i-PRO NVR-DTL-1-64TB-V7 Tower NVR Server
Overview
The NVR-DTL-1-64TB-V7 is a tower-based network video recorder purpose-built for mid-to-large surveillance deployments requiring sustained 150–250 Mbps recording throughput. It pairs an Intel 6-core/12-thread Xeon processor with 32GB RAM and up to 64TB usable storage, running VideoInsight (VI) Server software preinstalled and activated. This is a fully configured, tested, and plug-and-play system — no field assembly required.
Compatibility
The NVR-DTL-1-64TB-V7 integrates with any ONVIF-compliant IP camera or third-party surveillance source capable of H.265, H.264, or MJPEG encoding. It is compatible with VideoInsight Server workflows and supports Windows 11 PRO-based management tools. Network connectivity is dual 1GB Ethernet (BASE-T), suitable for enterprise LAN or dedicated surveillance subnets at 1 Gbps throughput. Storage capacity accommodates up to 1×3.5-inch enterprise HDD plus 1×M.2 SSD for OS — no RAID support on internal bays.
Installation Notes
Physical footprint is compact for a tower NVR: 13.4" height, 3.6" width, 11.7" depth, weighing 12 lbs. Power draw is 260W fixed PSU — ensure 120V/240V supply with adequate circuit protection. Rear drive slots support enterprise-class 3.5-inch HDDs via special order; configuration time may extend lead time. Video output is dual DisplayPort plus one HDMI for multi-monitor or KVM integration. TPM 2.0 on-board encryption supports secure credential storage; no RAID controller, so data resiliency depends on external backup or redundant recording to secondary NVRs. Warranty is 3-year next business day on-site service after remote diagnosis by i-PRO support team.
What's in the Box
- NVR-DTL-1-64TB-V7 tower unit (fully configured and tested)
- 1×260W fixed power supply
- Windows 11 PRO pre-installed
- VideoInsight Server software pre-installed and activated
- 1-year VI HM+ license activation (for secondary machine use)
