Geovision 125-EBD4813-000 Outdoor Network Camera
Overview
The Geovision 125-EBD4813-000 is a fixed compact outdoor IP camera built for surveillance sites where physical durability and flexible mounting matter as much as image quality. It captures video in H.265 codec—cutting storage and bandwidth overhead roughly in half compared to H.264—critical when you're running 24/7 recording across multiple cameras. The IK10 impact rating means it can withstand direct strikes and vandalism attempts without housing damage, making it suitable for exposed locations like retail storefronts, loading docks, or transit stations. IR and automatic day/night switching deliver usable video from bright daylight through complete darkness, eliminating blind spots during low-light hours.
Compatibility
The 125-EBD4813-000 integrates into any standard IP surveillance network supporting H.265 and H.264 streams. It requires PoE (802.3af)—standard 13W budget on any switch port with 802.3af capability. IPCAM cabling (Category 5e or better) connects the camera to your network infrastructure with no separate power supply required. The camera supports ONVIF-compliant VMS platforms, allowing integration into Milestone, Genetec, or other enterprise video management systems that speak the ONVIF protocol. Mounting compatibility spans wall, pole, pendant, corner, and rack orientations via Geovision's accessory bracket line (GV-Mount107, GV-Mount211-1, GV-Mount300-2, GV-Mount310-2, GV-Mount420, and others)—check the accessory catalog to confirm the bracket matches your installation geometry.
Installation Notes
The compact form factor (Φ120 × 334 mm) fits tight spaces without adding structural load—at 0.74 kg (1.63 lbs), it requires minimal bracket reinforcement. Varifocal lens (2.7–13.5 mm, F/1.2 maximum aperture) allows field adjustment without changing optics; orient focus during initial commissioning under your actual lighting. Ensure PoE power sourcing meets 802.3af minimum (minimum 15W per port on your switch), and route cabling away from high-voltage runs to avoid interference with IR function. Confirm mounting bracket clearance before final installation—some corner and pendant mounts require pre-drilled holes or conduit routing.
What's in the Box
- 1× Geovision GV-EBD4813 camera unit
- 1× Pendant mounting bracket (Φ120 × 334 mm)
