Geovision 125-TBL8810-0000 IP Bullet Camera
Overview
The Geovision 125-TBL8810-0000 is an outdoor bullet IP camera designed for perimeter surveillance and general-purpose facility monitoring where you need automatic Day/Night switching without manual filter adjustment. It combines a fixed 2.8–12mm varifocal lens with integrated IR illumination and H.265 encoding to balance image clarity, coverage flexibility, and network efficiency on a single PoE power source. The 1/2.8" sensor captures 137×233 resolution; H.265 compression cuts bandwidth roughly in half compared to H.264, a meaningful factor when deploying multiple cameras on bandwidth-constrained network links or when multi-camera 24/7 recording must fit within modest storage budgets.
Compatibility
The 125-TBL8810-0000 integrates with any IP video management system (VMS) that supports ONVIF Profile S or standard H.265/H.264 streaming. It draws under 13W via 802.3af PoE, so it operates on standard gigabit PoE switches without requiring PoE+ (802.3at) infrastructure. Cabling follows standard IPCAM Cat5e/Cat6 runs; no specialized connectors or custom patch panels are needed. The camera pairs with Geovision's own management platforms (GV Center, GV Control Center) or third-party systems like Milestone Xprotect, Axis Camera Station, or any ONVIF-compatible recorder.
Installation Notes
The camera accepts four mounting configurations: wall brackets (GV-Mount503, GV-Mount503-1), pole mounts (GV-Mount420, GV-Mount440-1 for poles Ø67–127mm), and convex/concave corner brackets (GV-Mount300-2, GV-Mount310-2) for edge-of-structure placement. Its compact footprint (5.4" W × 9.17" H × 6.3" D, 3.64 lb) fits confined spaces and does not require special reinforcement for standard structural mounting. The varifocal lens (2.8–12mm, F/1.6) is field-adjustable; manual focus and iris allow scene optimization without removing the camera. Environmental limits are not detailed in available documentation—confirm operating temperature range and IP rating with the manufacturer datasheet before deploying in extreme climates or washdown environments.
What's in the Box
Package contents are not specified in available documentation. Consult the manufacturer or distributor for a detailed packing list before ordering spare units or bulk deployments.
