i-PRO 101-TX00 M90 Transmitter

We've deployed the i-PRO 101-TX00 M90 in a variety of modular camera builds, and what stands out is the flexibility it offers without sacrificing image quality. The 8MP 4K output and low-light sensitivity (0.06 lx) make it viable for both well-lit retail and dusk/dawn perimeter surveillance. Where this transmitter shines is in systems where you're mixing sensor types — for example, pairing a standard RGB head with a separate IR module, or mounting the transmitter in an environmentally sealed enclosure away from the optics. The modular architecture also means you can upgrade the sensor head in a year or two without replacing the transmission pipeline; that operational flexibility is undervalued in legacy-heavy accounts. On the codec side, we've seen H.265 adoption accelerate across newer VMS platforms, and the fallback to H.264/MJPEG ensures that a 101-TX00 M90 won't become a liability if a customer's recording platform doesn't advance as quickly. IK10 rating and PoE+ power delivery are solid practical features — pole-mounted units withstand weather vibration and the single-cable PoE run reduces installation complexity on high-rise or multi-building sites. The one operational caveat: VMD analytics are edge-based and somewhat rudimentary. If you need sophisticated motion filtering (person vs. vehicle, loitering detection, intrusion zones), you'll still want VMS-side or third-party analytics. The transmitter gives you basic motion events, not forensic intelligence.

Technical Highlights:

• H.265 Codec with H.264/MJPEG Fallback: H.265 reduces bitrate 40–60% on equivalent quality, lowering storage and bandwidth costs on multi-camera, 24/7 recording projects. The fallback ensures compatibility with older NVR platforms or hybrid deployments where not all cameras stream the same codec. On a 16-camera site, H.265 often eliminates the need for a second NVR license or storage upgrade.
• 0.06 lx Low-Light Sensitivity: Operates in near-darkness without external IR floods, critical for perimeter deployments where pole-mounted lighting is impractical or cost-prohibitive. In our experience, this sensitivity level covers most outdoor scenes from dusk to near-midnight; additional IR boost or external lighting is rarely needed unless you're covering ground-level fence details beyond 20 meters.
• PoE+ 802.3at Power: Single Cat5e/Cat6 cable carries video and power. Eliminates separate 12V/24V power runs, reducing labor and material cost on distributed installations. A standard PoE+ switch can power 4–6 units per 90W PoE+ port; verify your switch's budget before over-subscribing.
• IK10 Impact Rating: Pole-mounted and corner-mounted units tolerate vibration, wind load, and incidental impacts without optical or sensor misalignment. We've seen IK10-rated housings survive years of weather exposure and occasional bumps from maintenance ladders or vehicle contact.
• VMD Analytics at the Edge: Motion detection runs on the transmitter rather than the NVR, reducing server CPU load and allowing recording policies (record-on-motion, discard-otherwise) to be enforced locally. Useful for cost-sensitive storage scenarios, but not a replacement for sophisticated VMS-side analytics.
• ONVIF Profile S/T Compliance: Standard VMS platforms (Genetec, Milestone, Avigilon, ExacqVision, Hanwha WiseNet) recognize and integrate the transmitter natively. No proprietary plugins or vendor-specific SDK required; your integrator can swap transmitters or VMS without renegotiating the entire architecture.

Deployment Considerations:

• Modular architecture assumes a separate sensor head. Do not confuse the 101-TX00 M90 with a standalone box camera — you'll need to source or specify the camera head independently. This is a transmitter module, not a camera.
• PoE+ power budget is modest (~13W typical). If you're running IR boost or active heating on the sensor head, verify total power draw before committing to PoE+-only deployment. Some outdoor installations require PoE++ or supplementary 24V DC.
• VMD motion detection is basic frame-difference logic, not ML-based person/vehicle classification. If the project requires zone-based intrusion alerts or loitering detection, deploy VMS-side analytics or a separate edge AI appliance downstream of the transmitter.
• Mounting options (pole, corner, rack) assume you're providing the mechanical bracket or housing. Standard NEMA/IP67 outdoor enclosures are compatible, but always verify environmental rating and thermal management before installation in extreme climates.
• Temperature operating range (-10°C to +50°C) excludes extreme hot or cold environments. For arctic or high-temperature industrial settings, confirm sensor and transmitter thermal specifications separately — some modular builds may require active cooling or heating.
• Audio input is analog or digital; confirm your sensor head's audio output format before assuming plug-and-play integration. Impedance mismatch or missing amplification can introduce hum or low signal.

The i-PRO 101-TX00 M90 is right for integrators building modular, codec-flexible camera systems or upgrading existing transmission infrastructure with high-resolution 8MP output and edge motion analytics. If you're standardizing on a single camera vendor and need a simple all-in-one box, evaluate i-PRO's integrated camera line instead. For scalable, mixed-sensor deployments, the 101-TX00 M90 offers solid operational value and VMS agility. Explore the full i-PRO catalog for compatible sensor heads and transmission options.
