-Resistant Fixed Dome Camera

Overview

The WV-CW634F is an IP66-rated vandal-resistant dome built for high-security indoor and transitional spaces where physical tampering and spray-down cleaning are routine. The 1/3-inch interline transfer CCD sensor delivers 700 TV lines horizontal resolution—sufficient for retail floors, transportation hubs, parking structures, and control rooms where evidence-grade footage matters without excessive storage overhead. Super Dynamic 6 fusion (combining Super Dynamic, Adaptive Black Stretch, and VMD) ensures usable detail in mixed lighting—a real advantage when you're dealing with sun-blasted entrances and dim back rooms simultaneously. Varifocal 3.8–8.0 mm CS-mount lens allows field focal-length adjustment without hardware swaps, reducing on-site inventory burden.

Compatibility

The WV-CW634F integrates into surveillance networks requiring Day/Night ICR (IR Cut filter Removal) switching and VMD (Video Motion Detection) analytics. The CS-mount lens design enables standard C-mount ecosystem compatibility, permitting field replacement or optical customization without replacing the camera body. Mounting options support both flush-mount (F-type) and surface-mount (S-type) ceiling installations, plus optional embedded ceiling mount via the WV-Q169A accessory. The camera operates on 24 V AC or 12 V DC power—standard in most fixed-dome surveillance infrastructure. Fog compensation is standard, supporting coastal or high-humidity environments.

Installation Notes

IP66 rating handles dust and direct water spray but not full submersion—skip this if you need IP67 or higher for washdown environments. The optional heater maintains operation between –30 °C and +60 °C (–22 °F to 140 °F); deployments beyond this range require additional thermal management. The 3-way hinge (horizontal, vertical, and swivel rotation) permits on-site aiming without tools. ABF (Auto Back Focus) eliminates manual focus calibration in both color and B/W modes. HLC (High Light Compensation) reduces blooming from vehicle headlights and point-source glare. Adaptive Digital Noise Reduction integrates 2D-DNR for cleaner footage at low light.

What's in the Box

• 1x CD-ROM (Operating Instructions)
• 1x Camera Mount Bracket
• Fixing Screws (multiple)
