Image sensor:
5MP 1/2.8" CMOS sensor (x4)
Maximum resolution:
20MP
Minimum Scene Illumination in color:
0.05 lux (color), 0.1 lux (B/W)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
2592 (H) × 1944 (V) (x4)
Focal Length:
2.8mm ~ 8.0mm (x4)
Horizontal Field of View (HFOV:
4x 51° ~ 93°
IR Distance:
NA
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
39°~68° (x4)
Audio compression:
G.711
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input (1.0Vms, 3K ohm), 1 output
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper (DWC-PVX20WATW)
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left (DWC-PPVX20WATW)
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
4x Micro SD/SDHC/SDXC class 10 cards (cards not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, FTP server, SD card recording
Privacy Zones:
16 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x2, x3, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP:
IPv4
LAN:
1000Base-T (1Gbps)
Network resolution:
4. H.264: 2592x1944 2560x1440 1920x1080 704x576 704x480 640x480 640x360 352x288 352x240, 4x MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
Any ONVIF conformant CMS, DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Required. Sold separately
Camera Dimensions (H X W X D:
8.26" x 3.61" (210 x 91.8 mm)
Camera Weight:
4.18 lbs (1.9kg)
Housing:
Panoramic, Vandal Dome
Housing Color:
White
IK rating:
IK10 Rated
IP rating:
Weather Resistant (IP67)
Materials:
Aluminum die-casting
American wire gauge (AWG:
Cable type #18
Power Consumption:
DC12V: max 28W, 2.33A, PoE: max 28W, 2.583A
Power Requirements:
High power PoE injector included, PoE
Warranty:
5 Year Warranty
