Panduit CUEORF03DPW1 Net-Contain Aisle Containment Roof Section
Overview
The Panduit CUEORF03DPW1 is a white PVC/Vinyl roof section panel for Panduit's Panduit Net-Contain hot aisle or cold aisle containment systems. At 35.43 inches wide and 8.94 inches in height, it fills overhead gaps in aisle containment enclosures, preventing conditioned air from bypassing your cooling infrastructure and mixing with hot exhaust air. Aisle containment is one of the highest-ROI thermal management investments in a data center — a single unsealed roof gap can neutralize the efficiency gains of an entire row of in-row coolers, and the CUEORF03DPW1 addresses exactly that weak point.
Key Features
- PVC/Vinyl Construction, White Finish: Lightweight and easy to cut or trim on-site if your row geometry requires a non-standard fit. White finish improves visibility in the overhead containment zone, making it easier to spot gaps during walkdowns.
- 35.43" (900 mm) Width: Sized to span standard aisle containment bays. Verify your bay pitch before ordering — the 900 mm nominal width needs to match your rail or frame spacing, or panels will require trimming.
- 8.94" (227 mm) Height: Provides adequate vertical coverage for the roof plane without requiring stacked panels in most standard overhead containment configurations.
- 37.9" Overall Length: Panel length covers the aisle depth dimension. Cross-reference your aisle depth when planning row count — partial bays at row ends typically require field-cut sections.
- RoHS Compliant: Meets Restriction of Hazardous Substances requirements, relevant if your facility has environmental compliance mandates or if this installation is part of a green data center certification effort.
- Package Quantity of 1: Sold individually, giving you precise quantity control when filling specific gaps in an existing containment run rather than over-ordering full kit quantities.
Integration & Compatibility
The CUEORF03DPW1 is designed as a component within the Panduit Net-Contain aisle containment product family. For a complete containment build, pair this roof section with compatible Panduit end caps, door assemblies, and vertical framing components from the Net-Contain line. When integrating into an existing hot or cold aisle containment row, confirm that your current frame system matches Panduit's Net-Contain rail dimensions and attachment points — mixing containment hardware from different vendors or generations often results in sealing gaps that require custom fillers. This panel is sold as a single unit; for larger deployments or multi-row builds, calculate your bay count carefully to avoid job-site shortages.
Frequently Asked Questions
Q: What material is the CUEORF03DPW1 made from?
A: The CUEORF03DPW1 is constructed from PVC/Vinyl in a white finish, making it lightweight and field-trimmable for non-standard bay widths.
Q: What are the dimensions of this roof section?
A: The panel measures 35.43 inches (900 mm) wide, 8.94 inches (227 mm) in height, and 37.9 inches in overall length.
Q: Is the CUEORF03DPW1 RoHS compliant?
A: Yes, the CUEORF03DPW1 meets RoHS (Restriction of Hazardous Substances) compliance standards.
Q: Is this panel sold individually or in a multi-pack?
A: It is sold with a package quantity of 1 — one roof section panel per order.
Q: What containment system is this panel designed for?
A: It is part of Panduit's Net-Contain aisle containment system and is designed to integrate with compatible Net-Contain framing, end caps, and door assemblies for hot or cold aisle containment builds.
The CUEORF03DPW1 is a straightforward component, but roof sections are where containment systems fail most often in practice. At 900 mm wide and 37.9 inches in length, this panel covers one bay overhead — and an unsealed overhead gap in a cold aisle is essentially a short-circuit path that dumps conditioned air directly into hot exhaust before it reaches your server inlets. Get one wrong and your PUE numbers will tell you about it.
Technical Highlights:
- 900 mm (35.43") Nominal Width: Matches standard Net-Contain bay spacing — but this is the spec to verify first. If your row was built with a different frame pitch, you'll be trimming PVC on-site, which is workable but adds labor time per bay.
- 8.94" (227 mm) Height: Covers the vertical roof plane without stacking in standard overhead containment. For raised plenum or non-standard ceiling heights, confirm clearance before the panels arrive on-site.
- RoHS Compliance: Relevant for facilities pursuing LEED certification or operating under EU environmental compliance mandates — it's a box you'll need to check during procurement documentation for green building projects.
Deployment Considerations:
- The 37.9" overall length determines aisle depth coverage per panel — calculate your total aisle depth and divide by 37.9" to get your panel count. Order at least one extra for the inevitable field-cut at the row end.
- PVC/Vinyl panels can creep over time under sustained heat exposure if your containment zone runs consistently above design temperatures — confirm your aisle temperature profile is within normal operating range before assuming long-term sealing integrity without periodic inspection.
This panel is the right pick for expanding or repairing an existing Panduit Net-Contain deployment in a hyperscale colocation row or enterprise data center where bay-by-bay overhead sealing is being phased in alongside new rack additions.
