Digital Watchdog DWC-MPHS5W37T 5MP Height Strip IP Camera

Discontinued — No Longer Available NewThis model has been discontinued by Digital Watchdog. Shop current Digital Watchdog products → or see the r…

$1,141.00 $619.99 SAVE $521
Usually Ships Same Business Day
In stock

Quantity:

Adding to cart… The item has been added
Compatibility guidance available for your deployment
Experts for pre and post-sales support
Technical and documentation support
Shipping and lead-time confirmation before install

Laura Bennett, IPSD Senior Specialist

Talk to Laura

Specialized training • U.S - based

Senior Specialist • 877-277-7147

Digital Watchdog DWC-MPHS5W37T 5MP Height Strip IP Camera

$1,141.00
$619.99

Overview

SKU: DWC-MPHS5W37T
Condition: New
Availability: No Longer Available
Warranty 5-year warranty

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Description

Discontinued — No Longer Available New

This model has been discontinued by Digital Watchdog. Shop current Digital Watchdog products → or see the recommended alternatives below.

The Digital Watchdog DWC-MHS5W37T (5MP) Height Strip IP Camera is a cutting-edge surveillance solution designed to enhance security in high-traffic areas such as retail stores, banks, and educational institutions. This camera combines high-resolution imaging with a unique height strip design to capture detailed, eye-level images of individuals entering or exiting a facility. Engineered for precision and reliability, the DWC-MHS5W37T integrates advanced technologies to deliver precise and effective monitoring under various lighting conditions.

Key Features

  • 5MP High-Resolution Imaging: This camera captures sharp, detailed video at real-time 30fps, ensuring clarity in every critical moment.
  • Star-Light Plus™ Technology: Provides exceptional color details in near-total darkness, enhancing nighttime security without the need for additional lighting.
  • Intelligent Video Analytics (IVA+): Advanced analytics for detecting and analyzing motion, enhancing security operations and reducing false alarms.
  • 3.7mm Fixed Lens: Offers a wide 87.6° field of view, ideal for monitoring narrow or confined spaces like doorways.
  • Height Measurement: Includes color-coded height indicators that help in quick identification of suspects by height.
  • True Wide Dynamic Range (WDR): Ensures balanced exposure in scenes with varying lighting conditions, capturing clear images in bright and dark areas.
  • Smart DNR™ 3D Digital Noise Reduction: Improves video quality in low-light conditions, reducing noise and enhancing image clarity.
  • Local Storage: Features a Micro SD card slot for local backup, ensuring continuous operation even if network connectivity is lost.

Compatibility

This camera seamlessly integrates with DW Spectrum® IPVMS and is compatible with other ONVIF conformant systems, ensuring easy setup and integration into existing video management systems. Its flexibility is enhanced with support for both PoE and DC12V power inputs, simplifying installation and reducing cabling requirements.

Package Contents

  • DWC-MHS5W37T Height Strip IP Camera
  • Mounting Kit and Screws
  • Quick Start Guide
  • Warranty Card
  • Software Installation CD

Summary

The Digital Watchdog DWC-MHS5W37T sets a new standard for height strip surveillance cameras. With its robust feature set, including 5MP high-resolution imaging, intelligent video analytics, and a unique height strip design, this camera is an ideal choice for businesses that require reliable, high-quality surveillance. Its durable construction and comprehensive warranty ensure it is a dependable part of any security system, standing out for its innovative approach to entry and exit monitoring.

Specifications
Frame Rate: 30fps
Frequency: 50Hz
Sensor Type: 5MP 1/2.8" CMOS sensor
Max Resolution: 5MP
Minimum Scene Illumination in color: 0.26 lux (color)
Total Pixels: 2592 (H) × 1944 (V)
Focal Length: 3.7mm
Horizontal Field of View (HFOV: 87.6°
Lens Type: Fixed Lens
Vertical Field of View (VFOV: 61.6°
IVA+ license: Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction: Smart DNR™ 3D Digital Noise Reduction
Auto gain control: Auto
Day and Night: Auto day/night, Day (color), Night (B/W)
De-fog: Yes
Memory slot: Micro SD/SDHC/SDXC, up to 1TB
Mirror/flip: Yes
Motion Detection: Yes
Operational Notifications: Alarm output activation, Email, SD card recording
Privacy Zones: 16 programmable privacy masks
Sharpness: Yes
Shutter Mode: Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed: 1/15 ~ 1/32000
Slow Shutter Speed: Off, x10, x15, x2, x3, x4, x5, x6, x7.5
White Balance: Yes
Wide Dynamic Range (WDR: True WDR 120dB
Bitrate Control: Multi-stream CBR/VBR H.265
IP: IPv4
LAN: RJ45 (10/100Base-T)
Protocol: Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SMTP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security: 802.1x, HTTPS (TLS), IP filtering, Multi-user authority
Stream Speed: Up to 30fps at all resolutions
Streaming Capability: Dual-stream at different rates and resolutions
Video Bitrate: 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type: H.264, H.265, MJPEG
Video Management Software: Any ONVIF conformant CMS, DW Spectrum® IPVMS
Environmental Operating Humidity: 10-90% (non-condensing)
Environmental Operating Temperature: -4°F ~ 122°F (-20°C ~ 50°C)
Camera Dimensions (H X W X D: 1.85" x 1.45" x 33.85" (47 x 37 x 860mm)
Camera Weight: 1.98 lbs (0.9kg)
Housing: Height Strip
Housing Color: White
Materials: Aluminum metal sheet height strip housing, For indoor use
Measurment Standards: Empirial (feet)
American wire gauge (AWG: 80M, Cable type #18
Power (Max: DC12V: max 4.0W, 333.3mA, PoE: max 4.8W, 100mA
Power Requirements: Adapter not included, PoE
Warranty: 5 Year Warranty
