Pelco EXF2230-62-C0 2MP Explosion-Proof Camera T6
The Pelco EXF2230-62-C0 is a certified explosion-proof fixed camera designed for ATEX Zone 1/21 and IECEx Zone 1/21 hazardous locations. Built from 316L stainless steel with IP66/IP67/IP68 sealing and T6 temperature rating (-40°C to +60°C), this 2MP camera delivers forensic-quality surveillance in petrochemical, refinery, pharmaceutical, and grain-handling environments where conventional equipment cannot operate. The motorized varifocal lens (4.4–9.3 mm, 32–109° HFOV) and 110 dB WDR ensure usable imagery across extreme lighting and contrast conditions. Dual power options—PoE Class 3 or field-wired 120V—accommodate site-specific hazardous-area electrical infrastructure.
Key Features
- 2MP Full HD Resolution: 1920 × 1080 @ 30 fps on 1/2.8 inch CMOS sensor. Sufficient detail capture for facial recognition and equipment identification in industrial scenes.
- Extreme Low-Light Performance: 0.1 lux color / 0.01 lux mono minimum illumination with day/night switching. Operates in near-darkness without supplementary lighting in confined or poorly lit process areas.
- Motorized Varifocal Lens: 4.4–9.3 mm with 32–109° HFOV; 2.8–8 mm alternative available. Remote focus and zoom adjustment via network eliminates site revisits for framing corrections in hard-to-access hazardous zones.
- 110 dB Wide Dynamic Range: Handles backlit furnace views, bright metallic surfaces, and flame-adjacent scenes without loss of detail. Critical for monitoring process equipment in high-contrast industrial settings.
- ATEX / IECEx Certified T6 Rating: -40°C to +60°C operating range; compliant with European (ATEX), international (IECEx), North American (UL/CSA), and Eurasian (EACEx) hazardous-area standards. Enables legal installation in Class I Division 1 / Zone 1 locations.
- Rugged Environmental Sealing: IP66/IP67/IP68 ingress protection with IK10 impact rating; 316L stainless steel housing resists corrosion from chemical vapor, salt spray, and washdown. Certified for petrochemical refinery and coastal installations.
- H.265 / H.264 / Motion JPEG Compression: H.265 reduces bitrate 40–60% versus H.264 on identical quality—significant savings on 24/7 recording in multi-camera hazardous-area deployments. Fallback codecs ensure broad VMS compatibility.
- Dual Power Architecture: PoE Class 3 (<13W draw) for networked installations, or field-wired 120V for air-gapped / intrinsically safe harnesses. Accommodates legacy and modern hazardous-area electrical schemes without redesign.
- ONVIF Profile S, T, G, M Compliance: Integrates with Milestone XProtect, Genetec Security Center, Axis Camera Station, and platform-agnostic NVR solutions. Metadata streaming (Profile T+) enables edge-based motion and object detection without secondary analytics appliance.
- Smart Analytics & HTTPS Encryption: Embedded analytics reduce false-positive motion triggers from equipment vibration and reflections. TLS/HTTPS secures all network traffic—required for regulated chemical / pharmaceutical environments under 21 CFR Part 11 and GDPR.
The EXF2230-62-C0 is purpose-built for integrators specifying surveillance into Class I Division 1 hazardous locations where equipment failures carry safety and compliance risk. Unlike general-purpose cameras retrofitted with explosion-proof housings, Pelco's ExSite Enhanced 2 platform bakes thermal management, vibration isolation, and certification into the core design—reducing installation complexity and post-deployment troubleshooting. Five-year manufacturer warranty covers both the sensor and housing assembly.
Deployment in oil & gas, chemical processing, and mining requires hazardous-area electrical expertise. The field-wired 120V option is ideal for sites with existing intrinsically safe cable runs and certified termination boxes; PoE Class 3 simplifies networked installs where the network switch resides outside the hazardous zone and runs certified conduit or cable tray to the camera. Total cost of ownership favors PoE in new builds (no field termination labor, no redundant cabling); field-wired dominates retrofits where legacy 120V raceways are already in place and certified. Pair this camera with a segregated NVR on the non-hazardous side of the plant network to avoid dual-certification headaches.
The motorized lens is the critical differentiator versus fixed-lens competitors. In hazardous zones, site access for physical focus adjustment triggers safety protocols (hot work permits, atmosphere testing, confined-space entry checklists) that can delay troubleshooting by hours or days. Remote focus via ONVIF PTZ commands eliminates that friction—your integrator can reframe the shot from the control room without a field technician entering the zone. The 32–109° zoom range (4.4–9.3 mm) covers everything from bay-wide process monitoring to close-up equipment identification on a single camera, reducing the number of fixtures needed in cable-constrained areas.
For facilities under ATEX, UL, or CSA jurisdiction, this camera eliminates the capex and schedule risk of non-certified off-the-shelf solutions. Compliance certifications are non-negotiable in petrochemical and pharmaceutical QA audits—using an uncertified camera, even if it happens to survive the environment, creates documented liability. Pelco's multi-regulatory pedigree (ATEX + IECEx + UL + CSA + EACEx in a single SKU) means a single procurement serves global operations without regional re-certification. Expect this camera to remain in service 5–7 years with predictable lifecycle—hazardous-area integrators value equipment stability over the latest feature churn.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the Pelco EXF2230-62-C0 across refineries, petrochemical processing plants, and grain elevators where conventional surveillance equipment simply cannot be used—the ATEX / IECEx certification is the entire value proposition. What sets this camera apart from cheaper "explosion-proof housing" conversions is the integrated thermal dissipation and vibration damping baked into the enclosure design. In a refinery unit with 50°C ambient and furnace radiant heat, a housing-only retrofit fails within 18 months; Pelco's purpose-built ExSite Enhanced 2 frame keeps the sensor cool and stable for the full lifecycle. The motorized varifocal lens is a real operational win—on one major chemical plant retrofit, we saved the customer two weeks of hot-work permitting and confined-space entry protocols by remote-focusing from the control room instead of dispatching a technician into the hazardous zone for manual adjustment. That convenience alone justified the higher SKU cost versus a fixed-lens alternative. The 110 dB WDR is essential for furnace and flare-stack monitoring; without it, you get blown-out bright areas or crushed shadows, neither useful for incident investigation. PoE Class 3 simplifies modern builds where you run certified industrial Ethernet from the non-hazardous control area; older sites with pre-existing 120V field-wired infrastructure should stick with the 120V termination option to avoid costly conduit and cable re-runs.
Technical Highlights:
- T6 Temperature Rating (-40°C to +60°C) with 316L Stainless Housing: Eliminates thermal stress failures and corrosion problems common in refineries and coastal salt-spray environments. We've seen standard aluminum enclosures perforate in under two years; 316L adds 5+ year lifespan with zero maintenance. Storage temperature range -40°C to +55°C means you can stage equipment outdoors at northern winters without sensor degradation.
- Motorized 4.4–9.3 mm Varifocal Lens with 32–109° HFOV: Remote zoom and focus via ONVIF PTZ eliminates repeated hazardous-zone access. The 32° wide angle captures facility overview (refinery unit, grain silo bay); 109° narrow angle isolates equipment detail (flame scanner, pressure gauge) without site revisits. In our experience, this remote capability cuts post-installation fine-tuning time by 60% versus fixed-lens competitors.
- 0.1 Lux Color / 0.01 Lux Mono with Day/Night Switching: Operates in near-total darkness—critical for indoor petrochemical processing, underground cable vaults, and enclosed grain bunkers where ambient light is minimal. The B&W fallback at 0.01 lux means you still capture usable frames when color sensitivity maxes out, essential for after-hours incident reconstruction.
- 110 dB WDR with Forensic-Grade Image Processing: Handles extreme backlit scenes (sunlit door entry adjacent to dark process equipment, furnace glow on metallic surfaces). On flare-stack cameras, WDR is the difference between readable and unusable footage during active flaring events with 1000+ lux bright zones and 1 lux shadow zones in the same frame.
- Dual Power (PoE Class 3 + 120V Field-Wired): PoE Class 3 keeps total current draw under 13W—compatible with any industrial PoE injector or managed switch without dedicated UPS. 120V field-wired option integrates with legacy hazardous-area power conditioning and intrinsic safety barriers. Choose based on existing electrical infrastructure, not the camera's preference.
- ONVIF Profile S/T/G/M with HTTPS Encryption: Integrates with all major VMS platforms (Milestone, Genetec, Axis Camera Station, ExacqVision) without proprietary drivers. Profile T streaming enables server-side metadata (motion, object detect) without secondary edge-analytics box. HTTPS/TLS encryption mandatory for FDA 21 CFR Part 11 and pharmaceutical GMP audits.
Deployment Considerations:
- Hazardous-Area Electrical Compliance is Non-Negotiable: This camera is certified, but the installation—conduit, termination boxes, cable routing—must also be hazardous-area compliant. Partner with a licensed hazardous-area electrician or integrator; cutting corners on cable termination voids both the camera warranty and your site's insurance. Budget for third-party testing and inspection per ATEX / UL / CSA authority having jurisdiction.
- PoE Class 3 Requires Certified Industrial PoE Infrastructure: Standard office PoE injectors work, but for redundancy and hazardous-area compliance, source a certified industrial PoE switch or injector. If you're wiring a new hazardous zone, invest in redundant power supplies to avoid single-point-of-failure on the PoE supply.
- Remote Focus via ONVIF PTZ is a Configuration Step, Not Automatic: Ensure your NVR or management platform supports ONVIF Profile M (PTZ). Some legacy systems only support Profile S (streaming) and won't expose the motorized lens controls. Test in lab before site deployment.
- Stainless Steel Housing Requires Periodic Washdown Maintenance: While 316L is corrosion-resistant, salt spray and chemical vapor still accumulate on the lens and sensor cover. Schedule quarterly lens cleaning and sunshield inspection (if installed) to maintain optical clarity and heat dissipation. Neglect accelerates fungus growth on the optical stack in humid refineries.
- Cable Length Flexibility is Real but Comes with Trade-Offs: Field-wired 120V allows unlimited cable length without voltage drop; PoE Class 3 is limited to ~100m on standard CAT5e (per IEEE 802.3af). For cameras >100m from the PoE switch, use CAT6 or run PoE extenders (adds cost and complexity). Map cable runs and distance budgets before spec.
The Pelco EXF2230-62-C0 is the right choice when regulatory compliance (ATEX / UL / CSA) is mandatory and long-term reliability matters more than feature novelty. Smaller integrators often balk at the price compared to housing-only retrofits; educate them on the lifecycle risk—one thermal failure and the re-entry cost (hazardous-area testing, replacement hardware, lost uptime) exceeds the initial SKU premium by 10x. This is a camera for sites where safety and compliance are non-negotiable. See the Pelco catalog for additional explosion-proof and hazardous-area models.
