Lenovo 4XG7A63083 SD530 Xeon Gold 5220R

Lenovo 4XG7A63083 Intel Xeon Gold 5220R Processor for SD530

Overview

The Lenovo 4XG7A63083 is a factory-configured Intel Xeon Gold 5220R processor option for the ThinkSystem SD530 server node. Built on Intel's 2nd Generation Xeon Scalable (Cascade Lake) architecture, the 5220R brings 24 physical cores and 48 threads to a 1U half-width node — a density profile suited to high-core-count compute workloads where rack space and power draw are both constrained. If you're configuring SD530 nodes for a dense server deployment and need to evaluate processor options, the 5220R lands in the mid-range of the Gold family: strong parallel throughput, a 4 GHz boost ceiling, and a 150W TDP that stays within standard server thermal envelopes.

Key Features

• 24 Cores / 48 Threads at 2.2 GHz Base: The 5220R runs a 2.2 GHz base clock with Turbo Boost up to 4.0 GHz. For workloads like video analytics, transcoding, or parallel database queries, the 48 available threads allow significant concurrent task execution without thrashing the scheduler — relevant when running multiple VM instances or containerized services on a single node.
• Cascade Lake 14nm Microarchitecture: The Cascade Lake refresh (indicated by the 'R' suffix) improves per-core performance over the original Cascade Lake at the same TDP. The 5220R specifically adds clock speed headroom compared to the base 5220, giving you more headroom in burst workloads without changing the thermal or power infrastructure.
• 35.75 MB L3 Cache: With nearly 36 MB of shared L3 cache across 24 cores, working data sets for compute-heavy tasks — think in-memory databases, large video frame buffers, or ML inference batches — stay closer to compute rather than round-tripping to DRAM. This directly reduces latency on cache-resident workloads.
• Hexa-Channel DDR4-2667 MHz, Up to 1 TB: Six memory channels running at 2667 MHz provide substantial memory bandwidth — the 5220R can feed data to 24 cores without the memory subsystem becoming the bottleneck. The 1 TB ceiling means a single SD530 node can be provisioned with enough RAM to host multiple large VMs or handle in-memory analytics without swapping.
• LGA 3647 (Socket P) Platform: The LGA 3647 socket is the standard for Intel Scalable processors on the SD530 platform. This is a Lenovo-configured option part — it is matched to SD530's motherboard and thermal solution, so there's no guesswork on heatsink compatibility or BIOS support.
• 150W TDP: At 150W, the 5220R sits within the standard power delivery range of the SD530's shared infrastructure tray. You won't need to upgrade cooling or power distribution to deploy this SKU in a standard SD530 chassis — budget power and rack cooling accordingly when calculating per-node draw across a full chassis.
• 64-Bit Operating Mode: Supports standard 64-bit OS and hypervisor deployments. No restrictions on OS compatibility for current enterprise hypervisors or Linux distributions targeting Xeon Scalable infrastructure.

Integration and Compatibility

The 4XG7A63083 is a Lenovo-qualified processor option for the ThinkSystem SD530 platform. As a structured part number from the Lenovo server configurator ecosystem, it is designed to be ordered against a compatible SD530 node bill of materials. Confirm your SD530's current processor socket population and thermal module configuration before ordering — the SD530 supports dual-socket configurations, and heatsink selection depends on whether the opposing socket is populated. Memory configuration should be planned against the hexa-channel architecture to maximize bandwidth: six DIMMs per CPU in a fully populated dual-socket node yields twelve channels of DDR4-2667 total. For workloads on NVR or video intelligence platforms, the 24-core count accommodates parallel stream decoding or analytics inference alongside management services without CPU contention.

Frequently Asked Questions

Q: What server platform is the Lenovo 4XG7A63083 designed for?

A: The 4XG7A63083 is a Lenovo-qualified processor option for the ThinkSystem SD530 server node. It uses the LGA 3647 (Socket P) interface specific to Intel 2nd Generation Xeon Scalable processors on that platform.

Q: What is the core and thread count of the Xeon Gold 5220R in this configuration?

A: The Intel Xeon Gold 5220R delivers 24 physical cores and 48 threads, running at a 2.2 GHz base frequency with Turbo Boost up to 4.0 GHz.

Q: How much memory does the 5220R support, and at what speed?

A: The 5220R supports up to 1 TB of DDR4 RAM across six memory channels (hexa-channel) running at 2667 MHz. Full channel population is recommended to take advantage of the available memory bandwidth.

Q: What is the TDP of the Xeon Gold 5220R and does it require special cooling in the SD530?

A: The 5220R has a 150W Thermal Design Power rating. This falls within the standard thermal envelope for the SD530 platform, though heatsink selection should be confirmed based on whether the second processor socket is populated.

Q: Is the 4XG7A63083 compatible with virtualization workloads?

A: Yes. The processor supports 64-bit operating modes and the 24-core/48-thread configuration is well-suited for running multiple virtual machines or containers. The 1 TB maximum memory support per processor allows substantial VM density per node.

Q: What microarchitecture does the Xeon Gold 5220R use?

A: The 5220R is based on Intel's Cascade Lake refresh architecture, fabricated at 14nm. The 'R' suffix denotes the revised Cascade Lake generation, which offers improved clock speeds compared to the base 5220 at the same TDP.

Jerry Tildsen

The 4XG7A63083 puts a 24-core Xeon Gold 5220R into the SD530's compact half-width footprint — and the 4.0 GHz Turbo ceiling is the spec worth paying attention to here. In bursty workloads like video analytics inference or VM consolidation, that headroom above the 2.2 GHz base matters more than base frequency comparisons on paper.

Technical Highlights:

• 24C/48T at 150W TDP: You get substantial parallelism without stepping into the high-TDP bracket. At 150W, this stays within SD530 standard infrastructure — no cooling upgrades required for single or dual-socket configurations within rated parameters.
• 35.75 MB L3 Cache: For workloads that recycle the same data set repeatedly — frame buffers in video processing, active index pages in databases — nearly 36 MB of shared cache reduces DRAM round-trips and keeps latency low under concurrent thread load.
• Hexa-Channel DDR4-2667 with 1 TB Ceiling: Six memory channels feeding 24 cores is a favorable ratio. Populate all six channels to avoid bandwidth asymmetry; running four DIMMs on a six-channel processor leaves two channels idle and reduces aggregate throughput noticeably.

Deployment Considerations:

• In a dual-socket SD530 configuration, heatsink selection is socket-population-dependent — verify the SD530's thermal module part number against Lenovo's configurator before finalizing your BOM if the second socket will be empty or populated with a different processor TDP class.
• The 5220R's 14nm process node means power density is higher than 10nm successors. In high-ambient-temperature rack environments (above 35°C inlet), derate your per-chassis node count accordingly against the SD530's thermal specifications.

The 4XG7A63083 is a strong fit for SD530-based edge compute or dense virtualization racks where per-node core count and memory headroom matter more than absolute per-core frequency — video intelligence nodes running parallel analytics pipelines being the clearest deployment match.
