HES 10318W-3-00 9507 Socket for Brown White Loop
The HES 10318W-3-00 is a precision 9507 socket connector engineered for brown and white loop wiring installations in professional access control and security systems. This compact, reliable connector facilitates seamless low-voltage connectivity in both new deployments and retrofit applications across commercial security environments.
Key Features
- 9507 socket connector form factor for standardized compatibility
- Brown and white loop wiring configuration
- Supports 12V and 24V DC circuits
- Compatible with HES and third-party control systems
- Ideal for access control and security system integration
Technical Specifications
- Form Factor: 9507 socket connector
- Voltage Rating: 12V or 24V DC
- Wiring Configuration: Brown and white loop topology
- System Compatibility: HES and third-party control systems
Applications
The HES 10318W-3-00 socket is suitable for commercial security installations requiring reliable low-voltage connectivity. Its standardized 9507 form factor ensures seamless integration with existing HES infrastructure and compatible third-party systems operating on 12V or 24V DC power supplies. Ideal for door locks, magnetic locks, and access control devices in office buildings, facilities, and enterprise security deployments.
